ClassProduct nameEANIsolationNominal output powerNominal output voltageNominal output current
Constant Current | Linear / Area | Non-dimmable
ELEMENT Dipswitch
ELEMENT 18/220-240/350 D CS L 🛈
Product family benefits
  • Flexible current setting (DIPswitch – 4 currents)
  • Small housing for flexible luminaire designs
  • High efficiency (up to 94%)
  • Enhanced safety due to overload, overtemperature, short-circuit protection
Areas of applicationion
  • Linear lighting for office, school and public areas
  • Suitable for luminaires of protection class I
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC 05, EAC, CCC, BIS, RCM
4052899553071Non isolated5…18 W25…54 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
ELEMENT 40/220-240/350 D CS L 🛈
Product family benefits
  • Flexible current setting (DIPswitch – 4 currents)
  • Small housing for flexible luminaire designs
  • High efficiency (up to 94%)
  • Enhanced safety due to overload, overtemperature, short-circuit protection
Areas of applicationion
  • Linear lighting for office, school and public areas
  • Suitable for luminaires of protection class I
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC 05, EAC, CCC, BIS, RCM
4052899553095Non isolated11…42 W55…120 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
ELEMENT 60/220-240/350 D CS L 🛈
Product family benefits
  • Flexible current setting (DIPswitch – 4 currents)
  • Small housing for flexible luminaire designs
  • High efficiency (up to 94%)
  • Enhanced safety due to overload, overtemperature, short-circuit protection
Areas of applicationion
  • Linear lighting for office, school and public areas
  • Suitable for luminaires of protection class I
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC 05, EAC, CCC, BIS, RCM
4052899553118Non isolated18…60 W90…175 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
ELEMENT 35/220-240/800 CS L 🛈
Product family benefits
  • Small housing design
  • Flexible current setting (DIPswitch – 4 currents)
  • Enhanced safety due to overload, overtemperature, short-circuit protection
Areas of applicationion
  • Linear lighting for office, school and public areas
  • Suitable for luminaires of protection class I
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC 05, EAC, BIS, RCM, CCC
4052899553132SELV11.5…40.8 W23…51 VDipswitches
500 mA, 600 mA, 700 mA, 800 mA
ELEMENT 55/220-240/1200 CS L 🛈
Product family benefits
  • Small housing design
  • Flexible current setting (DIPswitch – 4 currents)
  • Enhanced safety due to overload, overtemperature, short-circuit protection
Areas of applicationion
  • Linear lighting for office, school and public areas
  • Suitable for luminaires of protection class I
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC 05, EAC, BIS, RCM, CCC
4052899553156SELV21…61 W23…51 VDipswitches
920 mA, 1050 mA, 1075 mA, 1200 mA
EM FIT Dipswitch
EM FIT 18/220-240/350 D CS L 🛈
Product family benefits
  • Small housing design
  • Flexible current setting (DIPswitch – 4 currents)
  • High efficiency and reliability
  • Enhanced safety due to overload, overtemperature, short-circuit protection
  • High light quality due to low ripple current
  • Long lasting and high reliability
Areas of applicationion
  • Linear and area lighting
  • Shop lighting
  • Offices, Public buildings, Supermarkets
  • Industry lighting
  • Suitable for luminaires of protection class I and II
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, UKCA, RCM, EAC, TISI
4062172219891Non isolated5…18.9 W27…54 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
EM FIT 40/220-240/350 D CS L 🛈
Product family benefits
  • Small housing design
  • Flexible current setting (DIPswitch – 4 currents)
  • High efficiency and reliability
  • Enhanced safety due to overload, overtemperature, short-circuit protection
  • High light quality due to low ripple current
  • Long lasting and high reliability
Areas of applicationion
  • Linear and area lighting
  • Shop lighting
  • Offices, Public buildings, Supermarkets
  • Industry lighting
  • Suitable for luminaires of protection class I and II
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, UKCA, RCM, EAC, TISI
4062172219914Non isolated8…42 W40…120 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
EM FIT 60/220-240/350 D CS L 🛈
Product family benefits
  • Small housing design
  • Flexible current setting (DIPswitch – 4 currents)
  • High efficiency and reliability
  • Enhanced safety due to overload, overtemperature, short-circuit protection
  • High light quality due to low ripple current
  • Long lasting and high reliability
Areas of applicationion
  • Linear and area lighting
  • Shop lighting
  • Offices, Public buildings, Supermarkets
  • Industry lighting
  • Suitable for luminaires of protection class I and II
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, UKCA, RCM, EAC, TISI
4062172219938Non isolated18…61.25 W90…175 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
EM FIT 75/220-240/550 D CS L 🛈
Product family benefits
  • Small housing design
  • Flexible current setting (DIPswitch – 4 currents)
  • High efficiency and reliability
  • Enhanced safety due to overload, overtemperature, short-circuit protection
  • High light quality due to low ripple current
  • Long lasting and high reliability
Areas of applicationion
  • Linear and area lighting
  • Shop lighting
  • Offices, Public buildings, Supermarkets
  • Industry lighting
  • Suitable for luminaires of protection class I and II
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, CCC, EAC, ENEC, RCM, UKCA, TISI
4062172219952Non isolated31.5…75.6 W90…216 VDipswitches
350 mA, 400 mA, 500 mA, 550 mA
EM FIT 18/220-240/350 CS L 🛈
Product family benefits
  • Small housing design
  • Flexible current setting (DIPswitch – 4 currents)
  • Enhanced safety due to overload, overtemperature, short-circuit protection
  • High efficiency
  • Long lasting and high reliability
  • High light quality due to low ripple current
Areas of applicationion
  • Linear and area lighting
  • Shop lighting
  • Industry lighting
  • Offices, Public buildings, Supermarkets
  • Suitable for luminaires of protection class I and II
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, CCC, EAC, ENEC, RCM, UKCA
4062172219976SELV5.4…17.85 W27…51 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
EM FIT 40/220-240/800 CS L 🛈
Product family benefits
  • Small housing design
  • Flexible current setting (DIPswitch – 4 currents)
  • Enhanced safety due to overload, overtemperature, short-circuit protection
  • High efficiency
  • Long lasting and high reliability
  • High light quality due to low ripple current
Areas of applicationion
  • Linear and area lighting
  • Shop lighting
  • Industry lighting
  • Offices, Public buildings, Supermarkets
  • Suitable for luminaires of protection class I and II
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, RCM, EAC, CCC, UKCA
4062172219990SELV13.5…40.8 W27…51 VDipswitches
500 mA, 600 mA, 700 mA, 800 mA
EM FIT 60/220-240/1A2 CS L 🛈
Product family benefits
  • Small housing design
  • Flexible current setting (DIPswitch – 4 currents)
  • Enhanced safety due to overload, overtemperature, short-circuit protection
  • High efficiency
  • Long lasting and high reliability
  • High light quality due to low ripple current
Areas of applicationion
  • Linear and area lighting
  • Shop lighting
  • Industry lighting
  • Offices, Public buildings, Supermarkets
  • Suitable for luminaires of protection class I and II
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, CCC, EAC, ENEC, RCM, UKCA
4062172220019SELV24.3…61.2 W27…51 VDipswitches
900 mA, 1050 mA, 1100 mA, 1200 mA
EM FIT 75/220-240/1A6 CS L 🛈
Product family benefits
  • Small housing design
  • Flexible current setting (DIPswitch – 4 currents)
  • Enhanced safety due to overload, overtemperature, short-circuit protection
  • High efficiency
  • Long lasting and high reliability
  • High light quality due to low ripple current
Areas of applicationion
  • Linear and area lighting
  • Shop lighting
  • Industry lighting
  • Offices, Public buildings, Supermarkets
  • Suitable for luminaires of protection class I and II
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, CCC, ENEC, RCM, EAC, UKCA
4062172220033SELV35.1…81.6 W27…51 VDipswitches
1300 mA, 1400 mA, 1500 mA, 1600 mA
EM FIT Dipswitch G2
EM FIT 18/220-240/350 D CS L G2 NEW🛈
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, TISI, BIS
6977078992510Non isolated5…18.9 W25…54 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
EM FIT 40/220-240/350 D CS L G2 NEW🛈
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, TISI, BIS
6977078992534Non isolated8…42 W40…120 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
EM FIT 60/220-240/350 D CS L G2 NEW🛈
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, TISI, BIS
6977078992558Non isolated18…61.2 W90…175 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
EM FIT 75/220-240/550 D CS L G2 NEW🛈
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, TISI, BIS
6977078992572Non isolated31.5…75.6 W90…136 V, 90…150 V, 90…188 V, 90…216 VDipswitches
350 mA, 400 mA, 500 mA, 550 mA
EM FIT 18/220-240/350 CS L G2 NEW🛈
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, TISI, BIS
6977078992596SELV5.4…17.8 W27…51 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
EM FIT 40/220-240/800 CS L G2 NEW🛈
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, TISI, BIS
6977078992619SELV13.5…40.8 W27…51 VDipswitches
500 mA, 600 mA, 700 mA, 800 mA
EM FIT 60/220-240/1200 CS L G2 NEW🛈
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, TISI, BIS
6977078992633SELV24.3…61.2 W27…51 VDipswitches
900 mA, 1050 mA, 1100 mA, 1200 mA
EM FIT 75/220-240/1600 CS L G2 NEW🛈
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, TISI, BIS
6977078992657SELV35.1…76.8 W27…51 V, 27…48 VDipswitches
1300 mA, 1400 mA, 1500 mA, 1600 mA
IT FIT Dipswitch
IT FIT 18/220-240/350 CS D L 🛈
Product family benefits
  • Flexible with 1 driver offers 4 output currents
  • High quality light with very low ripple
  • Very high efficiency
  • Enable slim fixture design with flat 21 mm height metal housing
  • Long lasting and high reliability
  • Non-isolated driver
Areas of applicationion
  • Linear and area lighting
  • Office, industrial and shop lighting

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, BIS, EAC, UKCA, TISI
4062172212649Non isolated5…18.9 W23…54 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
IT FIT 18/220-240/350 CS L 🛈
Product family benefits
  • Flexible with 1 driver offers 4 output currents
  • High quality light with very low ripple
  • Very high efficiency up to 87%
  • Enable slim fixture design with flat 21 mm height metal housing
  • Long lasting and high reliability
  • SELV driver
Areas of applicationion
  • Linear and area lighting
  • Office, industrial and shop lighting
Programming interface: Dipswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, BIS, TISI, EAC, UKCA
4062172212663SELV4.6…18.9 W23…54 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
IT FIT 40/220-240/350 CS D L 🛈
Product family benefits
  • Flexible with 1 driver offers 4 output currents
  • High quality light with very low ripple
  • Very high efficiency
  • Enable slim fixture design with flat 21 mm height metal housing
  • Long lasting and high reliability
  • Non-isolated driver
Areas of applicationion
  • Linear and area lighting
  • Office, industrial and shop lighting

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, BIS, EAC, UKCA, TISI
4062172212687Non isolated8…42 W40…120 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
IT FIT 40/220-240/800 CS L 🛈
Product family benefits
  • Flexible with 1 driver offers 4 output currents
  • High quality light with very low ripple
  • Very high efficiency up to 87%
  • Enable slim fixture design with flat 21 mm height metal housing
  • Long lasting and high reliability
  • SELV driver
Areas of applicationion
  • Linear and area lighting
  • Office, industrial and shop lighting
Programming interface: Dipswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, BIS, TISI, EAC, UKCA
4062172212700SELV11.5…43.2 W23…54 VDipswitches
500 mA, 600 mA, 700 mA, 800 mA
IT FIT 60/220-240/1A2 CS L 🛈
Product family benefits
  • Flexible with 1 driver offers 4 output currents
  • High quality light with very low ripple
  • Very high efficiency up to 87%
  • Enable slim fixture design with flat 21 mm height metal housing
  • Long lasting and high reliability
  • SELV driver
Areas of applicationion
  • Linear and area lighting
  • Office, industrial and shop lighting
Programming interface: Dipswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, BIS, TISI, EAC, UKCA
4062172212724SELV20.7…61.2 W23…54 VDipswitches
900 mA, 1050 mA, 1100 mA, 1200 mA
IT FIT 60/220-240/350 CS D L 🛈
Product family benefits
  • Flexible with 1 driver offers 4 output currents
  • High quality light with very low ripple
  • Very high efficiency
  • Enable slim fixture design with flat 21 mm height metal housing
  • Long lasting and high reliability
  • Non-isolated driver
Areas of applicationion
  • Linear and area lighting
  • Office, industrial and shop lighting

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, BIS, EAC, UKCA, TISI
4062172212748Non isolated20.7…61.2 W90…175 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
IT FIT 75/220-240/1A6 CS L 🛈
Product family benefits
  • Flexible with 1 driver offers 4 output currents
  • High quality light with very low ripple
  • Very high efficiency up to 87%
  • Enable slim fixture design with flat 21 mm height metal housing
  • Long lasting and high reliability
  • SELV driver
Areas of applicationion
  • Linear and area lighting
  • Office, industrial and shop lighting
Programming interface: Dipswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, BIS, TISI, EAC, UKCA
4062172212762SELV29.9…76.8 W23…54 VDipswitches
1300 mA, 1400 mA, 1500 mA, 1600 mA
IT FIT 75/220-240/550 CS D L 🛈
Product family benefits
  • Flexible with 1 driver offers 4 output currents
  • High quality light with very low ripple
  • Very high efficiency
  • Enable slim fixture design with flat 21 mm height metal housing
  • Long lasting and high reliability
  • Non-isolated driver
Areas of applicationion
  • Linear and area lighting
  • Office, industrial and shop lighting

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, BIS, EAC, UKCA, TISI
4062172212786Non isolated31.5…75 W90…216 VDipswitches
350 mA, 400 mA, 500 mA, 550 mA
OT FIT
OT FIT 30/220-240/125 D L 🛈
Product family benefits
  • Small housing design
  • Fixed current
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High quality of light thanks to low output ripple current
  • High efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, BIS, RCM
4052899222557Non isolated6.8…27 W54…216 V125 mA
OT FIT 50/220-240/250 D L 🛈
Product family benefits
  • Small housing design
  • Fixed current
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High quality of light thanks to low output ripple current
  • High efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, BIS, RCM
4052899222571Non isolated13.5…54 W54…216 V250 mA
OT FIT 50/220-240/350 D L 🛈
Product family benefits
  • Small housing design
  • Fixed current
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High quality of light thanks to low output ripple current
  • High efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, BIS, RCM
4052899222595Non isolated18.9…52.5 W54…150 V350 mA
OT FIT 50/220-240/300 D L 🛈
Product family benefits
  • Small housing design
  • Fixed current
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High quality of light thanks to low output ripple current
  • High efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, BIS, RCM
4052899469884Non isolated16.2…52.5 W54…175 V300 mA
OT FIT 35/220-240/350 D LT2 L 🛈
Product family benefits
  • Flexible current setting (LEDset2)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High quality of light thanks to low output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
Programming interface: LEDset
Programming device: LEDset

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, BIS, RCM
4052899478411Non isolated4.1…35 W54…216 V65…350 mA
OT FIT 75/220-240/550 D LT2 L 🛈
Product family benefits
  • Flexible current setting (LEDset2)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High quality of light thanks to low output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
Programming interface: LEDset
Programming device: LEDset

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, BIS, RCM
4052899478435Non isolated6.8…75 W54…216 V125…550 mA
OT FIT 120/220-240/750 D LT2 L 🛈
Product family benefits
  • Flexible current setting (LEDset2)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High quality of light thanks to low output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
Programming interface: LEDset
Programming device: LEDset

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, BIS, RCM
4052899497900Non isolated13.5…120 W54…216 V250…700 mA
OT FIT 45/220-240/200 D L 🛈
Product family benefits
  • Small housing design
  • Fixed current
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High quality of light thanks to low output ripple current
  • High efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC
4052899590946Non isolated5…43.2 W54…216 V200 mA
OT FIT 25/220…240/300 D LT2 L 🛈
Product family benefits
  • Flexible current setting (LEDset2)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High quality of light thanks to low output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
Programming interface: LEDset
Programming device: LEDset

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC
4052899990289Non isolated2…25 W40…216 V35…300 mA
OT FIT Dipswitch
OT FIT 35/220-240/350 D CS L 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 65 W
  • Safety requirement due to overload, overtemperature, short-circuit protection
  • High efficiency
  • User flexibility with four different output currents from one driver
Areas of applicationion
  • Linear and area lighting
  • Office, industrial and shop lighting
  • Suitable for luminaires of protection class I
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CCC, CE, ENEC
4052899531437Non isolated8…40.3 W40…160 V, 40…115 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
OT FIT 65/220-240/350 D CS L 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 65 W
  • Safety requirement due to overload, overtemperature, short-circuit protection
  • High efficiency
  • User flexibility with four different output currents from one driver
Areas of applicationion
  • Linear and area lighting
  • Office, industrial and shop lighting
  • Suitable for luminaires of protection class I
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC 05, EAC, CCC, BIS, RCM
4052899531451Non isolated16…66.5 W70…220 V, 70…190 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
OT FIT 75/220-240/350 D CS L 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 65 W
  • Safety requirement due to overload, overtemperature, short-circuit protection
  • High efficiency
  • User flexibility with four different output currents from one driver
Areas of applicationion
  • Linear and area lighting
  • Office, industrial and shop lighting
  • Suitable for luminaires of protection class I
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC 05, EAC, CCC, BIS, RCM
4062172006323Non isolated16…77 W70…220 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
OT FIT 18/220-240/350 D CS L 🛈
Product family benefits
  • Flexible current setting (DIPswitch – 6 currents)
  • Higher quality of light thanks to low output ripple current
  • High efficiency
  • User flexibility with six different output currents from one driver
  • Safety requirement due to overload, overtemperature, short-circuit protection
  • Long reliable life at maximum permitted temperatures
  • Enable slim fixture design with flat 21 mm height metal housing
Areas of applicationion
  • Linear and area lighting
  • Office, industrial and shop lighting
  • Suitable for luminaires of protection class I
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, UKCA, BIS, EAC
4062172285254Non isolated5…18.9 W32…54 VDipswitches
100 mA, 150 mA, 200 mA, 250 mA, 300 mA, 350 mA
OT FIT 40/220-240/350 D CS L 🛈
Product family benefits
  • Flexible current setting (DIPswitch – 6 currents)
  • Higher quality of light thanks to low output ripple current
  • High efficiency
  • User flexibility with six different output currents from one driver
  • Safety requirement due to overload, overtemperature, short-circuit protection
  • Long reliable life at maximum permitted temperatures
  • Enable slim fixture design with flat 21 mm height metal housing
Areas of applicationion
  • Linear and area lighting
  • Office, industrial and shop lighting
  • Suitable for luminaires of protection class I
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, UKCA, BIS, EAC
4062172285278Non isolated8…42 W40…120 VDipswitches
100 mA, 150 mA, 200 mA, 250 mA, 300 mA, 350 mA
OT FIT 60/220-240/350 D CS L 🛈
Product family benefits
  • Flexible current setting (DIPswitch – 6 currents)
  • Higher quality of light thanks to low output ripple current
  • High efficiency
  • User flexibility with six different output currents from one driver
  • Safety requirement due to overload, overtemperature, short-circuit protection
  • Long reliable life at maximum permitted temperatures
  • Enable slim fixture design with flat 21 mm height metal housing
Areas of applicationion
  • Linear and area lighting
  • Office, industrial and shop lighting
  • Suitable for luminaires of protection class I
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, UKCA, BIS, EAC
4062172285292Non isolated18…61.2 W90…175 VDipswitches
100 mA, 150 mA, 200 mA, 250 mA, 300 mA, 350 mA
OT FIT 75/220-240/550 D CS L 🛈
Product family benefits
  • Flexible current setting (DIPswitch – 6 currents)
  • Higher quality of light thanks to low output ripple current
  • High efficiency
  • User flexibility with six different output currents from one driver
  • Safety requirement due to overload, overtemperature, short-circuit protection
  • Long reliable life at maximum permitted temperatures
  • Enable slim fixture design with flat 21 mm height metal housing
Areas of applicationion
  • Linear and area lighting
  • Office, industrial and shop lighting
  • Suitable for luminaires of protection class I
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, UKCA, BIS, EAC
4062172285315Non isolated31.5…75 W90…216 V, 90…188 V, 90…167 V, 90…150 V, 90…136 VDipswitches
300 mA, 350 mA, 400 mA, 450 mA, 500 mA, 550 mA
OT FIT Dipswitch G2
OT FIT 35/220-240/700 CS L G2 🛈
Product family benefits
  • Flexible current setting (DIPswitch – 4 currents)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High efficiency
  • High quality of light thanks to low output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, EL, ENEC 05, EAC, CCC, RCM, BIS
4052899522534SELV10.0…35.7 W27…51 VDipswitches
500 mA, 600 mA, 650 mA, 700 mA
OT FIT 55/220-240/1A0 CS L G2 🛈
Product family benefits
  • Flexible current setting (DIPswitch – 4 currents)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High efficiency
  • High quality of light thanks to low output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, EL, ENEC 05, EAC, CCC, RCM, BIS
4052899522558SELV14.0…53.6 W27…51 VDipswitches
800 mA, 900 mA, 975 mA, 1050 mA
OT FIT 75/220-240/1A4 CS L G2 🛈
Product family benefits
  • Flexible current setting (DIPswitch – 4 currents)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High efficiency
  • High quality of light thanks to low output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, EL, ENEC 05, EAC, CCC, RCM, BIS
4052899522572SELV21.0…71.4 W27…51 VDipswitches
1100 mA, 1200 mA, 1300 mA, 1400 mA
OT FIT Horticulture NFC
OT FIT 1000/220-400/1A6 D NFC HC 2CH B L 🛈
Product family benefits
  • Flexible and future-proof current setting via NFC (Near Field Communication)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • Higher quality of light thanks to 1% output ripple current
  • Very high efficiency (up to 97%)
  • Protection against 4 kV burst and 2 kV surge voltage (L-N and L-N/PE)
Areas of applicationion
  • Linear and area lighting
  • Horticulture lighting
  • Industry lighting
  • Suitable for luminaires of protection class I
Programming device: DALI magic, FEIG

Type of protection
IP20		Certificates & Approbations
CE
4052899624429Non isolated400…1050 W150…550 V400…1600 mA
OT FIT 500/220-400/1A6 D NFC HC B L 🛈
Product family benefits
  • Flexible and future-proof current setting via NFC (Near Field Communication)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • Higher quality of light thanks to 1% output ripple current
  • Very high efficiency (up to 97%)
  • Protection against 4 kV burst and 2 kV surge voltage (L-N and L-N/PE)
Areas of applicationion
  • Linear and area lighting
  • Horticulture lighting
  • Industry lighting
  • Suitable for luminaires of protection class I
Programming device: DALI magic, FEIG

Type of protection
IP20		Certificates & Approbations
CE
4052899624436Non isolated200…525 W150…550 V400…1600 mA
OT FIT 380/220-400/1A4 D NFC HC L 🛈
Product family benefits
  • Global usage - CE & cURus approval
  • Flexible and future-proof current setting via NFC (Near Field Communication)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • Higher quality of light thanks to 1% output ripple current
  • Very high efficiency (up to 97%)
  • Protection against 4 kV burst and 2 kV surge voltage (L-N and L-N/PE)
Areas of applicationion
  • Linear and area lighting
  • Greenhouse lighting
  • Industry lighting
  • Suitable for luminaires of protection class I
Programming interface: NFC
Programming device: NFC Reader

Type of protection
IP20		Certificates & Approbations
CE, VDE-ENEC, VDE-EMC, EAC, CCC, BIS, cURus
4062172063586Non isolated140…380 W150…550 V400…1400 mA
OT FIT Industry NFC
OT FIT 100/220-240/700 D NFC IND L 🛈
Product family benefits
  • Flexible and future-proof current setting via NFC and LT2
  • Lifetime: up to 100,000 h (temperature at Tc = 75 °C, max. 10 % failure rate)
  • Wide operating temperature range: -40…+65 °C
  • High quality of light thanks to 1% output ripple current
  • High surge protection: up to 4 kV (L-N) / 4 kV (L/N-PE)
  • Very high efficiency (up to 96%)
  • Integrated inrush current limiter
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting solutions for industry, storage areas and retail applications
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
Programming interface: NFC, LEDset
Programming device: NFC, LEDset

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, BIS, RCM
4052899990128Non isolated28…100 W64…300 V200…700 mA
OT FIT 150/220-240/1A0 D NFC IND L 🛈
Product family benefits
  • Flexible and future-proof current setting via NFC and LT2
  • Lifetime: up to 100,000 h (temperature at Tc = 75 °C, max. 10 % failure rate)
  • Wide operating temperature range: -40…+65 °C
  • High quality of light thanks to 1% output ripple current
  • High surge protection: up to 4 kV (L-N) / 4 kV (L/N-PE)
  • Very high efficiency (up to 96%)
  • Integrated inrush current limiter
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting solutions for industry, storage areas and retail applications
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
Programming interface: NFC, LEDset
Programming device: NFC, LEDset

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, BIS, RCM
4052899990142Non isolated43…150 W64…300 V250…1000 mA
OT FIT 75/220-240/550 D NFC IND L 🛈
Product family benefits
  • Flexible and future-proof current setting via NFC and LT2
  • Lifetime: up to 100,000 h (temperature at Tc = 75 °C, max. 10 % failure rate)
  • Wide operating temperature range: -40…+65 °C
  • High quality of light thanks to 1% output ripple current
  • High surge protection: up to 4 kV (L-N) / 4 kV (L/N-PE)
  • Very high efficiency (up to 96%)
  • Integrated inrush current limiter
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting solutions for industry, storage areas and retail applications
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
Programming interface: NFC, LEDset
Programming device: FEIG

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, BIS, RCM
4062172139694Non isolated8.0…75 W64…300 V125…550 mA
OT FIT 300/220-240/1A6 D NFC IND L 🛈
Product family benefits
  • Flexible and future-proof current setting via NFC and LT2
  • Lifetime: up to 100,000 h (temperature at Tc = 75 °C, max. 10 % failure rate)
  • Wide operating temperature range: -40…+65 °C
  • High quality of light thanks to 1% output ripple current
  • High surge protection: up to 4 kV (L-N) / 4 kV (L/N-PE)
  • Very high efficiency (up to 96%)
  • Integrated inrush current limiter
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting solutions for industry, storage areas and retail applications
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
Programming device: FEIG

Type of protection
IP20		Certificates & Approbations
CE, VDE-ENEC, EAC, CCC, BIS, RCM
4062172186179Non isolated40…300 W60…300 V250…1550 mA
OT FIT NFC
OT FIT 35/220-240/350 D NFC L 🛈
Product family benefits
  • Flexible and future-proof current setting via NFC (Near Field Communication)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
Programming interface: NFC

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, BIS, RCM
4052899990166Non isolated6.1…35 W54…216 V75…350 mA
OT FIT 75/220-240/550 D NFC L 🛈
Product family benefits
  • Flexible and future-proof current setting via NFC (Near Field Communication)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
Programming interface: NFC

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, BIS, RCM
4052899990180Non isolated10…75 W54…216 V125…550 mA
OT FIT 25/220-240/250 D NFC F L 🛈
Product family benefits
  • Flat housing (16 mm height) for innovative luminaire designs and applications
  • Flexible and future-proof current setting via NFC (Near Field Communication)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • Higher quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature protection
Areas of applicationion
  • Linear and area lighting
  • Industry lighting
  • Suitable for luminaires of protection class I
Programming interface: NFC
Programming device: FEIG

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, RCM, BIS
4062172063920Non isolated4…25 W54…216 V35…250 mA
OT FIT 35/220-240/400 D NFC F L 🛈
Product family benefits
  • Flat housing (16 mm height) for innovative luminaire designs and applications
  • Flexible and future-proof current setting via NFC (Near Field Communication)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • Higher quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature protection
Areas of applicationion
  • Linear and area lighting
  • Industry lighting
  • Suitable for luminaires of protection class I
Programming interface: NFC
Programming device: FEIG

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, RCM, BIS
4062172063944Non isolated6…35 W54…216 V75…400 mA
OT FIT 75/220-240/500 D NFC F L 🛈
Product family benefits
  • Flat housing (16 mm height) for innovative luminaire designs and applications
  • Flexible and future-proof current setting via NFC (Near Field Communication)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • Higher quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature protection
Areas of applicationion
  • Linear and area lighting
  • Industry lighting
  • Suitable for luminaires of protection class I
Programming interface: NFC
Programming device: FEIG

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, RCM, BIS
4062172063968Non isolated10…75 W54…216 V125…500 mA
OT FIT 25/220-240/500 NFC L 🛈
Product family benefits
  • Flexible and future-proof current setting via NFC (Near Field Communication)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • Fulfilling SVM (≤ 0.4) and PsT (≤ 1.0) standards
  • Higher quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Programming device: FEIG

Type of protection
IP20		Certificates & Approbations
CE, VDE-ENEC, EAC, CCC, BIS, RCM
4062172063982SELV8…25 W20…51 V170…500 mA
OT FIT 35/220-240/700 NFC L 🛈
Product family benefits
  • Flexible and future-proof current setting via NFC (Near Field Communication)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • Fulfilling SVM (≤ 0.4) and PsT (≤ 1.0) standards
  • Higher quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Programming device: FEIG

Type of protection
IP20		Certificates & Approbations
CE, VDE-ENEC, EAC, CCC, BIS, RCM
4062172064002SELV13…35 W20…51 V250…700 mA
OT FIT 55/220-240/1A0 NFC L 🛈
Product family benefits
  • Flexible and future-proof current setting via NFC (Near Field Communication)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • Fulfilling SVM (≤ 0.4) and PsT (≤ 1.0) standards
  • Higher quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Programming device: FEIG

Type of protection
IP20		Certificates & Approbations
CE, VDE-ENEC, EAC, CCC, BIS, RCM
4062172064026SELV21…55 W20…51 V400…1050 mA
OT FIT 75/220-240/1A4 NFC L 🛈
Product family benefits
  • Flexible and future-proof current setting via NFC (Near Field Communication)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • Fulfilling SVM (≤ 0.4) and PsT (≤ 1.0) standards
  • Higher quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Programming device: FEIG

Type of protection
IP20		Certificates & Approbations
CE, VDE-ENEC, EAC, CCC, BIS, RCM
4062172064040SELV29…72 W20…51 V600…1400 mA
OT FIT 100/220-240/750 D NFC L 🛈
Product family benefits
  • Flexible and future-proof current setting via NFC (Near Field Communication)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
Programming interface: NFC
Programming device: FEIG

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, BIS, RCM
4062172122863Non isolated13…100 W54…216 V250…750 mA
OT FIT 100/220-240/700 D NFC HV L NEW🛈
Programming interface: NFC
Programming device: DALI magic, FEIG Programmer, Tuner4TRONIC

Type of protection
IP20		Certificates & Approbations
CE, VDE-ENEC, EAC, CCC, BIS
4062172382298Non isolated28…100 W64…300 V200…700 mA
OT FIT 150/220-240/1A0 D NFC HV L NEW🛈
Programming interface: NFC
Programming device: DALI magic, FEIG Programmer, Tuner4TRONIC

Type of protection
IP20		Certificates & Approbations
CE, VDE-ENEC, EAC, CCC, BIS
4062172382311Non isolated43…150 W64…300 V250…1000 mA
OT FIT Ultraflat
OT FIT 35/220-240/400 D LT2 UF L 🛈
Product family benefits
  • Ultra-flat housing (11 mm height) for innovative luminaire designs and applications
  • Flexible and future-proof current setting via NFC and LT2
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • Higher quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Programming interface: NFC, LEDset
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
EL, VDE-ENEC, EAC, CCC, BIS, RCM, CE, VDE-EMC
4052899590960Non isolated4…38 W54…240 V75…400 mA
OT FIT 75/220-240/700 D LT2 UF L 🛈
Product family benefits
  • Ultra-flat housing (11 mm height) for innovative luminaire designs and applications
  • Flexible and future-proof current setting via NFC and LT2
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • Higher quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Programming interface: NFC, LEDset
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
EL, VDE-ENEC, EAC, CCC, BIS, RCM, CE, VDE-EMC
4052899590984Non isolated8.0…75 W54…240 V150…700 mA
Constant Current | Linear / Area | Dimmable
IT DALI 40/220-240/450 D LT2 L 🛈
Product family benefits
  • Versatile non-isolated DALI driver up to 75 W due to flexible output characteristic
  • Fully programmable via software (DALI Interface)
  • Flexible current setting (RSet)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 10…100 % by amplitude dimming
  • No TouchDIM nor Corridor Function
  • High quality of light thanks to 4% output ripple current
  • High efficiency
  • Low standby power consumption: 0.25 W
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear and area lighting
  • Industry lighting
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM
Programming interface: Rset
Programming device: DALI magic

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, BIS, RCM
4062172380096Non isolated5.4…40 W54…240 V100…450 mA
IT DALI 75/220-240/550 D LT2 L 🛈
Product family benefits
  • Versatile non-isolated DALI driver up to 75 W due to flexible output characteristic
  • Fully programmable via software (DALI Interface)
  • Flexible current setting (RSet)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 10…100 % by amplitude dimming
  • No TouchDIM nor Corridor Function
  • High quality of light thanks to 4% output ripple current
  • High efficiency
  • Low standby power consumption: 0.25 W
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear and area lighting
  • Industry lighting
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM
Programming interface: Rset
Programming device: DALI magic

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, BIS, RCM
4062172380119Non isolated18…75 W90…240 V200…550 mA
IT DALI 100/220-240/800 D LT2 L 🛈
Product family benefits
  • Versatile non-isolated DALI driver up to 75 W due to flexible output characteristic
  • Fully programmable via software (DALI Interface)
  • Flexible current setting (RSet)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 10…100 % by amplitude dimming
  • No TouchDIM nor Corridor Function
  • High quality of light thanks to 4% output ripple current
  • High efficiency
  • Low standby power consumption: 0.25 W
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear and area lighting
  • Industry lighting
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM
Programming interface: Rset
Programming device: DALI magic

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, BIS, RCM
4062172380133Non isolated27…100 W90…240 V300…800 mA
DEXAL Industry NFC
OTI DX 100/220-240/700 D NFC IND L 🛈
Product family benefits
  • Versatile non-isolated DEXAL LED driver up to 150 W due to flexible output characteristic
  • Integrated DEXAL Bus power supply for sensors and wireless radios
  • Simplified luminaire design for wireless lighting control system and sensors
  • Locking and unlocking of luminaire/driver data
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • Prepared for DiiA Specification Parts -250, -251, -252 and -253
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 75 °C, max. 10 % failure rate)
  • High light quality: 1…100% amplitude dimming and 1% output ripple current
  • Wide operating temperature range: -40…+65 °C
  • High surge protection: up to 4 kV (L-N) / 4 kV (L/N-PE)
  • Integrated inrush current limiter
  • Very high efficiency (up to 96%)
Areas of applicationion
  • Linear and area lighting
  • Industry lighting
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, DEXAL, Corridor
Programming interface: DEXAL, NFC, LEDset
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, BIS, RCM
4062172050883Non isolated23…100 W64…300 V200…700 mA
OTI DX 150/220-240/850 D NFC IND L 🛈
Product family benefits
  • Versatile non-isolated DEXAL LED driver up to 150 W due to flexible output characteristic
  • Integrated DEXAL Bus power supply for sensors and wireless radios
  • Simplified luminaire design for wireless lighting control system and sensors
  • Locking and unlocking of luminaire/driver data
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • Prepared for DiiA Specification Parts -250, -251, -252 and -253
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 75 °C, max. 10 % failure rate)
  • High light quality: 1…100% amplitude dimming and 1% output ripple current
  • Wide operating temperature range: -40…+65 °C
  • High surge protection: up to 4 kV (L-N) / 4 kV (L/N-PE)
  • Integrated inrush current limiter
  • Very high efficiency (up to 96%)
Areas of applicationion
  • Linear and area lighting
  • Industry lighting
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, DEXAL, Corridor
Programming interface: DEXAL, NFC, LEDset
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, BIS, RCM
4062172050920Non isolated43…150 W64…300 V250…850 mA
DEXAL NFC
OTI DX 35/220-240/400 D NFC L 🛈
Product family benefits
  • Versatile non-isolated DEXAL LED driver up to 75 W due to flexible output characteristic
  • Integrated DEXAL Bus power supply for sensors and wireless radios
  • Simplified luminaire design for wireless lighting control system and sensors
  • Locking and unlocking of luminaire/driver data
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • Prepared for DiiA Specification Parts -250, -251, -252 and -253
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Very high efficiency
  • Protection against 4 kV burst and 1.5 kV surge voltage (L-N)
  • Wide operating range up to 600 mA
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • DEXAL, easy connection to different partner BMS systems
  • Suitable for "Works with OSRAM DEXAL" partner components
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, DEXAL, Corridor, Touch DIM
Programming interface: DEXAL, NFC, LEDset
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, BIS, RCM
4052899590380Non isolated4…38 W54…240 V75…400 mA
OTI DX 75/220-240/600 D NFC L 🛈
Product family benefits
  • Versatile non-isolated DEXAL LED driver up to 75 W due to flexible output characteristic
  • Integrated DEXAL Bus power supply for sensors and wireless radios
  • Simplified luminaire design for wireless lighting control system and sensors
  • Locking and unlocking of luminaire/driver data
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • Prepared for DiiA Specification Parts -250, -251, -252 and -253
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Very high efficiency
  • Protection against 4 kV burst and 1.5 kV surge voltage (L-N)
  • Wide operating range up to 600 mA
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • DEXAL, easy connection to different partner BMS systems
  • Suitable for "Works with OSRAM DEXAL" partner components
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, DEXAL, Corridor, Touch DIM
Programming interface: DEXAL, NFC, LEDset
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, BIS, RCM
4052899590403Non isolated6.5…75 W54…240 V120…600 mA
OTI DX 35/220-240/700 NFC L 🛈
Product family benefits
  • D4i certified SELV DX LED driver up to 80 W due to flexible output characteristic
  • Integrated DEXAL Bus power supply for sensors and wireless radios
  • Simplified luminaire design for wireless lighting control system and sensors
  • Locking and unlocking of luminaire/driver data
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • Following DiiA Specification Parts -250, -251, -252 and -253
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Very high efficiency
  • Wide operating range up to 2100 mA
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • DEXAL, easy connection to different partner BMS systems
  • Suitable for "Works with OSRAM DEXAL" partner components
  • Suitable for luminaires of protection class I
Dimming interface: DALI, Corridor, Touch DIM
Programming interface: DEXAL, NFC
Programming device: DALI magic, NFC Scanner

Type of protection
NONE		Certificates & Approbations
CE, EL, ENEC, CCC, BIS, RCM
4062172372893SELV4…37 W15…54 V200…1050 mA
OTI DX 50/220-240/1A4 NFC L 🛈
Product family benefits
  • D4i certified SELV DX LED driver up to 80 W due to flexible output characteristic
  • Integrated DEXAL Bus power supply for sensors and wireless radios
  • Simplified luminaire design for wireless lighting control system and sensors
  • Locking and unlocking of luminaire/driver data
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • Following DiiA Specification Parts -250, -251, -252 and -253
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Very high efficiency
  • Wide operating range up to 2100 mA
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • DEXAL, easy connection to different partner BMS systems
  • Suitable for "Works with OSRAM DEXAL" partner components
  • Suitable for luminaires of protection class I
Dimming interface: DALI, Corridor, Touch DIM
Programming interface: DEXAL, NFC
Programming device: DALI magic, NFC Scanner

Type of protection
NONE		Certificates & Approbations
CE, EL, ENEC, CCC, BIS, RCM
4062172372916SELV12…54 W15…54 V400…1400 mA
OTI DX 80/220-240/2A1 NFC L 🛈
Product family benefits
  • D4i certified SELV DX LED driver up to 80 W due to flexible output characteristic
  • Integrated DEXAL Bus power supply for sensors and wireless radios
  • Simplified luminaire design for wireless lighting control system and sensors
  • Locking and unlocking of luminaire/driver data
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • Following DiiA Specification Parts -250, -251, -252 and -253
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Very high efficiency
  • Wide operating range up to 2100 mA
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • DEXAL, easy connection to different partner BMS systems
  • Suitable for "Works with OSRAM DEXAL" partner components
  • Suitable for luminaires of protection class I
Dimming interface: DALI, Corridor, Touch DIM
Programming interface: DEXAL, NFC
Programming device: DALI magic, NFC Scanner

Type of protection
NONE		Certificates & Approbations
CE, EL, ENEC, CCC, BIS, RCM
4062172372930SELV32…80 W15…54 V600…2100 mA
ETI DALI
ETi DALI 25/220-240/500 LT2 L 🛈
Product family benefits
  • Versatile SELV DALI driver up to 75 W due to flexible output characteristic
  • Fully programmable via software (DALI Interface)
  • Flexible current setting (RSet)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 10…100 % by amplitude dimming
  • No TouchDIM nor Corridor Function
  • High quality of light thanks to 3% output ripple current
  • High efficiency
  • Low standby consumption ≤ 0.5 W
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear and area lighting
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J, except those used in high-risk task areas, i.e. those systems must not be used in workplaces where operators and other occupants of the premises are involved in potentially dangerous processes or situations.
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2
Programming interface: Rset
Programming device: DALI magic

Type of protection
IP20		Certificates & Approbations
CE, ENEC 05, EL, EAC, CCC, BIS, RCM
4062172126212SELV3.6…25.5 W20…51 V180…500 mA
ETi DALI 35/220-240/700 LT2 L 🛈
Product family benefits
  • Versatile SELV DALI driver up to 75 W due to flexible output characteristic
  • Fully programmable via software (DALI Interface)
  • Flexible current setting (RSet)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 10…100 % by amplitude dimming
  • No TouchDIM nor Corridor Function
  • High quality of light thanks to 3% output ripple current
  • High efficiency
  • Low standby consumption ≤ 0.5 W
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear and area lighting
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J, except those used in high-risk task areas, i.e. those systems must not be used in workplaces where operators and other occupants of the premises are involved in potentially dangerous processes or situations.
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2
Programming interface: Rset
Programming device: DALI magic

Type of protection
IP20		Certificates & Approbations
CE, ENEC 05, EL, EAC, CCC, BIS, RCM
4062172126236SELV7.0…35.7 W20…51 V350…700 mA
ETi DALI 75/220-240/1A4 LT2 L 🛈
Product family benefits
  • Versatile SELV DALI driver up to 75 W due to flexible output characteristic
  • Fully programmable via software (DALI Interface)
  • Flexible current setting (RSet)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 10…100 % by amplitude dimming
  • No TouchDIM nor Corridor Function
  • High quality of light thanks to 3% output ripple current
  • High efficiency
  • Low standby consumption ≤ 0.5 W
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear and area lighting
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J, except those used in high-risk task areas, i.e. those systems must not be used in workplaces where operators and other occupants of the premises are involved in potentially dangerous processes or situations.
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2
Programming interface: Rset
Programming device: DALI magic

Type of protection
IP20		Certificates & Approbations
CE, ENEC 05, EL, EAC, CCC, BIS, RCM
4062172126250SELV12.0…71.4 W20…51 V600…1400 mA
OT NFC Wireless Intelligent
OT WI 35/220-240/400 D NFC BL L 🛈
Product family benefits
  • Versatile QBM window driver up to 100 W and 750 mA
  • Fully programmable via software (NFC)
  • Very high efficiency
  • High-quality dimming of 1…100 % (amplitude and/or PWM selectable by software)
  • Higher quality of light thanks to 1% output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor non-isolated installations
  • Suitable for luminaires of protection class I
Dimming interface: Qualified Bluetooth mesh, Corridor, Touch DIM
Programming interface: NFC
Programming device: FEIG, NFC Programmer

Type of protection
IP20		Certificates & Approbations
CE, VDE-ENEC, RCM, CCC, BIS, EL
4062172267373Non isolated4…38 W54…240 V75…400 mA
OT WI 75/220-240/550 D NFC BL L 🛈
Product family benefits
  • Versatile QBM window driver up to 100 W and 750 mA
  • Fully programmable via software (NFC)
  • Very high efficiency
  • High-quality dimming of 1…100 % (amplitude and/or PWM selectable by software)
  • Higher quality of light thanks to 1% output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor non-isolated installations
  • Suitable for luminaires of protection class I
Dimming interface: Qualified Bluetooth mesh, Corridor, Touch DIM
Programming interface: NFC
Programming device: FEIG, NFC Programmer

Type of protection
IP20		Certificates & Approbations
CE, VDE-ENEC, RCM, CCC, BIS, EL
4062172267397Non isolated6.5…75 W54…240 V125…550 mA
OT WI 100/220-240/750 D NFC BL L 🛈
Product family benefits
  • Versatile QBM window driver up to 100 W and 750 mA
  • Fully programmable via software (NFC)
  • Very high efficiency
  • High-quality dimming of 1…100 % (amplitude and/or PWM selectable by software)
  • Higher quality of light thanks to 1% output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor non-isolated installations
  • Suitable for luminaires of protection class I
Dimming interface: Qualified Bluetooth mesh, Corridor, Touch DIM
Programming interface: NFC
Programming device: FEIG, NFC Programmer

Type of protection
IP20		Certificates & Approbations
CE, VDE-ENEC, RCM, CCC, BIS, EL
4062172267410Non isolated5.4…100 W54…260 V100…750 mA
OT WI 35/220-240/400 D NFC CA L 🛈
Product family benefits
  • Versatile Casambi window driver up to 100 W and 750 mA
  • Fully programmable via software (NFC)
  • Very high efficiency
  • High-quality dimming of 1…100 % (amplitude and/or PWM selectable by software)
  • Higher quality of light thanks to 1% output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor non-isolated installations
  • Suitable for luminaires of protection class I
Dimming interface: Bluetooth CASAMBI
Programming interface: NFC
Programming device: FEIG, NFC Programmer

Type of protection
IP20		Certificates & Approbations
CE, VDE-ENEC, RCM, CCC, BIS, EL
4062172267434Non isolated4…38 W54…240 V75…400 mA
OT WI 75/220-240/550 D NFC CA L 🛈
Product family benefits
  • Versatile Casambi window driver up to 100 W and 750 mA
  • Fully programmable via software (NFC)
  • Very high efficiency
  • High-quality dimming of 1…100 % (amplitude and/or PWM selectable by software)
  • Higher quality of light thanks to 1% output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor non-isolated installations
  • Suitable for luminaires of protection class I
Dimming interface: Bluetooth CASAMBI
Programming interface: NFC
Programming device: FEIG, NFC Programmer

Type of protection
IP20		Certificates & Approbations
CE, VDE-ENEC, RCM, CCC, BIS, EL
4062172267458Non isolated6.5…75 W54…240 V125…550 mA
OT WI 100/220-240/750 D NFC CA L 🛈
Product family benefits
  • Versatile Casambi window driver up to 100 W and 750 mA
  • Fully programmable via software (NFC)
  • Very high efficiency
  • High-quality dimming of 1…100 % (amplitude and/or PWM selectable by software)
  • Higher quality of light thanks to 1% output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor non-isolated installations
  • Suitable for luminaires of protection class I
Dimming interface: Bluetooth CASAMBI
Programming interface: NFC
Programming device: FEIG, NFC Programmer

Type of protection
IP20		Certificates & Approbations
CE, VDE-ENEC, RCM, CCC, BIS, EL
4062172267472Non isolated5.4…100 W54…260 V100…750 mA
OT WI 35/220-240/1A0 NFC CA L 🛈
Product family benefits
  • Versatile Casambi window driver up to 80 W and 750 mA
  • Fully programmable via software (NFC)
  • Very high efficiency
  • High-quality dimming of 1…100 %
  • Higher quality of light thanks to 1% output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, hospitality and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I
Dimming interface: Bluetooth CASAMBI
Programming interface: NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, EL, RCM, ENEC
4062172311182SELV4…37 W20…54 V200…1050 mA
OT WI 35/220-240/1A0 NFC BL L 🛈
Product family benefits
  • Versatile QBM window driver up to 80 W and 750 mA
  • Fully programmable via software (NFC)
  • Very high efficiency
  • High-quality dimming of 1…100 %
  • Higher quality of light thanks to 1% output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, hospitality and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I
Dimming interface: Qualified Bluetooth mesh, Corridor, Touch DIM
Programming interface: NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, EL, RCM, ENEC
4062172311205SELV4…37 W20…54 V200…1050 mA
OT WI 50/220-240/1A4 NFC CA L 🛈
Product family benefits
  • Versatile Casambi window driver up to 80 W and 750 mA
  • Fully programmable via software (NFC)
  • Very high efficiency
  • High-quality dimming of 1…100 %
  • Higher quality of light thanks to 1% output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, hospitality and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I
Dimming interface: Bluetooth CASAMBI
Programming interface: NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, EL, RCM, ENEC
4062172311229SELV15…54 W20…54 V400…1400 mA
OT WI 50/220-240/1A4 NFC BL L 🛈
Product family benefits
  • Versatile QBM window driver up to 80 W and 750 mA
  • Fully programmable via software (NFC)
  • Very high efficiency
  • High-quality dimming of 1…100 %
  • Higher quality of light thanks to 1% output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, hospitality and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I
Dimming interface: Qualified Bluetooth mesh, Corridor, Touch DIM
Programming interface: NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, EL, RCM, ENEC
4062172311243SELV15…54 W20…54 V400…1400 mA
OT WI 80/220-240/2A1 NFC CA L 🛈
Product family benefits
  • Versatile Casambi window driver up to 80 W and 750 mA
  • Fully programmable via software (NFC)
  • Very high efficiency
  • High-quality dimming of 1…100 %
  • Higher quality of light thanks to 1% output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, hospitality and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I
Dimming interface: Bluetooth CASAMBI
Programming interface: NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, EL, RCM, ENEC
4062172311267SELV32…80 W20…54 V600…2100 mA
OT WI 80/220-240/2A1 NFC BL L 🛈
Product family benefits
  • Versatile QBM window driver up to 80 W and 750 mA
  • Fully programmable via software (NFC)
  • Very high efficiency
  • High-quality dimming of 1…100 %
  • Higher quality of light thanks to 1% output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, hospitality and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I
Dimming interface: Qualified Bluetooth mesh, Corridor, Touch DIM
Programming interface: NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, EL, RCM, ENEC
4062172311281SELV32…80 W20…54 V600…2100 mA
OTI DALI
OTi DALI 80/220-240/2A1 LT2 L 🛈
Product family benefits
  • Fully programmable via software (DALI Interface)
  • Flexible current setting (LEDset2)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming (except 80 W versions)
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Very low standby power consumption: 0.15 W *
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
Areas of applicationion
  • Linear lighting for office, education, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor
Programming interface: DALI, LEDset
Programming device: DALI magic

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, RCM
4052899028050SELV32…80 W20…54 V1000…2100 mA
OTi DALI 80/220-240/1A6 LT2 L 🛈
Product family benefits
  • Fully programmable via software (DALI Interface)
  • Flexible current setting (LEDset2)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming (except 80 W versions)
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Very low standby power consumption: 0.15 W *
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
Areas of applicationion
  • Linear lighting for office, education, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, LEDset
Programming device: DALI magic

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, RCM
4052899028074SELV32…80 W20…54 V600…1550 mA
OTi DALI 60/220-240/550 D LT2 L 🛈
Product family benefits
  • Fully programmable via software (DALI Interface)
  • Flexible current setting (LEDset2)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming (except 80 W versions)
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Very low standby power consumption: 0.25 W
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, LEDset
Programming device: DALI magic

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, BIS, RCM
4052899494206Non isolated6.4…60 W54…240 V120…550 mA
OTi DALI 35/220-240/400 D LT2 L 🛈
Product family benefits
  • Fully programmable via software (DALI Interface)
  • Flexible current setting (LEDset2)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming (except 80 W versions)
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Very low standby power consumption: 0.25 W
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, LEDset
Programming device: DALI magic

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, BIS, RCM
4052899494220Non isolated4…37 W54…240 V75…400 mA
OTi DALI 90/220-240/700 D LT2 L 🛈
Product family benefits
  • Fully programmable via software (DALI Interface)
  • Flexible current setting (LEDset2)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming (except 80 W versions)
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Very low standby power consumption: 0.25 W
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, LEDset
Programming device: DALI magic

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, BIS, RCM
4052899494244Non isolated13.5…90 W54…240 V250…700 mA
OTi DALI 90/220-240/1A0 LT2 L 🛈
Product family benefits
  • Fully programmable via software (DALI Interface)
  • Flexible current setting (LEDset2)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming (except 80 W versions)
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Very low standby power consumption: 0.25 W
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, LEDset
Programming device: DALI magic

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, BIS, RCM
4052899494268Non isolated13.5…90 W54…240 V250…1000 mA
OTI DALI G2
OTi DALI 35/220-240/700 LT2 L G2 🛈
Product family benefits
  • Fully programmable via software (DALI Interface)
  • Flexible current setting (LEDset2)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming (except 80 W versions)
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Very low standby power consumption: 0.15 W *
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
Areas of applicationion
  • Linear lighting for office, education, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, LEDset
Programming device: DALI magic

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, RCM, BIS
4052899551763SELV4…37 W15…54 V200…700 mA
OTi DALI 50/220-240/1A4 LT2 L G2 🛈
Product family benefits
  • Fully programmable via software (DALI Interface)
  • Flexible current setting (LEDset2)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming (except 80 W versions)
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Very low standby power consumption: 0.15 W *
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
Areas of applicationion
  • Linear lighting for office, education, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, LEDset
Programming device: DALI magic

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, RCM, BIS
4052899551787SELV12…50 W15…54 V600…1400 mA
OTI DALI Industry NFC
OTi DALI 100/220-240/700 D NFC IND L 🛈
Product family benefits
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 75 °C, max. 10 % failure rate)
  • High light quality: 1…100% amplitude dimming and 1% output ripple current
  • Wide operating temperature range: -40…+65 °C
  • High surge protection: up to 4 kV (L-N) / 4 kV (L/N-PE)
  • Integrated inrush current limiter
  • Very high efficiency (up to 96%)
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
Areas of applicationion
  • Linear lighting solutions for industry, storage areas and retail applications
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC, LEDset
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, RCM, BIS
4052899559516Non isolated28…100 W64…300 V200…700 mA
OTi DALI 150/220-240/1A0 D NFC IND L 🛈
Product family benefits
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 75 °C, max. 10 % failure rate)
  • High light quality: 1…100% amplitude dimming and 1% output ripple current
  • Wide operating temperature range: -40…+65 °C
  • High surge protection: up to 4 kV (L-N) / 4 kV (L/N-PE)
  • Integrated inrush current limiter
  • Very high efficiency (up to 96%)
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
Areas of applicationion
  • Linear lighting solutions for industry, storage areas and retail applications
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC, LEDset
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, RCM, BIS
4052899559530Non isolated43…150 W64…300 V250…1000 mA
OTi DALI 75/220-240/550 D NFC IND L 🛈
Product family benefits
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 75 °C, max. 10 % failure rate)
  • High light quality: 1…100% amplitude dimming and 1% output ripple current
  • Wide operating temperature range: -40…+65 °C
  • High surge protection: up to 4 kV (L-N) / 4 kV (L/N-PE)
  • Integrated inrush current limiter
  • Very high efficiency (up to 96%)
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
Areas of applicationion
  • Linear lighting solutions for industry, storage areas and retail applications
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC, LEDset
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, RCM, BIS
4062172139670Non isolated8.0…75 W64…300 V125…550 mA
OTi DALI 300/220-240/1A6 D NFC IND L 🛈
Product family benefits
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 75 °C, max. 10 % failure rate)
  • High light quality: 1…100% amplitude dimming and 1% output ripple current
  • Wide operating temperature range: -40…+65 °C
  • High surge protection: up to 4 kV (L-N) / 4 kV (L/N-PE)
  • Integrated inrush current limiter
  • Very high efficiency (up to 96%)
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
Areas of applicationion
  • Linear lighting solutions for industry, storage areas and retail applications
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
Dimming interface: DALI, Corridor, Touch DIM
Programming interface: DALI, NFC, LEDset
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, RCM, BIS
4062172186155Non isolated80…300 W60…300 V250…1550 mA
OTi DALI 150/220-240/700 D NFC IND L 🛈
Product family benefits
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 75 °C, max. 10 % failure rate)
  • High light quality: 1…100% amplitude dimming and 1% output ripple current
  • Wide operating temperature range: -40…+65 °C
  • High surge protection: up to 4 kV (L-N) / 4 kV (L/N-PE)
  • Integrated inrush current limiter
  • Very high efficiency (up to 96%)
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
Areas of applicationion
  • Linear lighting solutions for industry, storage areas and retail applications
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, CCC, RCM, BIS, ENEC
4062172290180Non isolated43…150 W64…260 V200…700 mA
OTI DALI NFC
OTi DALI 25/220-240/300 D NFC F L 🛈
Product family benefits
  • Flat housing (16 mm height) for innovative luminaire designs and applications
  • Fully programmable via software (DALI Interface, NFC)
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • Prepared for DiiA Specification Parts -251, -252 and -253
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % (amplitude and/or PWM selectable by software)
  • Higher quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, RCM, BIS
4062172020749Non isolated2.7…25 W54…240 V35…300 mA
OTi DALI 35/220-240/400 D NFC F L 🛈
Product family benefits
  • Flat housing (16 mm height) for innovative luminaire designs and applications
  • Fully programmable via software (DALI Interface, NFC)
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • Prepared for DiiA Specification Parts -251, -252 and -253
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % (amplitude and/or PWM selectable by software)
  • Higher quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, RCM, BIS
4062172020763Non isolated4…38 W54…240 V75…400 mA
OTi DALI 75/220-240/500 D NFC F L 🛈
Product family benefits
  • Flat housing (16 mm height) for innovative luminaire designs and applications
  • Fully programmable via software (DALI Interface, NFC)
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • Prepared for DiiA Specification Parts -251, -252 and -253
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % (amplitude and/or PWM selectable by software)
  • Higher quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, RCM, BIS
4062172020787Non isolated6.5…75 W54…240 V120…500 mA
OTi DALI 25/220-240/700 NFC L 🛈
Product family benefits
  • Fully programmable via software (DALI Interface, NFC)
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • DALI-2 certified incl. Parts 251, 252, 253
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming
  • Higher quality of light thanks to 3% output ripple current
  • Very high efficiency
  • Very low standby power consumption: 0.15 W *
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, BIS, RCM
4062172074940SELV2…28 W15…54 V100…700 mA
OTi DALI 35/220-240/1A0 NFC L 🛈
Product family benefits
  • Fully programmable via software (DALI Interface, NFC)
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • DALI-2 certified incl. Parts 251, 252, 253
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming
  • Higher quality of light thanks to 3% output ripple current
  • Very high efficiency
  • Very low standby power consumption: 0.15 W *
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, BIS, RCM
4062172074964SELV4…37 W15…54 V200…1050 mA
OTi DALI 50/220-240/1A4 NFC L 🛈
Product family benefits
  • Fully programmable via software (DALI Interface, NFC)
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • DALI-2 certified incl. Parts 251, 252, 253
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming
  • Higher quality of light thanks to 3% output ripple current
  • Very high efficiency
  • Very low standby power consumption: 0.15 W *
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, BIS, RCM
4062172074988SELV12…54 W15…54 V400…1400 mA
OTi DALI 100/220-240/750 D NFC L 🛈
Product family benefits
  • Fully programmable via software (DALI Interface)
  • Flexible current setting (LEDset2)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming (except 80 W versions)
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Very low standby power consumption: 0.25 W
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, BIS, RCM
4062172125116Non isolated5.4…100 W54…260 V100…750 mA
OTi DALI 80/220-240/2A1 NFC L 🛈
Product family benefits
  • Fully programmable via software (DALI Interface, NFC)
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • DALI-2 certified incl. Parts 251, 252, 253
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming
  • Higher quality of light thanks to 3% output ripple current
  • Very high efficiency
  • Very low standby power consumption: 0.15 W *
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, BIS, RCM
4062172238656SELV32…80 W20…54 V600…2100 mA
OTI DALI NFC TunableWhite
OTi DALI 35/220-240/400 D NFC TW L 🛈
Product family benefits
  • Control of standard white or Tunable White light acc. DALI device type 8 (DT8)*
  • TouchDIM Tunable White integrated for use without additional LMS
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % (amplitude and/or PWM selectable by software)
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
Areas of applicationion
  • For Tunable White as well as for 2-channel use (e.g. direct/indirect lighting)
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
  • Perfect system match with PrevaLED Linear Tunable White
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, RCM, BIS
4052899990302Non isolated4…38 W45…240 V75…400 mA
OTi DALI 75/220-240/700 D NFC TW L 🛈
Product family benefits
  • Control of standard white or Tunable White light acc. DALI device type 8 (DT8)*
  • TouchDIM Tunable White integrated for use without additional LMS
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % (amplitude and/or PWM selectable by software)
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
Areas of applicationion
  • For Tunable White as well as for 2-channel use (e.g. direct/indirect lighting)
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
  • Perfect system match with PrevaLED Linear Tunable White
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, RCM, BIS
4052899990326Non isolated8.1…75 W50…240 V150…700 mA
OTi DALI 35/220-240/700 NFC TW L 🛈
Product family benefits
  • Control of standard white or Tunable White light acc. DALI device type 8 (DT8)
  • TouchDIM Tunable White integrated for use without additional LMS
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 %
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • For Tunable White as well as for 2-channel use (e.g. direct/indirect lighting)
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
  • Perfect system match with PrevaLED Linear Tunable White
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, RCM, BIS
4062172092968SELV4…38 W15…54 V200…700 mA
OTi DALI 75/220-240/1A4 NFC TW L 🛈
Product family benefits
  • Control of standard white or Tunable White light acc. DALI device type 8 (DT8)
  • TouchDIM Tunable White integrated for use without additional LMS
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 %
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • For Tunable White as well as for 2-channel use (e.g. direct/indirect lighting)
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • Suitable for luminaires of protection class I
  • Perfect system match with PrevaLED Linear Tunable White
Dimming interface: DALI-2, Corridor, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, EAC, CCC, RCM, BIS
4062172092982SELV8.0…75 W15…54 V400…1400 mA
OTI DALI Ultraflat
OTi DALI 35/220-240/400 D LT2 UF L 🛈
Product family benefits
  • Ultra-flat housing (11 mm height) for innovative luminaire designs and applications
  • LEDset interface for direct Ultraflat sensor connection (LS/PD LT2 LI UF sensor)
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC, LEDset
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, RCM, BIS
4052899957022Non isolated4…38 W54…240 V75…400 mA
OTi DALI 75/220-240/700 D LT2 UF L 🛈
Product family benefits
  • Ultra-flat housing (11 mm height) for innovative luminaire designs and applications
  • LEDset interface for direct Ultraflat sensor connection (LS/PD LT2 LI UF sensor)
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming
  • High quality of light thanks to 1% output ripple current
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
  • Luminaire information for easy maintenance
Areas of applicationion
  • Linear lighting for office, education, industry, storage areas and retail
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for luminaires of protection class I
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor
Programming interface: DALI, NFC, LEDset
Programming device: DALI magic, NFC Scanner

Type of protection
IP20		Certificates & Approbations
CE, EL, VDE-ENEC, VDE-EMC, EAC, CCC, RCM, BIS
4052899957046Non isolated9.7…75 W54…240 V150…700 mA
Linear / Area Constant Current – Dimmable | Dimmable
Dimmable
IT DIM 40/HF LS/PD KIT 🛈
Product family benefits
  • KIT including driver, HF Sensor and cabling
  • Non isolated system for energy saving applications
  • High quality light with very low ripple
  • Very high efficiency
  • Enable slim fixture design with flat 21 mm height metal housing
  • Long lasting and high reliability
Areas of applicationion
  • Linear and area lighting
  • Industrial, retail and parking garage lighting
Dimming interface: proprietary
Programming interface: -

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, RCM, ENEC
4062172360265Non isolated8…42 W40…120 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
IT DIM 60/HF LS/PD KIT 🛈
Product family benefits
  • KIT including driver, HF Sensor and cabling
  • Non isolated system for energy saving applications
  • High quality light with very low ripple
  • Very high efficiency
  • Enable slim fixture design with flat 21 mm height metal housing
  • Long lasting and high reliability
Areas of applicationion
  • Linear and area lighting
  • Industrial, retail and parking garage lighting
Dimming interface: proprietary
Programming interface: -

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, RCM, ENEC
4062172360289Non isolated18…61.3 W90…175 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
IT DIM 75/HF LS/PD KIT 🛈
Product family benefits
  • KIT including driver, HF Sensor and cabling
  • Non isolated system for energy saving applications
  • High quality light with very low ripple
  • Very high efficiency
  • Enable slim fixture design with flat 21 mm height metal housing
  • Long lasting and high reliability
Areas of applicationion
  • Linear and area lighting
  • Industrial, retail and parking garage lighting
Dimming interface: proprietary
Programming interface: -

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, RCM, ENEC
4062172360302Non isolated31.5…75.6 W90…216 VDipswitches
350 mA, 450 mA, 500 mA, 550 mA
Constant Current | Compact | Non-dimmable
ELEMENT
ELEMENT 6/220-240/150 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 42 W
  • Safety ensured by OSRAM (SELV)
  • Higher quality of light thanks to 5% output ripple current
  • High efficiency
  • High compatibility with COBs and discrete LEDS
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25, UKCA
4062172355438SELV3.6…6.3 W24…42 V150 mA
ELEMENT 8/220-240/200 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 42 W
  • Safety ensured by OSRAM (SELV)
  • Higher quality of light thanks to 5% output ripple current
  • High efficiency
  • High compatibility with COBs and discrete LEDS
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25, UKCA
4062172355452SELV4.8…8.4 W24…42 V200 mA
ELEMENT 10/220-240/250 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 42 W
  • Safety ensured by OSRAM (SELV)
  • Higher quality of light thanks to 5% output ripple current
  • High efficiency
  • High compatibility with COBs and discrete LEDS
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25, UKCA
4062172355476SELV6…10.5 W24…42 V250 mA
ELEMENT 12/220-240/300 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 42 W
  • Safety ensured by OSRAM (SELV)
  • Higher quality of light thanks to 5% output ripple current
  • High efficiency
  • High compatibility with COBs and discrete LEDS
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25, UKCA
4062172355490SELV7.2…12.6 W24…42 V300 mA
ELEMENT 15/220-240/350 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 42 W
  • Safety ensured by OSRAM (SELV)
  • Higher quality of light thanks to 5% output ripple current
  • High efficiency
  • High compatibility with COBs and discrete LEDS
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25, UKCA
4062172355513SELV8.4…14.7 W24…42 V350 mA
ELEMENT 20/220-240/500 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 42 W
  • Safety ensured by OSRAM (SELV)
  • Higher quality of light thanks to 5% output ripple current
  • High efficiency
  • High compatibility with COBs and discrete LEDS
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25, UKCA
4062172355537SELV10.5…20 W21…40 V500 mA
ELEMENT 25/220-240/600 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 42 W
  • Safety ensured by OSRAM (SELV)
  • Higher quality of light thanks to 5% output ripple current
  • High efficiency
  • High compatibility with COBs and discrete LEDS
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25, UKCA
4062172355551SELV12.6…24 W21…40 V600 mA
ELEMENT 30/220-240/700 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 42 W
  • Safety ensured by OSRAM (SELV)
  • Higher quality of light thanks to 5% output ripple current
  • High efficiency
  • High compatibility with COBs and discrete LEDS
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25, UKCA
4062172355575SELV14.7…28 W21…40 V700 mA
ELEMENT 33/220-240/800 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 42 W
  • Safety ensured by OSRAM (SELV)
  • Higher quality of light thanks to 5% output ripple current
  • High efficiency
  • High compatibility with COBs and discrete LEDS
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25, UKCA
4062172355599SELV16.8…32 W21…40 V800 mA
ELEMENT 35/220-240/900 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 42 W
  • Safety ensured by OSRAM (SELV)
  • Higher quality of light thanks to 5% output ripple current
  • High efficiency
  • High compatibility with COBs and discrete LEDS
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25, UKCA
4062172355612SELV18.9…36 W21…40 V900 mA
ELEMENT 38/220-240/950 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 42 W
  • Safety ensured by OSRAM (SELV)
  • Higher quality of light thanks to 5% output ripple current
  • High efficiency
  • High compatibility with COBs and discrete LEDS
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25, UKCA
4062172355636SELV20…38 W21…40 V950 mA
ELEMENT 42/220-240/1050 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 42 W
  • Safety ensured by OSRAM (SELV)
  • Higher quality of light thanks to 5% output ripple current
  • High efficiency
  • High compatibility with COBs and discrete LEDS
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25, UKCA
4062172355650SELV22…42 W21…40 V1050 mA
ELEMENT G3
ELEMENT 12/220-240/300 G3 PHASE OUT🛈
Product family benefits
  • Safety ensured by OSRAM (SELV)
  • 3 years guarantee
  • High quality of light with ripple current 5%
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25
4062172167451SELV7.2…12.6 W24…42 V300 mA
ELEMENT 25/220-240/600 G3 PHASE OUT🛈
Product family benefits
  • Safety ensured by OSRAM (SELV)
  • 3 years guarantee
  • High quality of light with ripple current 5%
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25
4062172167512SELV12.6…24 W21…40 V600 mA
ELEMENT 28/220-240/700 G3 PHASE OUT🛈
Product family benefits
  • Safety ensured by OSRAM (SELV)
  • 3 years guarantee
  • High quality of light with ripple current 5%
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25
4062172167536SELV14.7…28 W21…40 V700 mA
ELEMENT 33/220-240/800 G3 PHASE OUT🛈
Product family benefits
  • Safety ensured by OSRAM (SELV)
  • 3 years guarantee
  • High quality of light with ripple current 5%
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25
4062172167550SELV16.8…32 W21…40 V800 mA
ELEMENT 38/220-240/950 G3 PHASE OUT🛈
Product family benefits
  • Safety ensured by OSRAM (SELV)
  • 3 years guarantee
  • High quality of light with ripple current 5%
Areas of applicationion
  • Spot light and down light
  • Panels
  • Other Indoor LED luminaries

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, ENEC 25
4062172167598SELV20…38 W21…40 V950 mA
IT FIT Dipswitch
IT FIT 60/220-240/1A4 CS 🛈
Product family benefits
  • Higher quality of light thanks to low output ripple current
  • High flexibility due to four different output currents
  • Small housing for flexible luminaire designs
  • High efficiency
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for luminaires of protection classes I and II
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
ENEC 05, CCC, RCM, CE
4062172306072SELV22.3…60 W27…57 V, 27…52 V, 27…48 V, 27…43 V, 27…40 VDipswitches
825 mA, 900 mA, 975 mA, 1050 mA, 1000 mA, 1200 mA, 1300 mA, 1400 mA
IT FIT 20/220-240/500 CS 🛈
Product family benefits
  • Higher quality of light thanks to low output ripple current
  • High flexibility due to eight different output currents
  • Small housing for flexible luminaire designs
  • High efficiency
  • Long lasting and high reliability
  • Safety ensured by OSRAM (SELV)
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations
  • Installation and independent mounting via Cable Clamp Kit possible
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, UKCA, ENEC 25
4062172326346SELV3.45…21 W23…42 VDipswitches
150 mA, 200 mA, 250 mA, 300 mA, 350 mA, 400 mA, 450 mA, 500 mA
IT FIT 30/220-240/700 CS 🛈
Product family benefits
  • Higher quality of light thanks to low output ripple current
  • High flexibility due to eight different output currents
  • Small housing for flexible luminaire designs
  • High efficiency
  • Long lasting and high reliability
  • Safety ensured by OSRAM (SELV)
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations
  • Installation and independent mounting via Cable Clamp Kit possible
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, UKCA, ENEC 25
4062172326360SELV8.05…29.4 W23…42 VDipswitches
350 mA, 400 mA, 450 mA, 500 mA, 550 mA, 600 mA, 650 mA, 700 mA
IT FIT 40/220-240/1A0 CS 🛈
Product family benefits
  • Higher quality of light thanks to low output ripple current
  • High flexibility due to eight different output currents
  • Small housing for flexible luminaire designs
  • High efficiency
  • Long lasting and high reliability
  • Safety ensured by OSRAM (SELV)
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations
  • Installation and independent mounting via Cable Clamp Kit possible
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, UKCA, ENEC 25
4062172326384SELV16.1…44.1 W23…42 VDipswitches
700 mA, 750 mA, 800 mA, 850 mA, 900 mA, 950 mA, 1000 mA, 1050 mA
IT FIT Dipswitch Independent
IT FIT 4/220-240/400 CS I 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Flexible current selection via DIP switch
  • Reversible overtemperature, overload, short-circuit and open-circuit protection
Areas of applicationion
  • Extra small design for downlights, spotlights and other indoor luminaries
  • Suitable for luminaires of protection classes I and II
  • Suitable for indoor SELV installations
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
ENEC 05, CCC, CE, RCM
4062172199261SELV0.25…4 W2.5…10 VDipswitches
100 mA, 200 mA, 300 mA, 400 mA
IT FIT 7/220-240/700 CS I 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Flexible current selection via DIP switch
  • Reversible overtemperature, overload, short-circuit and open-circuit protection
Areas of applicationion
  • Extra small design for downlights, spotlights and other indoor luminaries
  • Suitable for luminaires of protection classes I and II
  • Suitable for indoor SELV installations
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
ENEC 05, CCC, CE, RCM
4062172199285SELV0.88…7.7 W2.5…11 VDipswitches
350 mA, 400 mA, 450 mA, 500 mA, 550 mA, 600 mA, 650 mA, 700 mA
IT FIT 11/220-240/500 CS I 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Flexible current selection via DIP switch
  • Reversible overtemperature, overload, short-circuit and open-circuit protection
Areas of applicationion
  • Extra small design for downlights, spotlights and other indoor luminaries
  • Suitable for luminaires of protection classes I and II
  • Suitable for indoor SELV installations
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
ENEC 05, CCC, CE, RCM
4062172199308SELV3.85…10.5 W11…21 VDipswitches
350 mA, 400 mA, 450 mA, 500 mA
IT FIT 15/220-240/700 CS I 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Flexible current selection via DIP switch
  • Reversible overtemperature, overload, short-circuit and open-circuit protection
Areas of applicationion
  • Extra small design for downlights, spotlights and other indoor luminaries
  • Suitable for luminaires of protection classes I and II
  • Suitable for indoor SELV installations
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
ENEC 05, CCC, CE, RCM
4062172199322SELV6.05…14.7 W11…21 VDipswitches
550 mA, 600 mA, 650 mA, 700 mA
IT FIT 20/220-240/500 CS I 🛈
Product family benefits
  • Higher quality of light thanks to low output ripple current
  • High flexibility due to eight different output currents
  • Small housing for flexible luminaire designs
  • High efficiency
  • Long lasting and high reliability
  • Safety ensured by OSRAM (SELV)
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations
  • Installation and independent mounting via Cable Clamp Kit possible
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, UKCA, ENEC 25
4062172326285SELV3.45…21 W23…42 VDipswitches
150 mA, 200 mA, 250 mA, 300 mA, 350 mA, 400 mA, 450 mA, 500 mA
IT FIT 30/220-240/700 CS I 🛈
Product family benefits
  • Higher quality of light thanks to low output ripple current
  • High flexibility due to eight different output currents
  • Small housing for flexible luminaire designs
  • High efficiency
  • Long lasting and high reliability
  • Safety ensured by OSRAM (SELV)
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations
  • Installation and independent mounting via Cable Clamp Kit possible
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, UKCA, ENEC 25
4062172326308SELV8.05…29.4 W23…42 VDipswitches
350 mA, 400 mA, 450 mA, 500 mA, 550 mA, 600 mA, 650 mA, 700 mA
IT FIT 40/220-240/1A0 CS I 🛈
Product family benefits
  • Higher quality of light thanks to low output ripple current
  • High flexibility due to eight different output currents
  • Small housing for flexible luminaire designs
  • High efficiency
  • Long lasting and high reliability
  • Safety ensured by OSRAM (SELV)
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for indoor SELV installations
  • Installation and independent mounting via Cable Clamp Kit possible
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, UKCA, ENEC 25
4062172326322SELV16.1…44.1 W23…42 VDipswitches
700 mA, 750 mA, 800 mA, 850 mA, 900 mA, 950 mA, 1000 mA, 1050 mA
IT FIT Dipswitch Track black
IT FIT 30/220-240/700 CS T-B 🛈
Product family benefits
  • Compact size for miniaturized track light luminaire design
  • High light quality due to low ripple current
  • Three colors available: White, Grey, Black
  • High flexibility due to eight different output currents
  • High efficiency (up to 90%)
Areas of applicationion
  • Shops
  • Retail outlets
  • Public buildings
  • Suitable for luminaires of protection class II
  • Suitable for three circuits system
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, RCM, CQC, UKCA
4062172379847SELV6.75…29.4 W27…42 VDipswitches
250 mA, 350 mA, 400 mA, 450 mA, 500 mA, 550 mA, 600 mA, 700 mA
IT FIT 40/220-240/1A0 CS T-B 🛈
Product family benefits
  • Compact size for miniaturized track light luminaire design
  • High light quality due to low ripple current
  • Three colors available: White, Grey, Black
  • High flexibility due to eight different output currents
  • High efficiency (up to 90%)
Areas of applicationion
  • Shops
  • Retail outlets
  • Public buildings
  • Suitable for luminaires of protection class II
  • Suitable for three circuits system
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, RCM, CQC, UKCA
4062172379908SELV18.9…44.1 W27…42 VDipswitches
700 mA, 750 mA, 800 mA, 850 mA, 900 mA, 950 mA, 1000 mA, 1050 mA
IT FIT Dipswitch Track grey
IT FIT 30/220-240/700 CS T-G 🛈
Product family benefits
  • Compact size for miniaturized track light luminaire design
  • High light quality due to low ripple current
  • Three colors available: White, Grey, Black
  • High flexibility due to eight different output currents
  • High efficiency (up to 90%)
Areas of applicationion
  • Shops
  • Retail outlets
  • Public buildings
  • Suitable for luminaires of protection class II
  • Suitable for three circuits system
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, RCM, CQC, UKCA
4062172379861SELV6.75…29.4 W27…42 VDipswitches
250 mA, 350 mA, 400 mA, 450 mA, 500 mA, 550 mA, 600 mA, 700 mA
IT FIT 40/220-240/1A0 CS T-G 🛈
Product family benefits
  • Compact size for miniaturized track light luminaire design
  • High light quality due to low ripple current
  • Three colors available: White, Grey, Black
  • High flexibility due to eight different output currents
  • High efficiency (up to 90%)
Areas of applicationion
  • Shops
  • Retail outlets
  • Public buildings
  • Suitable for luminaires of protection class II
  • Suitable for three circuits system
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, RCM, CQC, UKCA
4062172379922SELV18.9…44.1 W27…42 VDipswitches
700 mA, 750 mA, 800 mA, 850 mA, 900 mA, 950 mA, 1000 mA, 1050 mA
IT FIT Dipswitch Track white
IT FIT 30/220-240/700 CS T-W 🛈
Product family benefits
  • Compact size for miniaturized track light luminaire design
  • High light quality due to low ripple current
  • Three colors available: White, Grey, Black
  • High flexibility due to eight different output currents
  • High efficiency (up to 90%)
Areas of applicationion
  • Shops
  • Retail outlets
  • Public buildings
  • Suitable for luminaires of protection class II
  • Suitable for three circuits system
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, RCM, CQC, UKCA
4062172379885SELV6.75…29.4 W27…42 VDipswitches
250 mA, 350 mA, 400 mA, 450 mA, 500 mA, 550 mA, 600 mA, 700 mA
IT FIT 40/220-240/1A0 CS T-W 🛈
Product family benefits
  • Compact size for miniaturized track light luminaire design
  • High light quality due to low ripple current
  • Three colors available: White, Grey, Black
  • High flexibility due to eight different output currents
  • High efficiency (up to 90%)
Areas of applicationion
  • Shops
  • Retail outlets
  • Public buildings
  • Suitable for luminaires of protection class II
  • Suitable for three circuits system
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, RCM, CQC, UKCA
4062172379946SELV18.9…44.1 W27…42 VDipswitches
700 mA, 750 mA, 800 mA, 850 mA, 900 mA, 950 mA, 1000 mA, 1050 mA
OT FIT Dipswitch
OT FIT 30/220-240/700 CS PHASE OUT🛈
Product family benefits
  • Higher quality of light thanks to low output ripple current
  • High flexibility due to four different output currents
  • Small housing for flexible luminaire designs
  • High efficiency
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for luminaires of protection classes I and II
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CCC, CE, RCM, ENEC 05
4052899617322SELV11.5…29.4 W23…42 VDipswitches
500 mA, 600 mA, 650 mA, 700 mA
OT FIT 75/220-240/1A6 CS 🛈
Product family benefits
  • Higher quality of light thanks to low output ripple current
  • High flexibility due to four different output currents
  • Small housing for flexible luminaire designs
  • High efficiency
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for luminaires of protection classes I and II
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CCC, CE, RCM, ENEC 05
4052899999565SELV32.5…77 W27…57 V, 27…42 VDipswitches
1200 mA, 1350 mA, 1500 mA, 1650 mA
OT FIT Dipswitch Track black
OT FIT 40/220-240/1A0 CS T-B PHASE OUT🛈
Product family benefits
  • High quality of light thanks to low output ripple current
  • High flexibility due to four different output currents per type
  • Short housing for minimum distance between spotlights
  • SELV system
Areas of applicationion
  • Track lights
  • Shops and hospitality: retail, hotels, restaurants
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, EAC, CQC, RCM
4052899617254SELV23…44.1 W27…42 VDipswitches
850 mA, 900 mA, 950 mA, 1050 mA
OT FIT Dipswitch Track grey
OT FIT 20/220-240/500 CS T-G PHASE OUT🛈
Product family benefits
  • High quality of light thanks to low output ripple current
  • High flexibility due to four different output currents per type
  • Short housing for minimum distance between spotlights
  • SELV system
Areas of applicationion
  • Track lights
  • Shops and hospitality: retail, hotels, restaurants
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, CCC, ENEC, EAC, CQC
4062172131773SELV6.3…21 W25…42 VDipswitches
250 mA, 350 mA, 450 mA, 500 mA
OT FIT 40/220-240/1A0 CS T-G PHASE OUT🛈
Product family benefits
  • High quality of light thanks to low output ripple current
  • High flexibility due to four different output currents per type
  • Short housing for minimum distance between spotlights
  • SELV system
Areas of applicationion
  • Track lights
  • Shops and hospitality: retail, hotels, restaurants
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, EAC, CQC, RCM
4062172131858SELV23…44.1 W27…42 VDipswitches
850 mA, 900 mA, 950 mA, 1050 mA
OT FIT Dipswitch Track white
OT FIT 20/220-240/500 CS T-W PHASE OUT🛈
Product family benefits
  • High quality of light thanks to low output ripple current
  • High flexibility due to four different output currents per type
  • Short housing for minimum distance between spotlights
  • SELV system
Areas of applicationion
  • Track lights
  • Shops and hospitality: retail, hotels, restaurants
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, CCC, ENEC, EAC, CQC
4062172131759SELV6.3…21 W25…42 VDipswitches
250 mA, 350 mA, 450 mA, 500 mA
OT FIT 40/220-240/1A0 CS T-W PHASE OUT🛈
Product family benefits
  • High quality of light thanks to low output ripple current
  • High flexibility due to four different output currents per type
  • Short housing for minimum distance between spotlights
  • SELV system
Areas of applicationion
  • Track lights
  • Shops and hospitality: retail, hotels, restaurants
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, EAC, CQC, RCM
4062172131834SELV23…44.1 W27…42 VDipswitches
850 mA, 900 mA, 950 mA, 1050 mA
OT FIT Low Profile
OT FIT 15/220-240/500 LT2 LP PHASE OUT🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 40 W
  • Fulfill safety requirement due to overload, overtemperature protection
  • High efficiency
  • Higher quality of light thanks to 5% output ripple current
Areas of applicationion
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Luminaires with flexible current setting (LEDset2)
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
  • Suitable for downlights, spotlights and LED panels
  • Independent mounting via Cable Clamp Kit possible
Programming device: LEDset

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, CCC, EL, RCM, BIS, EAC
4052899490673SELV4.5…17.5 W15…50 V150…500 mA
OT FIT 25/220-240/700 LT2 LP PHASE OUT🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 40 W
  • Fulfill safety requirement due to overload, overtemperature protection
  • High efficiency
  • Higher quality of light thanks to 5% output ripple current
Areas of applicationion
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Luminaires with flexible current setting (LEDset2)
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
  • Suitable for downlights, spotlights and LED panels
  • Independent mounting via Cable Clamp Kit possible
Programming device: LEDset

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, CCC, EL, RCM, BIS, EAC
4052899490697SELV8.0…26.5 W15…50 V300…700 mA
OT FIT 40/220-240/1A0 LT2 LP PHASE OUT🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 40 W
  • Fulfill safety requirement due to overload, overtemperature protection
  • High efficiency
  • Higher quality of light thanks to 5% output ripple current
Areas of applicationion
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Luminaires with flexible current setting (LEDset2)
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
  • Suitable for downlights, spotlights and LED panels
  • Independent mounting via Cable Clamp Kit possible
Programming device: LEDset

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, CCC, EL, RCM, BIS, EAC
4052899490734SELV13…40 W15…50 V500…1050 mA
OT FIT Mini Dipswitch Independent
OT FIT 8/220-240/180 CS I MINI 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Higher quality of light thanks to 3% output ripple current
  • Operating temperature: up to 60 °C
  • User flexibility with four different output currents from one driver
  • Flexible current selection via DIP switch
  • Reversible overtemperature, overload, short-circuit and open-circuit protection
  • High efficiency (up to 90%)
Areas of applicationion
  • Extra small design for downlights, spotlights and other indoor luminaries
  • Suitable for luminaires of protection classes I and II
  • Suitable for indoor SELV installations
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
ENEC 05, CCC, CE, RCM
4052899587946SELV2.7…7.6 W30…42 VDipswitches
90 mA, 120 mA, 150 mA, 180 mA
OT FIT Mini Dipswitch Small built-in
OT FIT 8/220-240/180 CS S MINI 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Higher quality of light thanks to 3% output ripple current
  • Operating temperature: up to 60 °C
  • User flexibility with four different output currents from one driver
  • Flexible current selection via DIP switch
  • Reversible overtemperature, overload, short-circuit and open-circuit protection
  • High efficiency (up to 90%)
Areas of applicationion
  • Extra small design for downlights, spotlights and other indoor luminaries
  • Suitable for luminaires of protection classes I and II
  • Suitable for indoor SELV installations
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
ENEC 05, CCC, CE, UKCA, RCM, BIS
4052899587922SELV2.7…7.6 W30…42 VDipswitches
90 mA, 120 mA, 150 mA, 180 mA
OT FIT 20/220-240/500 CS S MINI 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Higher quality of light thanks to 3% output ripple current
  • Operating temperature: up to 60 °C
  • User flexibility with four different output currents from one driver
  • Flexible current selection via DIP switch
  • Reversible overtemperature, overload, short-circuit and open-circuit protection
  • High efficiency (up to 90%)
Areas of applicationion
  • Extra small design for downlights, spotlights and other indoor luminaries
  • Suitable for luminaires of protection classes I and II
  • Suitable for indoor SELV installations
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
ENEC 05, CCC, CE, RCM
4052899587960SELV12…21 W30…42 VDipswitches
400 mA, 450 mA, 475 mA, 500 mA
OT FIT 38/220-240/900 CS S MINI 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Higher quality of light thanks to 3% output ripple current
  • Operating temperature: up to 60 °C
  • User flexibility with four different output currents from one driver
  • Flexible current selection via DIP switch
  • Reversible overtemperature, overload, short-circuit and open-circuit protection
  • High efficiency (up to 90%)
Areas of applicationion
  • Extra small design for downlights, spotlights and other indoor luminaries
  • Suitable for luminaires of protection classes I and II
  • Suitable for indoor SELV installations
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
ENEC 05, CCC, CE, RCM
4052899587984SELV24…37.8 W30…42 VDipswitches
800 mA, 850 mA, 875 mA, 900 mA
OT FIT 15/220-240/350 CS S MINI 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Higher quality of light thanks to 3% output ripple current
  • Operating temperature: up to 60 °C
  • User flexibility with four different output currents from one driver
  • Flexible current selection via DIP switch
  • Reversible overtemperature, overload, short-circuit and open-circuit protection
  • High efficiency (up to 90%)
Areas of applicationion
  • Extra small design for downlights, spotlights and other indoor luminaries
  • Suitable for luminaires of protection classes I and II
  • Suitable for indoor SELV installations
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
ENEC 05, CCC, CE, RCM
4062172013406SELV6.7…14.7 W30…42 VDipswitches
225 mA, 250 mA, 325 mA, 350 mA
OT FIT 30/220-240/700 CS S MINI 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Higher quality of light thanks to 3% output ripple current
  • Operating temperature: up to 60 °C
  • User flexibility with four different output currents from one driver
  • Flexible current selection via DIP switch
  • Reversible overtemperature, overload, short-circuit and open-circuit protection
  • High efficiency (up to 90%)
Areas of applicationion
  • Extra small design for downlights, spotlights and other indoor luminaries
  • Suitable for luminaires of protection classes I and II
  • Suitable for indoor SELV installations
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
ENEC 05, CCC, CE, RCM
4062172013420SELV16.5…29 W30…42 VDipswitches
550 mA, 600 mA, 650 mA, 700 mA
OT FIT NFC
OT FIT 15/220-240/350 NFC PHASE OUT🛈
Product family benefits
  • Fast programming / current set via NFC
  • High quality of light thanks to low output ripple current
  • Small housing for flexible luminaire designs
  • High efficiency
Areas of applicationion
  • Spot light and down light
  • Offices
  • Shops
  • Hospitality
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, ENEC
4052899617179SELV2.7…14 W18…40 V150…350 mA
OT FIT 25/220-240/700 NFC PHASE OUT🛈
Product family benefits
  • Fast programming / current set via NFC
  • High quality of light thanks to low output ripple current
  • Small housing for flexible luminaire designs
  • High efficiency
Areas of applicationion
  • Spot light and down light
  • Offices
  • Shops
  • Hospitality
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, ENEC
4052899617186SELV6.3…28 W18…40 V350…700 mA
OT FIT 40/220-240/1A0 NFC PHASE OUT🛈
Product family benefits
  • Fast programming / current set via NFC
  • High quality of light thanks to low output ripple current
  • Small housing for flexible luminaire designs
  • High efficiency
Areas of applicationion
  • Spot light and down light
  • Offices
  • Shops
  • Hospitality
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, ENEC
4052899617193SELV12.6…42 W18…40 V700…1050 mA
OT FIT NFC G2
OT FIT 15/220-240/350 NFC G2 🛈
Product family benefits
  • Fast programming / current set via NFC
  • Higher quality of light thanks to low output ripple current
  • Small housing for flexible luminaire designs
  • High efficiency
Areas of applicationion
  • Spot light and down light
  • Offices
  • Shops
  • Hospitality
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, BIS, EL
6977078993463SELV2.25…15 W15…50 V150…350 mA
OT FIT 25/220-240/700 NFC G2 🛈
Product family benefits
  • Fast programming / current set via NFC
  • Higher quality of light thanks to low output ripple current
  • Small housing for flexible luminaire designs
  • High efficiency
Areas of applicationion
  • Spot light and down light
  • Offices
  • Shops
  • Hospitality
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, BIS, EL
6977078993487SELV4.5…25 W15…50 V300…700 mA
OT FIT 40/220-240/1A0 NFC G2 🛈
Product family benefits
  • Fast programming / current set via NFC
  • Higher quality of light thanks to low output ripple current
  • Small housing for flexible luminaire designs
  • High efficiency
Areas of applicationion
  • Spot light and down light
  • Offices
  • Shops
  • Hospitality
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, BIS, EL
6977078993500SELV7.5…40 W15…50 V500…1050 mA
Constant Current | Compact | Non-dimmable | Outdoor
OT P5
OT 50/120-277/700 P5 🛈
Product family benefits
  • High surge protection: up to 6 kV (L-N) / 6 kV (L/N-PE)
  • High efficiency
  • Great flexibility due to wide operating temperature range of -40…50 °C or 55 °C
  • IP rating: IP65
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for luminaires of protection class I

Type of protection
IP65		Certificates & Approbations
CE, CQC
4052899259003SELV50 W24…74 V700 mA
OT 180/120-277/700 P5 🛈
Product family benefits
  • High surge protection: up to 6 kV (L-N) / 6 kV (L/N-PE)
  • High efficiency
  • Great flexibility due to wide operating temperature range of -40…50 °C or 55 °C
  • IP rating: IP65
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for luminaires of protection class I

Type of protection
IP65		Certificates & Approbations
CE, CQC
4052899259027Basic180 W115…257 V700 mA
OT 100/120-277/700 P5 🛈
Product family benefits
  • High surge protection: up to 6 kV (L-N) / 6 kV (L/N-PE)
  • High efficiency
  • Great flexibility due to wide operating temperature range of -40…50 °C or 55 °C
  • IP rating: IP65
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for luminaires of protection class I

Type of protection
IP65		Certificates & Approbations
CE, CQC
4052899259065Double/reinforced100 W55…152 V700 mA
OT 100/220-240/4A2 P5 PHASE OUT🛈
Product family benefits
  • High surge protection: up to 6 kV
  • High efficiency
  • Adjustable and wide output current range
  • Constant current output
  • Protection through double isolation between primary and secondary side (SELV)
  • IP rating: IP65
  • Long lifetime: up to 100,000 h
Areas of applicationion
  • Independent installation
  • Street and urban lighting
  • Industry
  • Suitable for luminaires of protection class I

Type of protection
IP65		Certificates & Approbations
CCC, CE, CB
4052899410657Double/reinforced100 W24…48 V2100…4200 mA
OT 150/220-240/4A9 P5 PHASE OUT🛈
Product family benefits
  • High surge protection: up to 6 kV
  • High efficiency
  • Adjustable and wide output current range
  • Constant current output
  • Protection through double isolation between primary and secondary side (SELV)
  • IP rating: IP65
  • Long lifetime: up to 100,000 h
Areas of applicationion
  • Independent installation
  • Street and urban lighting
  • Industry
  • Suitable for luminaires of protection class I

Type of protection
IP65		Certificates & Approbations
CCC, CE, CB
4052899410671Double/reinforced150 W30…60 V2450…4900 mA
OT 200/220-240/5A6 P5 PHASE OUT🛈
Product family benefits
  • High surge protection: up to 6 kV
  • High efficiency
  • Adjustable and wide output current range
  • Constant current output
  • Protection through double isolation between primary and secondary side (SELV)
  • IP rating: IP65
  • Long lifetime: up to 100,000 h
Areas of applicationion
  • Independent installation
  • Street and urban lighting
  • Industry
  • Suitable for luminaires of protection class I

Type of protection
IP65		Certificates & Approbations
CCC, CE, CB
4052899410695Double/reinforced200 W35…70 V2800…5600 mA
Constant Current | Compact | Dimmable
DEXAL NFC
OTI DX 25/220-240/700 NFC 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Integrated DEXAL Bus power supply for sensors and wireless radios
  • Simplified luminaire design for wireless lighting control system and sensors
  • Locking and unlocking of luminaire/driver data
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • D4i certified incl. Parts 250, 251, 252, 253
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Versatile scope of application due to OSRAM DALI Technology:
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13,appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
Areas of applicationion
  • DEXAL, easy connection to different partner BMS systems
  • Suitable for "Works with OSRAM DEXAL" partner components
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for use in luminaires with flexible current setting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
  • Suitable for downlights, spotlights and LED panels
  • Installation via Cable Clamp Kit possible (depending on version of product)
Dimming interface: DALI-2, DEXAL, D4i
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
ENEC 10, VDE, EMC, EL, CE, DALI-2, CCC, EAC, D4i
4062172017947SELV27 W15…54 V180…700 mA
OTI DX 35/220-240/1A0 NFC 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Integrated DEXAL Bus power supply for sensors and wireless radios
  • Simplified luminaire design for wireless lighting control system and sensors
  • Locking and unlocking of luminaire/driver data
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • D4i certified incl. Parts 250, 251, 252, 253
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Versatile scope of application due to OSRAM DALI Technology:
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13,appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
Areas of applicationion
  • DEXAL, easy connection to different partner BMS systems
  • Suitable for "Works with OSRAM DEXAL" partner components
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for use in luminaires with flexible current setting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
  • Suitable for downlights, spotlights and LED panels
  • Installation via Cable Clamp Kit possible (depending on version of product)
Dimming interface: DALI-2, DEXAL, D4i
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
ENEC 10, VDE, EMC, EL, CE, DALI-2, CCC, EAC, D4i
4062172017961SELV35 W15…54 V350…1050 mA
OTI DX 50/220-240/1A4 NFC 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Integrated DEXAL Bus power supply for sensors and wireless radios
  • Simplified luminaire design for wireless lighting control system and sensors
  • Locking and unlocking of luminaire/driver data
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • D4i certified incl. Parts 250, 251, 252, 253
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Versatile scope of application due to OSRAM DALI Technology:
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13,appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
Areas of applicationion
  • DEXAL, easy connection to different partner BMS systems
  • Suitable for "Works with OSRAM DEXAL" partner components
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for use in luminaires with flexible current setting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
  • Suitable for downlights, spotlights and LED panels
  • Installation via Cable Clamp Kit possible (depending on version of product)
Dimming interface: DALI/DEXAL/D4i
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
ENEC 10, VDE, EMC, EL, CE, DALI-2, CCC, EAC, D4i
4062172061865SELV55 W15…54 V600…1400 mA
Dimmable Dipswitch Independent
IT DIM 12/220-240/300 CS I 🛈
Product family benefits
  • 1-100% dimming
  • Dim to off
  • Compact housing for mounting in very tight spaces
  • Flicker-free dimming
  • Higher quality of light thanks to 3% output ripple current
Areas of applicationion
  • Decorative illumination
  • Downlights, flat luminaires
  • Hospitality
  • Living areas
  • Museums, residential buildings
  • Offices
  • Shop lighting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I and II
Dimming interface: 0-10V
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, UKCA, CCC, RCM, ENEC
4062172321334SELV2.3…12.6 W23…42 VDipswitches
70 mA, 120 mA, 150 mA, 180 mA, 200 mA, 230 mA, 250 mA, 300 mA
IT DIM 20/220-240/500 CS I 🛈
Product family benefits
  • 1-100% dimming
  • Dim to off
  • Compact housing for mounting in very tight spaces
  • Flicker-free dimming
  • Higher quality of light thanks to 3% output ripple current
Areas of applicationion
  • Decorative illumination
  • Downlights, flat luminaires
  • Hospitality
  • Living areas
  • Museums, residential buildings
  • Offices
  • Shop lighting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I and II
Dimming interface: 0-10V
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, UKCA, CCC, RCM, ENEC
4062172321402SELV3.5…21 W23…42 VDipswitches
150 mA, 200 mA, 250 mA, 300 mA, 350 mA, 400 mA, 450 mA, 500 mA
Dimmable Dipswitch Independent Astro
IT DIM 40/220-240/1A0 CS I 🛈
Product family benefits
  • 1-100% dimming
  • Dim to off
  • Compact housing for mounting in very tight spaces
  • Flicker-free dimming
  • Higher quality of light thanks to 3% output ripple current
Areas of applicationion
  • Decorative illumination
  • Downlights, flat luminaires
  • Hospitality
  • Living areas
  • Museums, residential buildings
  • Offices
  • Shop lighting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I and II
Dimming interface: 0-10V
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, UKCA, CCC, RCM, ENEC
4062172321426SELV13.8…44.1 W23…42 VDipswitches
600 mA, 700 mA, 750 mA, 800 mA, 850 mA, 900 mA, 950 mA, 1050 mA
Dipswitch
IT DALI 30/220-240/700 CS 🛈
Product family benefits
  • Safety ensured by OSRAM (SELV)
  • DALI-2 certified
  • High flexibility due to eight different output currents
  • Touch DIM application: easy to control via pushbutton or sensor
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Higher quality of light thanks to low output ripple current
  • Small housing for flexible luminaire designs
  • Housing from 80% recycled plastic
Areas of applicationion
  • Offices
  • Shops
  • Hospitality
  • Panels, spotlight, downlight, and other indoor LED luminaires
  • Suitable for indoor SELV equivalent installations
  • Suitable for luminaires of protection classes I and II
  • Installation in emergency lighting systems according to IEC 61347-2-3, appendix J
Dimming interface: DALI-2, Touch DIM, Corridor
Programming interface: Dipswitch
Programming device: DALI, DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, EL, RCM, UKCA, CCC, KC, BIS
4062172306232SELV5.3…29.4 W15…42 VDipswitches
350 mA, 400 mA, 450 mA, 500 mA, 550 mA, 600 mA, 650 mA, 700 mA
IT DALI 42/220-240/1A0 CS 🛈
Product family benefits
  • Safety ensured by OSRAM (SELV)
  • DALI-2 certified
  • High flexibility due to eight different output currents
  • Touch DIM application: easy to control via pushbutton or sensor
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Higher quality of light thanks to low output ripple current
  • Small housing for flexible luminaire designs
  • Housing from 80% recycled plastic
Areas of applicationion
  • Offices
  • Shops
  • Hospitality
  • Panels, spotlight, downlight, and other indoor LED luminaires
  • Suitable for indoor SELV equivalent installations
  • Suitable for luminaires of protection classes I and II
  • Installation in emergency lighting systems according to IEC 61347-2-3, appendix J
Dimming interface: DALI-2, Touch DIM, Corridor
Programming interface: Dipswitch
Programming device: DALI, DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, EL, RCM, UKCA, CCC, KC, BIS
4062172306256SELV10.5…42 W15…42 VDipswitches
700 mA, 750 mA, 800 mA, 850 mA, 900 mA, 950 mA, 1000 mA, 1050 mA
IT DALI 15/220-240/350 CS 🛈
Product family benefits
  • Safety ensured by OSRAM (SELV)
  • DALI-2 certified
  • High flexibility due to eight different output currents
  • Touch DIM application: easy to control via pushbutton or sensor
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Higher quality of light thanks to low output ripple current
  • Small housing for flexible luminaire designs
  • Housing from 80% recycled plastic
Areas of applicationion
  • Offices
  • Shops
  • Hospitality
  • Panels, spotlight, downlight, and other indoor LED luminaires
  • Suitable for indoor SELV equivalent installations
  • Suitable for luminaires of protection classes I and II
  • Installation in emergency lighting systems according to IEC 61347-2-3, appendix J
Dimming interface: DALI-2, Touch DIM, Corridor
Programming interface: Dipswitch
Programming device: DALI, DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, EL, RCM, UKCA, CCC, KC, BIS
4062172373883SELV0.9…14.7 W9…42 VDipswitches
100 mA, 120 mA, 150 mA, 180 mA, 200 mA, 250 mA, 300 mA, 350 mA
IT DALI 60/220-240/1A4 CS NEW🛈
Product family benefits
  • Safety ensured by OSRAM (SELV)
  • DALI-2 certified
  • High flexibility due to eight different output currents
  • Touch DIM application: easy to control via pushbutton or sensor
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Higher quality of light thanks to low output ripple current
  • Small housing for flexible luminaire designs
  • Housing from 80% recycled plastic
Areas of applicationion
  • Offices
  • Shops
  • Hospitality
  • Panels, spotlight, downlight, and other indoor LED luminaires
  • Suitable for indoor SELV equivalent installations
  • Suitable for luminaires of protection classes I and II
  • Installation in emergency lighting systems according to IEC 61347-2-3, appendix J
Dimming interface: DALI-2, Touch DIM, Corridor
Programming interface: Dipswitch
Programming device: DALI, DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, EL, RCM, CCC, KC, BIS
4062172373982SELV60 W27…54 VDipswitches
700 mA, 800 mA, 900 mA, 1000 mA, 1050 mA, 1200 mA, 1300 mA, 1400 mA
Phase Cut
OTe 10/220-240/700 PC 🛈
Product family benefits
  • Compact housing for mounting in very tight spaces
  • Compatible with the most common leading-edge and trailing-edge phase dimmers
Areas of applicationion
  • Optional cable clamp E-style for independent mounting
  • Suitable for indoor installations
  • Suitable for indoor SELV installations
Dimming interface: Phase Cut

Type of protection
IP20		Certificates & Approbations
CE, ENEC 10, VDE, CB
4052899105300SELV10 W7…14 V700 mA
OTe 13/220-240/350 PC 🛈
Product family benefits
  • Compact housing for mounting in very tight spaces
  • Compatible with the most common leading-edge and trailing-edge phase dimmers
Areas of applicationion
  • Optional cable clamp E-style for independent mounting
  • Suitable for indoor installations
  • Suitable for indoor SELV installations
Dimming interface: Phase Cut

Type of protection
IP20		Certificates & Approbations
CE, ENEC 10, VDE, CB
4052899105324SELV13 W18…38 V350 mA
OTe 18/220-240/350 PC 🛈
Product family benefits
  • Compact housing for mounting in very tight spaces
  • Compatible with the most common leading-edge and trailing-edge phase dimmers
Areas of applicationion
  • Optional cable clamp E-style for independent mounting
  • Suitable for indoor installations
  • Suitable for indoor SELV installations
Dimming interface: Phase Cut

Type of protection
IP20		Certificates & Approbations
CE, ENEC 10, VDE, CB
4052899105348SELV19 W27…54 V350 mA
OTe 18/220-240/500 PC 🛈
Product family benefits
  • Compact housing for mounting in very tight spaces
  • Compatible with the most common leading-edge and trailing-edge phase dimmers
Areas of applicationion
  • Optional cable clamp E-style for independent mounting
  • Suitable for indoor installations
  • Suitable for indoor SELV installations
Dimming interface: Phase Cut

Type of protection
IP20		Certificates & Approbations
CE, ENEC 10, VDE, CB
4052899105362SELV18 W18…36 V500 mA
OTe 25/220-240/700 PC 🛈
Product family benefits
  • Compact housing for mounting in very tight spaces
  • Compatible with the most common leading-edge and trailing-edge phase dimmers
Areas of applicationion
  • Optional cable clamp E-style for independent mounting
  • Suitable for indoor installations
  • Suitable for indoor SELV installations
Dimming interface: Phase Cut

Type of protection
IP20		Certificates & Approbations
CE, ENEC 10, VDE, CB
4052899105386SELV25 W18…36 V700 mA
OT FIT Dipswitch Phase Cut
OT FIT 40/220-240/1A0 CS PC 🛈
Product family benefits
  • Compatible with the most common leading-edge and trailing-edge phase dimmers
  • Flexible current setting (DIPswitch – 2 to 4 currents)
  • Flicker-free dimming
  • Higher quality of light thanks to 5% output ripple current
  • Housing from 80% recycled plastic
Areas of applicationion
  • Decorative illumination
  • Downlights, flat luminaires
  • Hospitality
  • Living areas
  • Museums, residential buildings
  • Offices
  • Shop lighting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I and II
Dimming interface: Phase Cut
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE
4052899617261SELV21.6…42 W27…40 VDipswitches
800 mA, 900 mA, 950 mA, 1050 mA
OT FIT 30/220-240/700 CS PC 🛈
Product family benefits
  • Compatible with the most common leading-edge and trailing-edge phase dimmers
  • Flexible current setting (DIPswitch – 2 to 4 currents)
  • Flicker-free dimming
  • Higher quality of light thanks to 5% output ripple current
  • Housing from 80% recycled plastic
Areas of applicationion
  • Decorative illumination
  • Downlights, flat luminaires
  • Hospitality
  • Living areas
  • Museums, residential buildings
  • Offices
  • Shop lighting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I and II
Dimming interface: Phase Cut

Type of protection
IP20		Certificates & Approbations
CE
4052899617308SELV13.5…28 W27…40 VDipswitches
500 mA, 700 mA
OT FIT 8/220-240/180 CS PC PHASE OUT🛈
Product family benefits
  • Compatible with the most common leading-edge and trailing-edge phase dimmers
  • Flexible current setting (DIPswitch – 2 to 4 currents)
  • Flicker-free dimming
  • Higher quality of light thanks to 5% output ripple current
  • Housing from 80% recycled plastic
Areas of applicationion
  • Decorative illumination
  • Downlights, flat luminaires
  • Hospitality
  • Living areas
  • Museums, residential buildings
  • Offices
  • Shop lighting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I and II
Dimming interface: Phase Cut
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, CCC, ENEC, EAC, RCM
4062172007535SELV7.2 W27…40 VDipswitches
100 mA, 120 mA, 155 mA, 180 mA
OT FIT 18/220-240/450 CS PC 🛈
Product family benefits
  • Compatible with the most common leading-edge and trailing-edge phase dimmers
  • Flexible current setting (DIPswitch – 2 to 4 currents)
  • Flicker-free dimming
  • Higher quality of light thanks to 5% output ripple current
  • Housing from 80% recycled plastic
Areas of applicationion
  • Decorative illumination
  • Downlights, flat luminaires
  • Hospitality
  • Living areas
  • Museums, residential buildings
  • Offices
  • Shop lighting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I and II
Dimming interface: Phase Cut
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, CCC, ENEC, EAC, RCM
4062172007559SELV18 W27…40 VDipswitches
225 mA, 325 mA, 350 mA, 450 mA
OT FIT 14/220-240/350 CS PC 🛈
Product family benefits
  • Compatible with the most common leading-edge and trailing-edge phase dimmers
  • Flexible current setting (DIPswitch – 2 to 4 currents)
  • Flicker-free dimming
  • Higher quality of light thanks to 5% output ripple current
  • Housing from 80% recycled plastic
Areas of applicationion
  • Decorative illumination
  • Downlights, flat luminaires
  • Hospitality
  • Living areas
  • Museums, residential buildings
  • Offices
  • Shop lighting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I and II
Dimming interface: Phase Cut
Programming interface: Dipswitch
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CCC, CE, UKCA, ENEC
4062172286503SELV5.4…14 W27…40 VDipswitches
200 mA, 250 mA, 300 mA, 350 mA
OT FIT 7/220-240/180 CS PC 🛈
Product family benefits
  • Compatible with the most common leading-edge and trailing-edge phase dimmers
  • Flexible current setting (DIPswitch – 2 to 4 currents)
  • Flicker-free dimming
  • Higher quality of light thanks to 5% output ripple current
  • Housing from 80% recycled plastic
Areas of applicationion
  • Decorative illumination
  • Downlights, flat luminaires
  • Hospitality
  • Living areas
  • Museums, residential buildings
  • Offices
  • Shop lighting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I and II
Dimming interface: Phase Cut
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CCC, CE, UKCA, ENEC
4062172286541SELV2.7…7.2 W27…40 VDipswitches
100 mA, 120 mA, 155 mA, 180 mA
OT FIT Dipswitch Phase Cut Screw Terminal
OT FIT 8/220-240/180 CS PC SC PHASE OUT🛈
Product family benefits
  • Compatible with the most common leading-edge and trailing-edge phase dimmers
  • Flexible current setting (DIPswitch – 2 to 4 currents)
  • Flicker-free dimming
  • Higher quality of light thanks to 5% output ripple current
  • Housing from 80% recycled plastic
Areas of applicationion
  • Decorative illumination
  • Downlights, flat luminaires
  • Hospitality
  • Living areas
  • Museums, residential buildings
  • Offices
  • Shop lighting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I and II
Dimming interface: Phase Cut
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, CCC, ENEC, EAC, RCM
4062172088688SELV7.2 W27…40 VDipswitches
100 mA, 120 mA, 155 mA, 180 mA
OT FIT 40/220-240/1A0 CS PC SC PHASE OUT🛈
Product family benefits
  • Compatible with the most common leading-edge and trailing-edge phase dimmers
  • Flexible current setting (DIPswitch – 2 to 4 currents)
  • Flicker-free dimming
  • Higher quality of light thanks to 5% output ripple current
  • Housing from 80% recycled plastic
Areas of applicationion
  • Decorative illumination
  • Downlights, flat luminaires
  • Hospitality
  • Living areas
  • Museums, residential buildings
  • Offices
  • Shop lighting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection class I and II
Dimming interface: Phase Cut
Programming device: DIPswitch

Type of protection
IP20		Certificates & Approbations
CE, ENEC, EAC
4062172131438SELV21.6…42 W27…40 VDipswitches
800 mA, 900 mA, 950 mA, 1050 mA
OT NFC Wireless Intelligent Low Profile
OT WI 15/220-240/1A0 NFC BL LP 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile QBM window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: Qualified Bluetooth mesh by Silvair
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EAC, EL
4062172227810SELV18 W10…54 V150…1050 mA
OT WI 25/220-240/700 NFC BL LP 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile QBM window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: Qualified Bluetooth mesh by Silvair
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EAC, EL
4062172227834SELV27 W10…54 V180…700 mA
OT WI 40/220-240/1A0 NFC BL LP 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile QBM window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: Qualified Bluetooth mesh by Silvair
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EAC, EL
4062172227858SELV38 W10…54 V350…1050 mA
OT WI 15/220-240/1A0 NFC BL LPI 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile QBM window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: Qualified Bluetooth mesh by Silvair
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EAC, EL
4062172227872SELV18 W10…54 V150…1050 mA
OT WI 25/220-240/700 NFC BL LPI 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile QBM window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: Qualified Bluetooth mesh by Silvair
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EAC, EL
4062172227919SELV27 W10…54 V180…700 mA
OT WI 40/220-240/1A0 NFC BL LPI 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile QBM window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: Qualified Bluetooth mesh by Silvair
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EAC, EL
4062172227933SELV38 W10…54 V350…1050 mA
OT WI 15/220-240/1A0 NFC CA LP 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile CASAMBI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: Bluetooth CASAMBI
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EAC, EL, BIS
4062172227971SELV18 W10…54 V150…1050 mA
OT WI 25/220-240/700 NFC CA LP 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile CASAMBI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: Bluetooth CASAMBI
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EAC, EL, BIS
4062172227995SELV27 W10…54 V180…700 mA
OT WI 40/220-240/1A0 NFC CA LP 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile CASAMBI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: Bluetooth CASAMBI
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EAC, EL, BIS
4062172228015SELV38 W10…54 V350…1050 mA
OT WI 15/220-240/1A0 NFC CA LPI 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile CASAMBI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: Bluetooth CASAMBI
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EAC, EL, BIS
4062172228039SELV18 W10…54 V150…1050 mA
OT WI 25/220-240/700 NFC CA LPI 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile CASAMBI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: Bluetooth CASAMBI
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EAC, EL, BIS
4062172228053SELV27 W10…54 V180…700 mA
OT WI 40/220-240/1A0 NFC CA LPI 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile CASAMBI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: Bluetooth CASAMBI
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EAC, EL, BIS
4062172228077SELV38 W10…54 V350…1050 mA
OT NFC Wireless Intelligent Track black
OT WI 40/220-240/1A0 NFC BL T-B 🛈
Product family benefits
  • High quality of light thanks to low output ripple current
  • Short housing for minimum distance between spotlights
  • Versatile QBM window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • High-quality dimming of 1…100 % by amplitude dimming
  • SELV system
Areas of applicationion
  • Track lights
  • Shops and hospitality: retail, hotels, restaurants
Dimming interface: Qualified Bluetooth mesh by Silvair
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, CQC, RCM
4062172310574SELV2.7…40 W18…42 V150…1050 mA
OT WI 40/220-240/1A0 NFC CA T-B 🛈
Product family benefits
  • High quality of light thanks to low output ripple current
  • Short housing for minimum distance between spotlights
  • Versatile CASAMBI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • High-quality dimming of 1…100 % by amplitude dimming
  • SELV system
Areas of applicationion
  • Track lights
  • Shops and hospitality: retail, hotels, restaurants
Dimming interface: Bluetooth CASAMBI
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, CQC, RCM
4062172310611SELV2.7…40 W18…42 V150…1050 mA
OT NFC Wireless Intelligent Track grey
OT WI 40/220-240/1A0 NFC BL T-G 🛈
Product family benefits
  • High quality of light thanks to low output ripple current
  • Short housing for minimum distance between spotlights
  • Versatile QBM window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • High-quality dimming of 1…100 % by amplitude dimming
  • SELV system
Areas of applicationion
  • Track lights
  • Shops and hospitality: retail, hotels, restaurants
Dimming interface: Qualified Bluetooth mesh by Silvair
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, CQC, RCM
4062172350129SELV2.7…40 W18…42 V150…1050 mA
OT WI 40/220-240/1A0 NFC CA T-G 🛈
Product family benefits
  • High quality of light thanks to low output ripple current
  • Short housing for minimum distance between spotlights
  • Versatile CASAMBI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • High-quality dimming of 1…100 % by amplitude dimming
  • SELV system
Areas of applicationion
  • Track lights
  • Shops and hospitality: retail, hotels, restaurants
Dimming interface: Bluetooth CASAMBI
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, CQC, RCM
4062172350143SELV2.7…40 W18…42 V150…1050 mA
OT NFC Wireless Intelligent Track white
OT WI 40/220-240/1A0 NFC BL T-W 🛈
Product family benefits
  • High quality of light thanks to low output ripple current
  • Short housing for minimum distance between spotlights
  • Versatile QBM window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • High-quality dimming of 1…100 % by amplitude dimming
  • SELV system
Areas of applicationion
  • Track lights
  • Shops and hospitality: retail, hotels, restaurants
Dimming interface: Qualified Bluetooth mesh by Silvair
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, CQC, RCM
4062172310598SELV2.7…40 W18…42 V150…1050 mA
OT WI 40/220-240/1A0 NFC CA T-W 🛈
Product family benefits
  • High quality of light thanks to low output ripple current
  • Short housing for minimum distance between spotlights
  • Versatile CASAMBI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • High-quality dimming of 1…100 % by amplitude dimming
  • SELV system
Areas of applicationion
  • Track lights
  • Shops and hospitality: retail, hotels, restaurants
Dimming interface: Bluetooth CASAMBI
Programming interface: NFC
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, CQC, RCM
4062172310635SELV2.7…40 W18…42 V150…1050 mA
OTI DALI
OTi DALI 25/220-240/700 LT2 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Very high efficiency
  • Protection of the system thanks to thermal management and Smart Control
  • High-quality dimming of 1…100 % by amplitude dimming
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
Areas of applicationion
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for use in luminaires with flexible current setting (DALI, CLO, LEDset)
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
  • Suitable for downlights, spotlights and LED panels
  • Installation via Cable Clamp Kit possible (depending on version of product)
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, LEDset
Programming device: DALI, LEDset

Type of protection
IP20		Certificates & Approbations
ENEC 10, VDE, EMC, EL, CE, DALI-2, BIS
4052899488144SELV27 W12…54 V180…700 mA
OTi DALI 35/220-240/1A0 LT2 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Very high efficiency
  • Protection of the system thanks to thermal management and Smart Control
  • High-quality dimming of 1…100 % by amplitude dimming
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
Areas of applicationion
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for use in luminaires with flexible current setting (DALI, CLO, LEDset)
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
  • Suitable for downlights, spotlights and LED panels
  • Installation via Cable Clamp Kit possible (depending on version of product)
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, LEDset
Programming device: DALI, LEDset

Type of protection
IP20		Certificates & Approbations
ENEC 10, VDE, EMC, EL, CE, DALI-2, BIS
4052899488168SELV35 W15…54 V350…1050 mA
OTi DALI 50/220-240/1A4 LT2 FAN 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Very high efficiency
  • Protection of the system thanks to thermal management and Smart Control
  • High-quality dimming of 1…100 % by amplitude dimming
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
Areas of applicationion
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for use in luminaires with flexible current setting (DALI, CLO, LEDset)
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
  • Suitable for downlights, spotlights and LED panels
  • Installation via Cable Clamp Kit possible (depending on version of product)
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, LEDset
Programming device: DALI, LEDset

Type of protection
IP20		Certificates & Approbations
ENEC 10, VDE, EMC, EL, CE, DALI-2, BIS
4052899488182SELV55 W15…54 V600…1400 mA
OTi DALI 15/220-240/1A0 LT2 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Very high efficiency
  • Protection of the system thanks to thermal management and Smart Control
  • High-quality dimming of 1…100 % by amplitude dimming
Versatile scope of application due to OSRAM DALI Technology:
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
  • Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
Areas of applicationion
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for use in luminaires with flexible current setting (DALI, CLO, LEDset)
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
  • Suitable for downlights, spotlights and LED panels
  • Installation via Cable Clamp Kit possible (depending on version of product)
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, LEDset
Programming device: DALI, LEDset

Type of protection
IP20		Certificates & Approbations
ENEC 10, VDE, EMC, EL, CE, DALI-2, BIS
4062172143912SELV18 W7.5…54 V150…1050 mA
OTI DALI NFC
OTi DALI 25/220-240/700 NFC 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Locking and unlocking of luminaire/driver data
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Versatile scope of application due to OSRAM DALI Technology:
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13,appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
Areas of applicationion
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for use in luminaires with flexible current setting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
  • Suitable for downlights, spotlights and LED panels
  • Installation via Cable Clamp Kit possible (depending on version of product)
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, EL, ENEC 10, VDE, VDE-EMC, DALI-2, EAC, MM
4062172017909SELV27 W15…54 V180…700 mA
OTi DALI 35/220-240/1A0 NFC 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Locking and unlocking of luminaire/driver data
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Versatile scope of application due to OSRAM DALI Technology:
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13,appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
Areas of applicationion
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for use in luminaires with flexible current setting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
  • Suitable for downlights, spotlights and LED panels
  • Installation via Cable Clamp Kit possible (depending on version of product)
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, EL, ENEC 10, VDE, VDE-EMC, DALI-2, EAC, MM
4062172017923SELV35 W15…54 V350…1050 mA
OTi DALI 15/220-240/1A0 NFC 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Locking and unlocking of luminaire/driver data
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Versatile scope of application due to OSRAM DALI Technology:
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13,appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
Areas of applicationion
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for use in luminaires with flexible current setting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
  • Suitable for downlights, spotlights and LED panels
  • Installation via Cable Clamp Kit possible (depending on version of product)
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, EL, ENEC 10, VDE-EMC, DALI-2
4062172061766SELV18 W7.5…54 V150…1050 mA
OTi DALI 50/220-240/1A4 NFC 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Locking and unlocking of luminaire/driver data
  • Advanced luminaire/driver data (power, energy, operating hours…) for analytics
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Versatile scope of application due to OSRAM DALI Technology:
  • Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13,appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
  • Feedback of power consumption and operating hours (Fit for SMART GRID)
  • Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
Areas of applicationion
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for use in luminaires with flexible current setting
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
  • Suitable for downlights, spotlights and LED panels
  • Installation via Cable Clamp Kit possible (depending on version of product)
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, EL, DALI-2, EAC
4062172061889SELV55 W15…54 V600…1400 mA
OTi DALI 10/220-240/700 NFC PHASE OUT🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Locking and unlocking of luminaire/driver data
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
ENEC 10, VDE, EMC, EL, CE, DALI-2, CCC
4062172143899SELV10 W2.5…45 V150…700 mA
OTi DALI 10/220-240/700 NFC 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile DALI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
ENEC 10, VDE, EL, CE, UKCA, DALI-2, CCC, RCM, EAC
4062172250269SELV10 W2.5…45 V150…700 mA
OTI DALI NFC Independent
OTi DALI 20/220-240/500 NFC I 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Locking and unlocking of luminaire/driver data
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, EL, DALI-2, EAC
4062172114967SELV20 W20…50 V200…500 mA
OTi DALI 30/220-240/700 NFC I 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Locking and unlocking of luminaire/driver data
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, EL, DALI-2, EAC
4062172114981SELV30 W20…50 V350…700 mA
OTi DALI 40/220-240/1A0 NFC I 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Locking and unlocking of luminaire/driver data
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, EL, DALI-2, EAC
4062172115001SELV40 W20…50 V500…1050 mA
OTi DALI 10/220-240/700 NFC I 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile DALI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
ENEC, VDE-EMC, EL, CE, DALI-2
4062172151252SELV10 W2.5…45 V150…700 mA
OTi DALI 25/220-240/700 NFC I 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, EL, DALI-2, EAC
4062172201797SELV2.7…27 W15…54 V180…700 mA
OTi DALI 35/220-240/1A0 NFC I 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, EL, DALI-2, EAC
4062172201810SELV5.25…35 W15…54 V350…1050 mA
OTi DALI 60/220-240/1A4 NFC I 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, EL, DALI-2, EAC
4062172201834SELV22…58 W15…54 V600…1400 mA
OTI DALI NFC Low Profile
OTi DALI 50/220-240/1A4 NFC LP 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile DALI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, EL, DALI-2, EAC
4062172224024SELV55 W15…54 V600…1400 mA
OTi DALI 15/220-240/1A0 NFC LP 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile DALI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EL, DALI-2, EAC, BIS
4062172227674SELV18 W10…54 V150…1050 mA
OTi DALI 25/220-240/700 NFC LP 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile DALI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EL, DALI-2, EAC, BIS
4062172227698SELV27 W10…54 V180…700 mA
OTi DALI 40/220-240/1A0 NFC LP 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile DALI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EL, DALI-2, EAC, BIS
4062172227711SELV38 W10…54 V350…1050 mA
OTi DALI 15/220-240/1A0 NFC LPI 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile DALI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EL, DALI-2, EAC, BIS
4062172227735SELV18 W10…54 V150…1050 mA
OTi DALI 25/220-240/700 NFC LPI 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile DALI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EL, DALI-2, EAC, BIS
4062172227759SELV27 W10…54 V180…700 mA
OTi DALI 40/220-240/1A0 NFC LPI 🛈
Product family benefits
  • Small housing for flexible luminaire designs
  • Versatile DALI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy to use in corridors and restrooms because of three-level Corridor function
  • Touch DIM application: easy to control via pushbutton or sensor
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EL, DALI-2, EAC, BIS
4062172227773SELV38 W10…54 V350…1050 mA
OTI DALI NFC Small built-in
OTi DALI 20/220-240/500 NFC S 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Locking and unlocking of luminaire/driver data
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, EL, DALI-2, EAC, CCC, ENEC
4062172110068SELV20 W20…50 V200…500 mA
OTi DALI 30/220-240/700 NFC S 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Locking and unlocking of luminaire/driver data
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, EL, DALI-2, EAC
4062172110082SELV30 W20…50 V350…700 mA
OTi DALI 40/220-240/1A0 NFC S 🛈
Product family benefits
  • Versatile DALI window driver due to flexible output characteristic
  • Locking and unlocking of luminaire/driver data
  • Easy and fast output current setting via NFC
  • Very high efficiency
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
Areas of applicationion
  • Suitable for downlights, spotlights and LED panels
  • Suitable for use in luminaires with flexible current setting
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Suitable for indoor SELV installations
  • Suitable for luminaires of protection classes I and II
Dimming interface: DALI-2
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, EL, DALI-2, EAC
4062172110105SELV40 W20…50 V500…1050 mA
OTI DALI NFC Track black
OTi DALI 40/220-240/1A0 NFC T-B 🛈
Product family benefits
  • High quality of light thanks to low output ripple current
  • Short housing for minimum distance between spotlights
  • Versatile DALI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
  • Touch DIM application: easy to control via pushbutton or sensor
  • SELV system
Areas of applicationion
  • Track lights
  • Shops and hospitality: retail, hotels, restaurants
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, DALI-2, CQC, RCM
4062172310475SELV2.7…40 W18…42 V150…1050 mA
OTI DALI NFC Track grey
OTi DALI 40/220-240/1A0 NFC T-G 🛈
Product family benefits
  • High quality of light thanks to low output ripple current
  • Short housing for minimum distance between spotlights
  • Versatile DALI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
  • Touch DIM application: easy to control via pushbutton or sensor
  • SELV system
Areas of applicationion
  • Track lights
  • Shops and hospitality: retail, hotels, restaurants
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, DALI-2, CQC, RCM
4062172350105SELV2.7…40 W18…42 V150…1050 mA
OTI DALI NFC Track white
OTi DALI 40/220-240/1A0 NFC T-W 🛈
Product family benefits
  • High quality of light thanks to low output ripple current
  • Short housing for minimum distance between spotlights
  • Versatile DALI window driver due to flexible output characteristic
  • Easy and fast output current setting via NFC
  • High-quality dimming of 1…100 % by amplitude dimming
  • DALI-2 certified incl. Parts 251, 252, 253
  • Touch DIM application: easy to control via pushbutton or sensor
  • SELV system
Areas of applicationion
  • Track lights
  • Shops and hospitality: retail, hotels, restaurants
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, DALI-2, CQC, RCM
4062172310529SELV2.7…40 W18…42 V150…1050 mA
Constant Current | Compact | Dimmable | Outdoor
IT DALI 20/220-240/1A0 E 🛈
Product family benefits
  • Versatile DALI driver due to flexible output characteristic
  • High surge protection: up to 10 kV (single pulse or more)
  • Long lasting and high reliability
  • Fully programmable via T4T software (DALI / AstroDIM / Constant Lumen)
  • 5 years guarantee
  • Great flexibility due to wide operating temperature range of up to -40…60 °C (+55°C for some products)
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • High efficiency
  • High-quality amplitude dimming
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: DALI-2, AstroDIM
Programming device: DALI

Type of protection
IP20		Certificates & Approbations
CE, CCC, EAC, RCM, VDE, VDE-EMC, UKCA, DALI-2, ENEC
4052899620254SELV20 W15…29 V350…1050 mA
IT DALI 40/220-240/1A0 E 🛈
Product family benefits
  • Versatile DALI driver due to flexible output characteristic
  • High surge protection: up to 10 kV (single pulse or more)
  • Long lasting and high reliability
  • Fully programmable via T4T software (DALI / AstroDIM / Constant Lumen)
  • 5 years guarantee
  • Great flexibility due to wide operating temperature range of up to -40…60 °C (+55°C for some products)
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • High efficiency
  • High-quality amplitude dimming
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM, DALI-2
Programming device: DALI

Type of protection
IP20		Certificates & Approbations
CCC, CE, EAC, RCM, DALI-2, VDE, VDE-EMC, UKCA, ENEC
4052899620261SELV40 W29…57 V350…1050 mA
IT DALI 75/220-240/1A0 E 🛈
Product family benefits
  • Versatile DALI driver due to flexible output characteristic
  • High surge protection: up to 10 kV (single pulse or more)
  • Long lasting and high reliability
  • Fully programmable via T4T software (DALI / AstroDIM / Constant Lumen)
  • 5 years guarantee
  • Great flexibility due to wide operating temperature range of up to -40…60 °C (+55°C for some products)
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • High efficiency
  • High-quality amplitude dimming
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM, DALI-2
Programming device: DALI

Type of protection
IP20		Certificates & Approbations
CCC, CE, EAC, RCM, DALI-2, UKCA, VDE, VDE-ENEC, ENEC
4052899620278SELV75 W55…107 V350…1050 mA
IT DALI 110/220-240/1A0 E 🛈
Product family benefits
  • Versatile DALI driver due to flexible output characteristic
  • High surge protection: up to 10 kV (single pulse or more)
  • Long lasting and high reliability
  • Fully programmable via T4T software (DALI / AstroDIM / Constant Lumen)
  • 5 years guarantee
  • Great flexibility due to wide operating temperature range of up to -40…60 °C (+55°C for some products)
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • High efficiency
  • High-quality amplitude dimming
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM, DALI-2
Programming device: DALI

Type of protection
IP20		Certificates & Approbations
CCC, CE, EAC, RCM, DALI-2, UKCA, VDE-EMC, VDE, ENEC
4052899620285Double110 W75…157 V350…1050 mA
IT DALI 150/220-240/1A0 E 🛈
Product family benefits
  • Versatile DALI driver due to flexible output characteristic
  • High surge protection: up to 10 kV (single pulse or more)
  • Long lasting and high reliability
  • Fully programmable via T4T software (DALI / AstroDIM / Constant Lumen)
  • 5 years guarantee
  • Great flexibility due to wide operating temperature range of up to -40…60 °C (+55°C for some products)
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • High efficiency
  • High-quality amplitude dimming
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM, DALI-2
Programming device: DALI

Type of protection
IP20		Certificates & Approbations
CCC, CE, RCM, EAC, UKCA, DALI-2, VDE, VDE-EMC, ENEC
4052899620292Basic150 W110…214 V350…1050 mA
IT DALI 200/220-240/1A0 E 🛈
Product family benefits
  • Versatile DALI driver due to flexible output characteristic
  • High surge protection: up to 10 kV (single pulse or more)
  • Long lasting and high reliability
  • Fully programmable via T4T software (DALI / AstroDIM / Constant Lumen)
  • 5 years guarantee
  • Great flexibility due to wide operating temperature range of up to -40…60 °C (+55°C for some products)
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • High efficiency
  • High-quality amplitude dimming
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM, DALI-2
Programming device: DALI

Type of protection
IP20		Certificates & Approbations
CCC, CE, DALI-2, EAC, ENEC, RCM, UKCA
4062172286619Basic200 W145…285 V350…1050 mA
P7
IT DALI 20/120-240/1A0 P7 🛈
Product family benefits
  • Versatile DALI driver due to flexible output characteristic
  • Fully programmable via T4T software (DALI / AstroDIM / Constant Lumen)
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • High efficiency
  • High surge protection: up to 10 kV
  • IP rating: IP67 (Independent installation)
  • High efficiency and reliability
  • 5 years guarantee
Areas of applicationion
  • Industry lighting
  • Street and urban lighting
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: DALI-2, AstroDIM
Programming device: DALI

Type of protection
IP67		Certificates & Approbations
CCC, CE, TISI, RCM, ENEC, UKCA, DALI-2, IP67
4052899620308SELV20 W15…29 V350…1050 mA
IT DALI 40/120-240/1A0 P7 🛈
Product family benefits
  • Versatile DALI driver due to flexible output characteristic
  • Fully programmable via T4T software (DALI / AstroDIM / Constant Lumen)
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • High efficiency
  • High surge protection: up to 10 kV
  • IP rating: IP67 (Independent installation)
  • High efficiency and reliability
  • 5 years guarantee
Areas of applicationion
  • Industry lighting
  • Street and urban lighting
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: DALI-2, AstroDIM
Programming device: DALI

Type of protection
IP67		Certificates & Approbations
CCC, CE, TISI, RCM, ENEC, DALI-2, UKCA, IP67
4052899620315SELV40 W29…57 V350…1050 mA
IT DALI 75/120-240/1A0 P7 🛈
Product family benefits
  • Versatile DALI driver due to flexible output characteristic
  • Fully programmable via T4T software (DALI / AstroDIM / Constant Lumen)
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • High efficiency
  • High surge protection: up to 10 kV
  • IP rating: IP67 (Independent installation)
  • High efficiency and reliability
  • 5 years guarantee
Areas of applicationion
  • Industry lighting
  • Street and urban lighting
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: DALI-2, AstroDIM
Programming device: DALI

Type of protection
IP67		Certificates & Approbations
CCC, CE, TISI, RCM, ENEC, DALI-2, UKCA, IP67
4052899620322SELV75 W55…108 V350…1050 mA
IT DALI 110/120-240/1A0 P7 🛈
Product family benefits
  • Versatile DALI driver due to flexible output characteristic
  • Fully programmable via T4T software (DALI / AstroDIM / Constant Lumen)
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • High efficiency
  • High surge protection: up to 10 kV
  • IP rating: IP67 (Independent installation)
  • High efficiency and reliability
  • 5 years guarantee
Areas of applicationion
  • Industry lighting
  • Street and urban lighting
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: DALI-2, AstroDIM
Programming device: DALI

Type of protection
IP67		Certificates & Approbations
CCC, CE, TISI, RCM, ENEC, UKCA, DALI-2, IP67
4052899620339Double110 W75…157 V350…1050 mA
IT DALI 150/120-240/1A0 P7 🛈
Product family benefits
  • Versatile DALI driver due to flexible output characteristic
  • Fully programmable via T4T software (DALI / AstroDIM / Constant Lumen)
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • High efficiency
  • High surge protection: up to 10 kV
  • IP rating: IP67 (Independent installation)
  • High efficiency and reliability
  • 5 years guarantee
Areas of applicationion
  • Industry lighting
  • Street and urban lighting
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: DALI-2, AstroDIM
Programming device: DALI

Type of protection
IP67		Certificates & Approbations
CCC, CE, TISI, RCM, ENEC, UKCA, DALI-2, IP67
4052899620346Basic150 W110…214 V350…1050 mA
IT DALI 200/120-240/1A0 P7 🛈
Product family benefits
  • Versatile DALI driver due to flexible output characteristic
  • Fully programmable via T4T software (DALI / AstroDIM / Constant Lumen)
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • High efficiency
  • High surge protection: up to 10 kV
  • IP rating: IP67 (Independent installation)
  • High efficiency and reliability
  • 5 years guarantee
Areas of applicationion
  • Industry lighting
  • Street and urban lighting
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: DALI-2, AstroDIM
Programming device: DALI

Type of protection
IP67		Certificates & Approbations
CCC, CE, TISI, RCM, DALI-2, ENEC, UKCA, IP67
4052899620353Basic200 W145..286 V350…1050 mA
IT DALI 240/120-240/1A0 P7 🛈
Product family benefits
  • Versatile DALI driver due to flexible output characteristic
  • Fully programmable via T4T software (DALI / AstroDIM / Constant Lumen)
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • High efficiency
  • High surge protection: up to 10 kV
  • IP rating: IP67 (Independent installation)
  • High efficiency and reliability
  • 5 years guarantee
Areas of applicationion
  • Industry lighting
  • Street and urban lighting
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: DALI-2, AstroDIM
Programming device: DALI

Type of protection
IP67		Certificates & Approbations
CCC, CE, TISI, RCM, DALI-2, ENEC, UKCA, IP67
4062172286633Basic240 W172…343 V350…1050 mA
OT 1DIM Astro G1
OT 20/170-240/1A0 1DIMLT2 G1 CE 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • Optimized for AstroDIM operation
  • Wide current output range: 200 mA…1050 mA
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Protection through double isolation between mains input and LED output
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 65
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, ENEC, VDE, VDE-EMC, CCC
4052899517400SELV22 W10…38 V200…1050 mA
OT 40/170-240/1A0 1DIMLT2 G1 CE 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • Optimized for AstroDIM operation
  • Wide current output range: 200 mA…1050 mA
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Protection through double isolation between mains input and LED output
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 65
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, ENEC, VDE, VDE-EMC, CCC
4052899517424SELV40 W15…56 V200…1050 mA
OT 75/170-240/1A0 1DIMLT2 G1 CE 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • Optimized for AstroDIM operation
  • Wide current output range: 200 mA…1050 mA
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Protection through double isolation between mains input and LED output
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 65
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, ENEC, VDE, VDE-EMC, CCC
4052899541092SELV75 W35…115 V200…1050 mA
OT 110/170-240/1A0 1DIMLT2 G1 CE 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • Optimized for AstroDIM operation
  • Wide current output range: 200 mA…1050 mA
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Protection through double isolation between mains input and LED output
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 65
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, ENEC, VDE, VDE-EMC, CCC
4052899541115Double110 W80…220 V200…1050 mA
OT 1DIM Astro G2
OT 75/220-240/1A0 1DIM G2 CE 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • Optimized for AstroDIM operation
  • Wide current output range: 200 mA…1050 mA
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Protection through double isolation between mains input and LED output
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 65
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, ENEC, VDE, VDE-EMC, CCC, EAC
4052899605367Double75 W35…115 V200…1050 mA
OT 165/220-240/1A0 1DIM G2 CE 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • Optimized for AstroDIM operation
  • Wide current output range: 200 mA…1050 mA
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Protection through double isolation between mains input and LED output
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 65
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CE, ENEC, VDE, VDE-EMC, CCC, EAC
4052899605381Double165 W130…260 V200…1050 mA
OT 1DIM Astro P7
OT 60/220-240/1A4 1DIMA P7 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 6 kV
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Optimized for AstroDIM operation
Areas of applicationion
  • Street and urban lighting
  • Industry
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP67		Certificates & Approbations
CCC, CE, ENEC
4052899495012Double60 W43…86 V700…1400 mA
OT 100/220-240/1A4 1DIMA P7 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 6 kV
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Optimized for AstroDIM operation
Areas of applicationion
  • Street and urban lighting
  • Industry
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP67		Certificates & Approbations
CCC, CE, ENEC
4052899495036Double100 W72…144 V700…1400 mA
OT 150/220-240/1A4 1DIMA P7 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 6 kV
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Optimized for AstroDIM operation
Areas of applicationion
  • Street and urban lighting
  • Industry
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP67		Certificates & Approbations
CCC, CE, ENEC
4052899495050Basic150 W107…214 V700…1400 mA
OT 200/220-240/1A4 1DIMA P7 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 6 kV
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Optimized for AstroDIM operation
Areas of applicationion
  • Street and urban lighting
  • Industry
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP67		Certificates & Approbations
CCC, CE, ENEC
4052899495074Basic200 W143…286 V700…1400 mA
OT 2DIM Astro
OT 50/120-277/800 2DIMLT2 P 🛈
Product family benefits
  • 2DIM functionality in one device (AstroDIM, 0…10 V)
  • High surge protection: up to 6 kV (in protection class I or II)
  • Fast programming without mains voltage
  • High efficiency
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Protection through double isolation between mains input and LED output
  • IP rating: IP64
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for luminaires of protection classes I and II
Dimming interface: 2DIM, 1…10 V, AstroDIM
Programming device: OT Programmer

Type of protection
IP64		Certificates & Approbations
CE, ENEC 15, UR, CQC
4052899173781SELV50 W30…115 V350…800 mA
OT 50/120-277/1A2 2DIMLT2 P 🛈
Product family benefits
  • 2DIM functionality in one device (AstroDIM, 0…10 V)
  • High surge protection: up to 6 kV (in protection class I or II)
  • Fast programming without mains voltage
  • High efficiency
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Protection through double isolation between mains input and LED output
  • IP rating: IP64
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for luminaires of protection classes I and II
Dimming interface: 2DIM, 1…10 V, AstroDIM
Programming device: OT Programmer

Type of protection
IP64		Certificates & Approbations
CE, ENEC 15, UR, CQC
4052899173804SELV50 W20…55 V600…1250 mA
OT 110/120-277/1A4 2DIMLT2 P 🛈
Product family benefits
  • 2DIM functionality in one device (AstroDIM, 0…10 V)
  • High surge protection: up to 6 kV (in protection class I or II)
  • Fast programming without mains voltage
  • High efficiency
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Protection through double isolation between mains input and LED output
  • IP rating: IP64
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for luminaires of protection classes I and II
Dimming interface: 2DIM, 1…10 V, AstroDIM
Programming device: OT Programmer

Type of protection
IP64		Certificates & Approbations
CE, ENEC 15, UR, CQC
4052899253438SELV110 W35…85 V600…1400 mA
OT 100/120-277/800 2DIMLT2 P PHASE OUT🛈
Product family benefits
  • 2DIM functionality in one device (AstroDIM, 0…10 V)
  • High surge protection: up to 6 kV (in protection class I or II)
  • Fast programming without mains voltage
  • High efficiency
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Protection through double isolation between mains input and LED output
  • IP rating: IP64
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for luminaires of protection classes I and II
Dimming interface: 2DIM, 1…10 V, AstroDIM
Programming device: OT Programmer

Type of protection
IP64		Certificates & Approbations
CE, ENEC 15, UR, CQC
4062172069151Double/reinforced100 W50…186 V350…800 mA
OT 2DIM Astro P7
OT 400/220-240/ 1A4 2DIM P7 AUX12 🛈
Product family benefits
  • Easily programmable by OT Programmer-S, (AstroDIM / Constant lumen)
  • Efficient and reliable
  • 2DIM functionality in one device (AstroDIM, 1…10 V)
  • High surge protection: up to 10 kV
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Lifetime: up to 100,000 h
  • IP rating: IP67
  • 5 years guarantee
Areas of applicationion
  • Area lighting
  • Stadium lighting
  • Horticulture lighting
  • Street and urban lighting
  • Suitable for luminaires of protection class I
Dimming interface: 1…10 V, 2DIM
Programming device: OT Programmer-S

Type of protection
IP67		Certificates & Approbations
CCC, CE, CB, ENEC, RCM
4052899624221Basic400 W247…380 V1050…1400 mA
OT 100/ 220-240/1A4 2DIM P7 🛈
Product family benefits
  • Easily programmable by NFC (AstroDIM / Constant lumen)
  • High surge protection: up to 10 kV
  • High efficiency
  • Lifetime: up to 100,000 h
Areas of applicationion
  • Street and urban lighting
  • Industry lighting
  • Suitable for luminaires of protection class I
Dimming interface: AstroDIM, 1…10 V, Pulse Width Modulation
Programming interface: NFC
Programming device: NFC

Type of protection
IP67		Certificates & Approbations
CE, CCC, RCM, ENEC 05, TISI
4062172060677Double50…100 W72…144 V700…1400 mA
OT 150/ 220-240/1A4 2DIM P7 🛈
Product family benefits
  • Easily programmable by NFC (AstroDIM / Constant lumen)
  • High surge protection: up to 10 kV
  • High efficiency
  • Lifetime: up to 100,000 h
Areas of applicationion
  • Street and urban lighting
  • Industry lighting
  • Suitable for luminaires of protection class I
Dimming interface: AstroDIM, 1…10 V, Pulse Width Modulation
Programming interface: NFC
Programming device: NFC

Type of protection
IP67		Certificates & Approbations
CE, CCC, RCM, ENEC 05, TISI
4062172060691Basic75…150 W107…214 V700…1400 mA
OT 200/ 220-240/1A4 2DIM P7 🛈
Product family benefits
  • Easily programmable by NFC (AstroDIM / Constant lumen)
  • High surge protection: up to 10 kV
  • High efficiency
  • Lifetime: up to 100,000 h
Areas of applicationion
  • Street and urban lighting
  • Industry lighting
  • Suitable for luminaires of protection class I
Dimming interface: AstroDIM, 1…10 V, Pulse Width Modulation
Programming interface: NFC
Programming device: NFC

Type of protection
IP67		Certificates & Approbations
CE, CCC, RCM, ENEC 05, TISI
4062172069649Basic100…200 W121…286 V700…1400 mA
OT 240/ 220-240/1A0 2DIM P7 🛈
Product family benefits
  • Easily programmable by NFC (AstroDIM / Constant lumen)
  • High surge protection: up to 10 kV
  • High efficiency
  • Lifetime: up to 100,000 h
Areas of applicationion
  • Street and urban lighting
  • Industry lighting
  • Suitable for luminaires of protection class I
Dimming interface: AstroDIM, 1…10 V, Pulse Width Modulation
Programming interface: NFC
Programming device: NFC

Type of protection
IP67		Certificates & Approbations
CE, CCC, RCM, ENEC 05, TISI
4062172069663Basic120…240 W228…343 V700…1050 mA
OT 2DIM P7
OT 600/220-240/ 2A1 2DIM P7 AUX12 🛈
Product family benefits
  • Easily programmable by OT Programmer-S, (AstroDIM / Constant lumen)
  • Efficient and reliable
  • 2DIM functionality in one device (AstroDIM, 1…10 V)
  • High surge protection: up to 10 kV
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Lifetime: up to 100,000 h
  • IP rating: IP67
  • 5 years guarantee
Areas of applicationion
  • Area lighting
  • Stadium lighting
  • Horticulture lighting
  • Street and urban lighting
  • Suitable for luminaires of protection class I
Dimming interface: 1…10 V, 2DIM
Programming device: OT Programmer-S

Type of protection
IP67		Certificates & Approbations
CCC, CE, ENEC, RCM, CB
4052899624238Basic600 W225…343 V1750…2100 mA
OT 2DIM UNV Astro P7
OT 100 UNV 1A0 2DIM P7 🛈
Product family benefits
  • 2DIM functionality in one device (AstroDIM, 1…10 V)
  • High surge protection: up to 10 kV
  • High efficiency up to 92%
  • Great flexibility due to wide operating temperature range of -40…60 °C
  • IP rating: IP67
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for luminaires of protection class I
Dimming interface: 2DIM, 1…10 V, AstroDIM
Programming device: OT PROGRAMMER/5

Type of protection
IP67		Certificates & Approbations
CCC, CE, ENEC, UL
4062172158169Double/reinforced105 W75…150 V500…1050 mA
OT 150 UNV 1A0 2DIM P7 🛈
Product family benefits
  • 2DIM functionality in one device (AstroDIM, 1…10 V)
  • High surge protection: up to 10 kV
  • High efficiency up to 92%
  • Great flexibility due to wide operating temperature range of -40…60 °C
  • IP rating: IP67
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for luminaires of protection class I
Dimming interface: 2DIM, 1…10 V, AstroDIM
Programming device: OT PROGRAMMER/5

Type of protection
IP67		Certificates & Approbations
CCC, CE, ENEC, UL
4062172158183Double/reinforced150 W107…214 V520…1050 mA
OT 200 UNV 1A0 2DIM P7 🛈
Product family benefits
  • 2DIM functionality in one device (AstroDIM, 1…10 V)
  • High surge protection: up to 10 kV
  • High efficiency up to 92%
  • Great flexibility due to wide operating temperature range of -40…60 °C
  • IP rating: IP67
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for luminaires of protection class I
Dimming interface: 2DIM, 1…10 V, AstroDIM
Programming device: OT PROGRAMMER/5

Type of protection
IP67		Certificates & Approbations
CCC, CE, ENEC, UL
4062172158206Double/reinforced200 W143…286 V520…1050 mA
OT 320 UNV 1A1 2DIM P7 🛈
Product family benefits
  • 2DIM functionality in one device (AstroDIM, 1…10 V)
  • High surge protection: up to 10 kV
  • High efficiency up to 92%
  • Great flexibility due to wide operating temperature range of -40…60 °C
  • IP rating: IP67
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for luminaires of protection class I
Dimming interface: 2DIM, 1…10 V, AstroDIM
Programming device: OT PROGRAMMER/5

Type of protection
IP67		Certificates & Approbations
CCC, CE, ENEC, UL
4062172158220Double/reinforced320 W228…457 V520…1100 mA
OT 4DIM Astro G2
OT 20/170-240/1A0 4DIMLT2 G2 CE 🛈
Product family benefits
  • 4DIM functionality in one device (StepDIM, AstroDIM, MainsDIM, DALI)
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • Wide current output range: 200 mA…1050 mA
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • Protection through double isolation between mains input and LED output
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: 4DIM, AstroDIM, DALI, MainsDIM, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, DALI-2, EL, ENEC, RCM, VDE, VDE-EMC
4052899981928SELV22 W10…38 V200…1050 mA
OT 40/170-240/1A0 4DIMLT2 G2 CE 🛈
Product family benefits
  • 4DIM functionality in one device (StepDIM, AstroDIM, MainsDIM, DALI)
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • Wide current output range: 200 mA…1050 mA
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • Protection through double isolation between mains input and LED output
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: 4DIM, AstroDIM, DALI, MainsDIM, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, DALI-2, EL, ENEC, RCM, VDE, VDE-EMC
4052899981935SELV40 W15…56 V200…1050 mA
OT 75/170…240/1A0 4DIMLT2 G2 CE 🛈
Product family benefits
  • 4DIM functionality in one device (StepDIM, AstroDIM, MainsDIM, DALI)
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • Wide current output range: 200 mA…1050 mA
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • Protection through double isolation between mains input and LED output
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: 4DIM, AstroDIM, DALI, MainsDIM, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, DALI-2, EL, ENEC, RCM, VDE, VDE-EMC
4052899981942SELV75 W35…115 V250…1050 mA
OT 110/170…240/1A0 4DIMLT2 G2 CE 🛈
Product family benefits
  • 4DIM functionality in one device (StepDIM, AstroDIM, MainsDIM, DALI)
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • Wide current output range: 200 mA…1050 mA
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • Protection through double isolation between mains input and LED output
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: 4DIM, AstroDIM, DALI, MainsDIM, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, DALI-2, EL, ENEC, RCM, VDE, VDE-EMC
4052899981959Double110 W80…220 V200…1050 mA
OT 165/170-240/1A0 4DIMLT2 G2 CE 🛈
Product family benefits
  • 4DIM functionality in one device (StepDIM, AstroDIM, MainsDIM, DALI)
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • Wide current output range: 200 mA…1050 mA
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • Protection through double isolation between mains input and LED output
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: 4DIM, AstroDIM, DALI, MainsDIM, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, DALI-2, EL, ENEC, VDE, VDE-EMC
4062172053952Double165 W130…260 V200…1050 mA
OT DEXAL
OT DX 40/220-240/1A0 DIMA LT2 E 🛈
Product family benefits
  • For Zhaga Book18 Luminaires and D4i certified incl. Parts 25x + AUX
  • Electrical interface and data communication fully based on open standards
  • Fully programmable via software (DALI Interface, NFC)
  • Low luminous efficacy tolerance through low output current tolerance of ± 3 %
  • High surge protection: up to 10 kV (1 pulse) in protection class I or II
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • Mains input undervoltage protection
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM, DALI/DEXAL/D4i, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, ENEC, VDE, VDE-EMC, CCC, EL, DALI-2, D4i, RCM
4052899999664SELV40 W15…56 V200…1050 mA
OT DX 75/220-240/1A0 DIMA LT2 E 🛈
Product family benefits
  • For Zhaga Book18 Luminaires and D4i certified incl. Parts 25x + AUX
  • Electrical interface and data communication fully based on open standards
  • Fully programmable via software (DALI Interface, NFC)
  • Low luminous efficacy tolerance through low output current tolerance of ± 3 %
  • High surge protection: up to 10 kV (1 pulse) in protection class I or II
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • Mains input undervoltage protection
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM, DALI/DEXAL/D4i, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, ENEC, VDE, VDE-EMC, CCC, EL, DALI-2, D4i, RCM
4052899999671SELV75 W35…115 V200…1050 mA
OT DX 110/220-240/1A0 DIMA LT2 E 🛈
Product family benefits
  • For Zhaga Book18 Luminaires and D4i certified incl. Parts 25x + AUX
  • Electrical interface and data communication fully based on open standards
  • Fully programmable via software (DALI Interface, NFC)
  • Low luminous efficacy tolerance through low output current tolerance of ± 3 %
  • High surge protection: up to 10 kV (1 pulse) in protection class I or II
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • Mains input undervoltage protection
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM, DALI/DEXAL/D4i, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, ENEC, VDE, VDE-EMC, CCC, EL, DALI-2, D4i, RCM
4052899999688Double110 W75…220 V200…1050 mA
OT DX 165/220-240/1A0 DIMA LT2 E 🛈
Product family benefits
  • For Zhaga Book18 Luminaires and D4i certified incl. Parts 25x + AUX
  • Electrical interface and data communication fully based on open standards
  • Fully programmable via software (DALI Interface, NFC)
  • Low luminous efficacy tolerance through low output current tolerance of ± 3 %
  • High surge protection: up to 10 kV (1 pulse) in protection class I or II
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • Mains input undervoltage protection
  • Very high efficiency
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM, DALI/DEXAL/D4i, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, ENEC, VDE, VDE-EMC, CCC, EL, DALI-2, D4i, RCM
4052899999695Double165 W130…260 V200…1050 mA
OT DEXAL NFC G2
OT DX 40/170-240/1A0 DIMA NFC G2 CE 🛈
Product family benefits
  • For Zhaga Book18 Luminaires and D4i certified incl. Parts 25x + AUX
  • Electrical interface and data communication fully based on open standards
  • Fully programmable via software (DALI Interface, NFC)
  • Low luminous efficacy tolerance through low output current tolerance of ± 1,5 %
  • High surge protection: up to 10 kV in protection class I or II
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • Mains input undervoltage protection
  • DEXAL interface (with 15V current supply on DALI-2 lines - DALI Part 250)
  • SELV DEXAL and 24V AUX interface (DALI Part 150) up to 6W
  • Standardized DALI-2 communication (incl. monitoring data, energy metering)
  • Integrated ESD protection: more robust for installation on non-conductive poles
  • Optimized NFC for programming from the top: easy accessibility in luminaires
  • Surge and overvoltage protection on DALI interface for DALI installations
  • Full compatibility with Tuner4TRONIC and T4T Field App
  • BOX Programming: all drivers in one BOX can be programmed in one step
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM, DALI/DEXAL/D4i, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, D4i, DALI-2, EL, ENEC, RCM, VDE
4052899631649Double40 W15…65 V150…1050 mA
OT DX 75/170-240/1A0 DIMA NFC G2 CE 🛈
Product family benefits
  • For Zhaga Book18 Luminaires and D4i certified incl. Parts 25x + AUX
  • Electrical interface and data communication fully based on open standards
  • Fully programmable via software (DALI Interface, NFC)
  • Low luminous efficacy tolerance through low output current tolerance of ± 1,5 %
  • High surge protection: up to 10 kV in protection class I or II
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • Mains input undervoltage protection
  • DEXAL interface (with 15V current supply on DALI-2 lines - DALI Part 250)
  • SELV DEXAL and 24V AUX interface (DALI Part 150) up to 6W
  • Standardized DALI-2 communication (incl. monitoring data, energy metering)
  • Integrated ESD protection: more robust for installation on non-conductive poles
  • Optimized NFC for programming from the top: easy accessibility in luminaires
  • Surge and overvoltage protection on DALI interface for DALI installations
  • Full compatibility with Tuner4TRONIC and T4T Field App
  • BOX Programming: all drivers in one BOX can be programmed in one step
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM, DALI/DEXAL/D4i, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, D4i, DALI-2, EL, ENEC, RCM, VDE
4052899631663Double75 W35…150 V150…1050 mA
OT DX 110/170-240/1A0 DIMA NFC G2 CE 🛈
Product family benefits
  • For Zhaga Book18 Luminaires and D4i certified incl. Parts 25x + AUX
  • Electrical interface and data communication fully based on open standards
  • Fully programmable via software (DALI Interface, NFC)
  • Low luminous efficacy tolerance through low output current tolerance of ± 1,5 %
  • High surge protection: up to 10 kV in protection class I or II
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • Mains input undervoltage protection
  • DEXAL interface (with 15V current supply on DALI-2 lines - DALI Part 250)
  • SELV DEXAL and 24V AUX interface (DALI Part 150) up to 6W
  • Standardized DALI-2 communication (incl. monitoring data, energy metering)
  • Integrated ESD protection: more robust for installation on non-conductive poles
  • Optimized NFC for programming from the top: easy accessibility in luminaires
  • Surge and overvoltage protection on DALI interface for DALI installations
  • Full compatibility with Tuner4TRONIC and T4T Field App
  • BOX Programming: all drivers in one BOX can be programmed in one step
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM, DALI/DEXAL/D4i, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, D4i, DALI-2, EL, ENEC, RCM, VDE
4052899631694Double110 W65…230 V150…1050 mA
OT DX 165/170-240/1A0 DIMA NFC G2 CE 🛈
Product family benefits
  • For Zhaga Book18 Luminaires and D4i certified incl. Parts 25x + AUX
  • Electrical interface and data communication fully based on open standards
  • Fully programmable via software (DALI Interface, NFC)
  • Low luminous efficacy tolerance through low output current tolerance of ± 1,5 %
  • High surge protection: up to 10 kV in protection class I or II
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • Mains input undervoltage protection
  • DEXAL interface (with 15V current supply on DALI-2 lines - DALI Part 250)
  • SELV DEXAL and 24V AUX interface (DALI Part 150) up to 6W
  • Standardized DALI-2 communication (incl. monitoring data, energy metering)
  • Integrated ESD protection: more robust for installation on non-conductive poles
  • Optimized NFC for programming from the top: easy accessibility in luminaires
  • Surge and overvoltage protection on DALI interface for DALI installations
  • Full compatibility with Tuner4TRONIC and T4T Field App
  • BOX Programming: all drivers in one BOX can be programmed in one step
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM, DALI/DEXAL/D4i, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, D4i, DALI-2, EL, ENEC, RCM, VDE
4052899631717Double165 W90…260 V150…1050 mA
OT DX 200/170-240/1A0 DIMA NFC G2 CE 🛈
Product family benefits
  • For Zhaga Book18 Luminaires and D4i certified incl. Parts 25x + AUX
  • Electrical interface and data communication fully based on open standards
  • Fully programmable via software (DALI Interface, NFC)
  • Low luminous efficacy tolerance through low output current tolerance of ± 1,5 %
  • High surge protection: up to 10 kV in protection class I or II
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • Mains input undervoltage protection
  • DEXAL interface (with 15V current supply on DALI-2 lines - DALI Part 250)
  • SELV DEXAL and 24V AUX interface (DALI Part 150) up to 6W
  • Standardized DALI-2 communication (incl. monitoring data, energy metering)
  • Integrated ESD protection: more robust for installation on non-conductive poles
  • Optimized NFC for programming from the top: easy accessibility in luminaires
  • Surge and overvoltage protection on DALI interface for DALI installations
  • Full compatibility with Tuner4TRONIC and T4T Field App
  • BOX Programming: all drivers in one BOX can be programmed in one step
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM, DALI/DEXAL/D4i, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, D4i, DALI-2, EL, ENEC, RCM, VDE
4052899631731Double200 W140…300 V150…1050 mA
OT DX 24/170-240/0A7 DIMA NFC G2 CE 🛈
Product family benefits
  • For Zhaga Book18 Luminaires and D4i certified incl. Parts 25x + AUX
  • Electrical interface and data communication fully based on open standards
  • Fully programmable via software (DALI Interface, NFC)
  • Low luminous efficacy tolerance through low output current tolerance of ± 1,5 %
  • High surge protection: up to 10 kV in protection class I or II
  • Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
  • Mains input undervoltage protection
  • DEXAL interface (with 15V current supply on DALI-2 lines - DALI Part 250)
  • SELV DEXAL and 24V AUX interface (DALI Part 150) up to 6W
  • Standardized DALI-2 communication (incl. monitoring data, energy metering)
  • Integrated ESD protection: more robust for installation on non-conductive poles
  • Optimized NFC for programming from the top: easy accessibility in luminaires
  • Surge and overvoltage protection on DALI interface for DALI installations
  • Full compatibility with Tuner4TRONIC and T4T Field App
  • BOX Programming: all drivers in one BOX can be programmed in one step
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM, DALI/DEXAL/D4i, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, D4i, DALI-2, EL, ENEC, RCM, VDE
4052899632349Double24 W12…48 V150…700 mA
OT NFC 1DIM Astro G3
OT 20/170-240/1A0 1DIM NFC G3 CE 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, ENEC, RCM, VDE
4052899631861SELV22 W10…38 V150…1050 mA
OT 40/170-240/1A0 1DIM NFC G3 CE 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, ENEC, RCM, VDE
4052899631885SELV40 W15…56 V150…1050 mA
OT 75/170-240/1A0 1DIM NFC G3 CE 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, ENEC, RCM, VDE
4052899631908SELV75 W35…115 V150…1050 mA
OT 110/170-240/1A0 1DIM NFC G3 CE 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, ENEC, RCM, VDE
4052899631922Double110 W55…157 V150…1050 mA
OT 165/170-240/1A0 1DIM NFC G3 CE 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, ENEC, RCM, VDE
4052899631939Double165 W90…260 V150…1050 mA
OT NFC 1DIM G3
OT 40/170-240/0A7 1DIM NFC G3 CE 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, ENEC, RCM, VDE
4052899631878SELV40 W30…77 V150…700 mA
OT 75/170-240/0A7 1DIM NFC G3 CE 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, ENEC, RCM, VDE
4052899631892Double75 W50…150 V150…700 mA
OT 110/170-240/0A7 1DIM NFC G3 CE 🛈
Product family benefits
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: AstroDIM
Programming device: NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, ENEC, RCM, VDE
4052899631915Double110 W80…220 V150…700 mA
OT NFC 4DIM Astro G3
OT 20/170-240/1A0 4DIM NFC G3 CE 🛈
Product family benefits
  • 4DIM functionality in one device (StepDIM, AstroDIM, MainsDIM, DALI)
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • High surge DALI protection: 1 kV
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: 4DIM, AstroDIM, DALI, MainsDIM, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, DALI-2, EL, ENEC, RCM, VDE
4062172218917SELV22 W10…38 V150…1050 mA
OT 40/170-240/1A0 4DIM NFC G3 CE 🛈
Product family benefits
  • 4DIM functionality in one device (StepDIM, AstroDIM, MainsDIM, DALI)
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • High surge DALI protection: 1 kV
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: 4DIM, AstroDIM, DALI, MainsDIM, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, DALI-2, EL, ENEC, RCM, VDE
4062172218955SELV40 W15…56 V150…1050 mA
OT 75/170-240/1A0 4DIM NFC G3 CE 🛈
Product family benefits
  • 4DIM functionality in one device (StepDIM, AstroDIM, MainsDIM, DALI)
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • High surge DALI protection: 1 kV
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: 4DIM, AstroDIM, DALI, MainsDIM, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, DALI-2, EL, ENEC, RCM, VDE
4062172218993SELV75 W35…115 V150…1050 mA
OT 110/170-240/1A0 4DIM NFC G3 CE 🛈
Product family benefits
  • 4DIM functionality in one device (StepDIM, AstroDIM, MainsDIM, DALI)
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • High surge DALI protection: 1 kV
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: 4DIM, AstroDIM, DALI, MainsDIM, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, DALI-2, EL, ENEC, RCM, VDE
4062172219037Double110 W55…157 V150…1050 mA
OT 165/170-240/1A0 4DIM NFC G3 CE 🛈
Product family benefits
  • 4DIM functionality in one device (StepDIM, AstroDIM, MainsDIM, DALI)
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • High surge DALI protection: 1 kV
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: 4DIM, AstroDIM, DALI, MainsDIM, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, DALI-2, EL, ENEC, RCM, VDE
4062172219075Double165 W90…260 V150…1050 mA
OT 200/170-240/1A0 4DIM NFC G3 CE 🛈
Product family benefits
  • 4DIM functionality in one device (StepDIM, AstroDIM, MainsDIM, DALI)
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • High surge DALI protection: 1 kV
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: 4DIM, AstroDIM, DALI, MainsDIM, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, DALI-2, EL, ENEC, RCM, VDE
4062172219105Double200 W140…300 V150…1050 mA
OT NFC 4DIM G3
OT 40/170-240/0A7 4DIM NFC G3 CE 🛈
Product family benefits
  • 4DIM functionality in one device (StepDIM, AstroDIM, MainsDIM, DALI)
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • High surge DALI protection: 1 kV
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: 4DIM, AstroDIM, DALI, MainsDIM, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, DALI-2, EL, ENEC, RCM, VDE
4062172218931SELV40 W30…77 V150…700 mA
OT 75/170-240/0A7 4DIM NFC G3 CE 🛈
Product family benefits
  • 4DIM functionality in one device (StepDIM, AstroDIM, MainsDIM, DALI)
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • High surge DALI protection: 1 kV
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: 4DIM, AstroDIM, DALI, MainsDIM, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, DALI-2, EL, ENEC, RCM, VDE
4062172218979Double75 W50…150 V150…700 mA
OT 75/170-240/1A5 4DIM NFC G3 CE 🛈
Product family benefits
  • 4DIM functionality in one device (StepDIM, AstroDIM, MainsDIM, DALI)
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • High surge DALI protection: 1 kV
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: 4DIM, AstroDIM, DALI, MainsDIM, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, DALI-2, EL, ENEC, RCM, VDE
4062172219013SELV75 W25…75 V350…1500 mA
OT 110/170-240/0A7 4DIM NFC G3 CE 🛈
Product family benefits
  • 4DIM functionality in one device (StepDIM, AstroDIM, MainsDIM, DALI)
  • DALI-2 certified incl. Parts 251, 252, 253
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • High surge DALI protection: 1 kV
  • Protection through double isolation between mains input and LED output
  • Optimized NFC for programming from the top: easy accessibility in luminaires
Areas of applicationion
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP 54
  • Suitable for use in outdoor luminaires of protection class I and II
Dimming interface: 4DIM, AstroDIM, DALI, MainsDIM, StepDIM
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CCC, CE, DALI-2, EL, ENEC, RCM, VDE
4062172219051Double110 W80…220 V150…700 mA
OTI DALI NFC TunableWhite
OTi DALI 35/220-240/1A0 NFC TW 🛈
Product family benefits
  • Control of standard white or Tunable White light acc. DALI device type 8 (DT8)
  • TouchDIM Tunable White integrated for use without additional LMS
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming
  • High quality of light thanks to 1% output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Classrooms
  • Conference rooms
  • Daylight simulation for windowless rooms
  • For Tunable White as well as for 2-channel use (e.g. direct/indirect lighting)
  • Healthcare and hospitality with HCL functionality
  • Independent mounting via Cable Clamp Kit possible
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Office with high end HCL functionality
  • Suitable for indoor and outdoor SELV installations
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EAC, DALI-2, EL
4062172123501SELV38 W15…54 V350…1050 mA
OTi DALI 50/220-240/1A4 NFC TW 🛈
Product family benefits
  • Control of standard white or Tunable White light acc. DALI device type 8 (DT8)
  • TouchDIM Tunable White integrated for use without additional LMS
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming
  • High quality of light thanks to 1% output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Classrooms
  • Conference rooms
  • Daylight simulation for windowless rooms
  • For Tunable White as well as for 2-channel use (e.g. direct/indirect lighting)
  • Healthcare and hospitality with HCL functionality
  • Independent mounting via Cable Clamp Kit possible
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Office with high end HCL functionality
  • Suitable for indoor and outdoor SELV installations
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EAC, DALI-2, EL
4062172123525SELV55 W15…54 V600…1400 mA
OTI DALI NFC TunableWhite Independent
OTi DALI 15/220-240/1A0 NFC TW I 🛈
Product family benefits
  • Control of standard white or Tunable White light acc. DALI device type 8 (DT8)
  • TouchDIM Tunable White integrated for use without additional LMS
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming
  • High quality of light thanks to 1% output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Classrooms
  • Conference rooms
  • Daylight simulation for windowless rooms
  • For Tunable White as well as for 2-channel use (e.g. direct/indirect lighting)
  • Healthcare and hospitality with HCL functionality
  • Independent mounting via Cable Clamp Kit possible
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Office with high end HCL functionality
  • Suitable for indoor and outdoor SELV installations
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EAC, DALI-2, EL
4062172211543SELV18 W7.5…54 V150…1050 mA
OTi DALI 25/220-240/700 NFC TW I 🛈
Product family benefits
  • Control of standard white or Tunable White light acc. DALI device type 8 (DT8)
  • TouchDIM Tunable White integrated for use without additional LMS
  • Fully programmable via T4T software (NFC, DALI Interface)
  • Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
  • High-quality dimming of 1…100 % by amplitude dimming
  • High quality of light thanks to 1% output ripple current
  • Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Areas of applicationion
  • Classrooms
  • Conference rooms
  • Daylight simulation for windowless rooms
  • For Tunable White as well as for 2-channel use (e.g. direct/indirect lighting)
  • Healthcare and hospitality with HCL functionality
  • Independent mounting via Cable Clamp Kit possible
  • Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
  • Office with high end HCL functionality
  • Suitable for indoor and outdoor SELV installations
Dimming interface: DALI-2, Touch DIM, Touch DIM Sensor, Corridor
Programming interface: DALI, NFC
Programming device: DALI, NFC

Type of protection
IP20		Certificates & Approbations
CE, UKCA, ENEC, EAC, DALI-2, EL
4062172211567SELV25 W12…54 V180…700 mA
Constant Voltage | Non-dimmable
ELEMENT G2
ELEMENT 30/220-240/24 G2 🛈
Product family benefits
  • High efficiency up to 92%
  • Higher quality of light thanks to 3% output ripple current
  • Excellent price/performance ratio
  • Class II design for wide application
  • 3 years guarantee
Areas of applicationion
  • Decorative lighting in hospitality, restaurants and Shops
  • Shelf lighting
  • Cove lighting
  • Under cabinet lighting

Type of protection
IP20		Certificates & Approbations
CE, RCM, CCC, MM
4052899605503SELV30 W24 Vnot relevant mA
ELEMENT 60/220-240/24 G2 🛈
Product family benefits
  • High efficiency up to 92%
  • Higher quality of light thanks to 3% output ripple current
  • Excellent price/performance ratio
  • Class II design for wide application
  • 3 years guarantee
Areas of applicationion
  • Decorative lighting in hospitality, restaurants and Shops
  • Shelf lighting
  • Cove lighting
  • Under cabinet lighting

Type of protection
IP20		Certificates & Approbations
CE, RCM, CCC, MM
4052899605527SELV60 W24 Vnot relevant mA
ELEMENT 120/220-240/24 G2 🛈
Product family benefits
  • High efficiency up to 92%
  • Higher quality of light thanks to 3% output ripple current
  • Excellent price/performance ratio
  • Class II design for wide application
  • 3 years guarantee
Areas of applicationion
  • Decorative lighting in hospitality, restaurants and Shops
  • Shelf lighting
  • Cove lighting
  • Under cabinet lighting

Type of protection
IP20		Certificates & Approbations
CE, RCM, CCC, MM
4052899605541SELV120 W24 Vnot relevant mA
ELEMENT 180/220-240/24 G2 🛈
Product family benefits
  • High efficiency up to 92%
  • Higher quality of light thanks to 3% output ripple current
  • Excellent price/performance ratio
  • Class II design for wide application
  • 3 years guarantee
Areas of applicationion
  • Decorative lighting in hospitality, restaurants and Shops
  • Shelf lighting
  • Cove lighting
  • Under cabinet lighting

Type of protection
IP20		Certificates & Approbations
CE, RCM, CCC
4052899605565SELV180 W24 Vnot relevant mA
ELEMENT 30/220-240/12 G2 🛈
Product family benefits
  • High efficiency (up to 91 %)
  • Higher quality of light thanks to 3% output ripple current
  • Excellent price/performance ratio
  • Class II design for wide application
  • 3 years guarantee
Areas of applicationion
  • Decorative lighting in hospitality, restaurants and Shops
  • Shelf lighting
  • Cove lighting
  • Under cabinet lighting

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, MM, RCM, UKCA
4062172277846SELV30 W12.5 Vnot relevant mA
ELEMENT 60/220-240/12 G2 🛈
Product family benefits
  • High efficiency (up to 91 %)
  • Higher quality of light thanks to 3% output ripple current
  • Excellent price/performance ratio
  • Class II design for wide application
  • 3 years guarantee
Areas of applicationion
  • Decorative lighting in hospitality, restaurants and Shops
  • Shelf lighting
  • Cove lighting
  • Under cabinet lighting

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, MM, RCM, UKCA
4062172277860SELV60 W12.5 Vnot relevant mA
ELEMENT 120/220-240/12 G2 🛈
Product family benefits
  • High efficiency (up to 91 %)
  • Higher quality of light thanks to 3% output ripple current
  • Excellent price/performance ratio
  • Class II design for wide application
  • 3 years guarantee
Areas of applicationion
  • Decorative lighting in hospitality, restaurants and Shops
  • Shelf lighting
  • Cove lighting
  • Under cabinet lighting

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, MM, RCM, UKCA
4062172277884SELV120 W12.5 Vnot relevant mA
ELEMENT 180/220-240/12 G2 🛈
Product family benefits
  • High efficiency (up to 91 %)
  • Higher quality of light thanks to 3% output ripple current
  • Excellent price/performance ratio
  • Class II design for wide application
  • 3 years guarantee
Areas of applicationion
  • Decorative lighting in hospitality, restaurants and Shops
  • Shelf lighting
  • Cove lighting
  • Under cabinet lighting

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, MM, RCM, UKCA
4062172277907SELV180 W12.5 Vnot relevant mA
ELEMENT 250/220-240/24 G2 🛈
Product family benefits
  • High efficiency up to 92%
  • Higher quality of light thanks to 3% output ripple current
  • Excellent price/performance ratio
  • Class II design for wide application
  • 3 years guarantee
Areas of applicationion
  • Decorative lighting in hospitality, restaurants and Shops
  • Shelf lighting
  • Cove lighting
  • Under cabinet lighting

Type of protection
IP20		Certificates & Approbations
CE, RCM, CCC
4062172333467SELV250 W24 Vnot relevant mA
Constant voltage ECG for LED modules | Non-dimmable
IT FIT
IT FIT 30/220-240/24 🛈
Product family benefits
  • Class II design for wide application
  • Well design for Flex and Signage
  • Excellent price/quality/watt ratio
Areas of applicationion
  • Hospitality – decorative lighting, night light
  • Residential – cove lighting, under cabinet lighting
  • Shops – decorative lighting, shelf lighting
  • Restaurants – decorative lighting

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, MM
406217216800730 W24 Vnot relevant mA
IT FIT 60/220-240/24 🛈
Product family benefits
  • Class II design for wide application
  • Well design for Flex and Signage
  • Excellent price/quality/watt ratio
Areas of applicationion
  • Hospitality – decorative lighting, night light
  • Residential – cove lighting, under cabinet lighting
  • Shops – decorative lighting, shelf lighting
  • Restaurants – decorative lighting

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, MM
406217216802160 W24 Vnot relevant mA
IT FIT 120/220-240/24 🛈
Product family benefits
  • Class II design for wide application
  • Well design for Flex and Signage
  • Excellent price/quality/watt ratio
Areas of applicationion
  • Hospitality – decorative lighting, night light
  • Residential – cove lighting, under cabinet lighting
  • Shops – decorative lighting, shelf lighting
  • Restaurants – decorative lighting

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM, MM
4062172168045120 W24 Vnot relevant mA
IT FIT 180/220-240/24 🛈
Product family benefits
  • Class II design for wide application
  • Well design for Flex and Signage
  • Excellent price/quality/watt ratio
Areas of applicationion
  • Hospitality – decorative lighting, night light
  • Residential – cove lighting, under cabinet lighting
  • Shops – decorative lighting, shelf lighting
  • Restaurants – decorative lighting

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM
4062172168069180 W24 Vnot relevant mA
IT FIT 250/220-240/24 🛈
Product family benefits
  • Class II design for wide application
  • Well design for Flex and Signage
  • Excellent price/quality/watt ratio
Areas of applicationion
  • Hospitality – decorative lighting, night light
  • Residential – cove lighting, under cabinet lighting
  • Shops – decorative lighting, shelf lighting
  • Restaurants – decorative lighting

Type of protection
IP20		Certificates & Approbations
CE, CCC, RCM
4062172168083250 W24 Vnot relevant mA
Constant Voltage | Non-dimmable | Outdoor
OT FIT
OT FIT 80/220-240/24 P 🛈
Areas of applicationion
  • For example luminous signage in areas such as hotels
  • Public squares and architecture lighting
  • Suitable for indoor and outdoor SELV installations

Type of protection
IP66/IP67		Certificates & Approbations
CE, CCC, TISI, RCM
4062172085465SELV80 W24 Vnot relevant mA
OT FIT 150/220-240/24 P 🛈
Areas of applicationion
  • For example luminous signage in areas such as hotels
  • Public squares and architecture lighting
  • Suitable for indoor and outdoor SELV installations

Type of protection
IP66/IP67		Certificates & Approbations
CE, CCC, TISI, RCM
4062172085601SELV150 W24 Vnot relevant mA
OT FIT 200/220-240/24 P 🛈
Areas of applicationion
  • For example luminous signage in areas such as hotels
  • Public squares and architecture lighting
  • Suitable for indoor and outdoor SELV installations

Type of protection
IP66/IP67		Certificates & Approbations
CE, CCC, TISI, RCM
4062172085649SELV200 W24 Vnot relevant mA
OT FIT 300/220-240/24 P 🛈
Areas of applicationion
  • For example luminous signage in areas such as hotels
  • Public squares and architecture lighting
  • Suitable for indoor and outdoor SELV installations

Type of protection
IP66/IP67		Certificates & Approbations
CE, CCC, TISI, RCM
4062172085687SELV300 W24 Vnot relevant mA
CV Dimmers
OT DMX Dimmable
OT DMX DIM 5CH NEW🛈
Product family benefits
  • Control of white, Tunable White, RGB, RGBW and RGBTW LED modules
  • Independent housing for ceiling installation
  • Minimal installation effort
  • Selectable PWM frequency
Areas of applicationion
  • Suitable for indoor installations
  • Shops and hospitality: retail, hotels, restaurants
  • Museums, residential buildings, gyms
Dimming interface: DMX512 protocol

Type of protection
IP20		Certificates & Approbations
CE
6977078993838Non isolated576 W12 V, 24 V, 48 V
OT Dimmable
OT DIM 🛈
Product family benefits
  • 1…10 V control port basic isolated
Areas of applicationion
  • Suitable for indoor SELV installations
Dimming interface: 1…10 V

Type of protection
IP20		Certificates & Approbations
CE, VDE, VDE-EMC
4050300943459SELV equivalent120 W10.5…24 Vnot relevant mA
OT Wireless Intelligent Dimmable
OT WI DIM 5CH CA 🛈
Product family benefits
  • Control of white, Tunable White, RGB, RGBW and RGBTW LED modules
  • Independent housing for ceiling installation
  • Support of systems based on CASAMBI lighting control solutions
  • Minimal installation effort
  • Dry contacts for optional connection to any commercial pushbutton
Areas of applicationion
  • Suitable for indoor installations
  • Shops and hospitality: retail, hotels, restaurants
  • Museums, residential buildings

Type of protection
IP20		Certificates & Approbations
CE, UKCA
4062172382274Non isolated576 W12…48 Vnot relevant mA
OTI DALI
OTi DALI DIM 1-4CH D 🛈
Product family benefits
  • Very precise dimming thanks to digital light control
Areas of applicationion
  • Suitable for indoor installations
  • Separate installation (ceiling mounting)
Dimming interface: DALI-2, Corridor, Touch DIM

Type of protection
IP20		Certificates & Approbations
CE, EAC, RCM, ENEC 05
4062172166010SELV240 W12…48 Vnot relevant mA
CV Power supplies | Dimmable
OT Wireless Intelligent
OT WI 160/220-240/24 2CH CA 🛈
Product family benefits
  • Power supply and control of white, Tunable White, Tunable Warm White, Dim to Warm
  • Power supply and control of RGB and RGBW LED modules
  • Driver with integrated CASAMBI lighting control system
  • Slim form factor for installation in light boxes
  • No stroboscopic effect thanks to patented high PWM frequency management ( 2 kHz)
Areas of applicationion
  • Suitable for indoor installations
  • Shops and hospitality: retail, hotels, restaurants
  • Museums, residential buildings
Dimming interface: Bluetooth CASAMBI
Programming interface: CASAMBI

Type of protection
IP20		Certificates & Approbations
CE, ENEC 10, UKCA, RCM, VDE, VDE-ENEC
4052899632042SELV160 W24.2 Vnot relevant mA
OT WI 80/220-240/24 4CH CA 🛈
Product family benefits
  • Power supply and control of white, Tunable White, Tunable Warm White, Dim to Warm
  • Power supply and control of RGB and RGBW LED modules
  • Driver with integrated CASAMBI lighting control system
  • Slim form factor for installation in light boxes
  • No stroboscopic effect thanks to patented high PWM frequency management ( 2 kHz)
Areas of applicationion
  • Suitable for indoor installations
  • Shops and hospitality: retail, hotels, restaurants
  • Museums, residential buildings
Dimming interface: Bluetooth CASAMBI
Programming interface: CASAMBI

Type of protection
IP20		Certificates & Approbations
CE, ENEC 10, UKCA, RCM, VDE, VDE-ENEC
4052899632059SELV80 W24.2 Vnot relevant mA
OT WI 50/220-240/24 4CH CA 🛈
Product family benefits
  • Power supply and control of white, Tunable White, Tunable Warm White, Dim to Warm
  • Power supply and control of RGB and RGBW LED modules
  • Driver with integrated CASAMBI lighting control system
  • Slim form factor for installation in light boxes
  • No stroboscopic effect thanks to patented high PWM frequency management ( 2 kHz)
Areas of applicationion
  • Suitable for indoor installations
  • Shops and hospitality: retail, hotels, restaurants
  • Museums, residential buildings
Dimming interface: Bluetooth CASAMBI
Programming interface: CASAMBI

Type of protection
IP20		Certificates & Approbations
CE, ENEC 10, UKCA, RCM, VDE, VDE-ENEC
4052899632066SELV50 W24.2 Vnot relevant mA
OT FIT Phase Cut
OT FIT 36 /220-240/24 PC 🛈
Product family benefits
  • IP rating: IP20
  • High efficiency
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Independent installation possible
Areas of applicationion
  • Suitable for luminaires of protection classes I and II
  • Hospitality – decorative lighting, night light
  • Restaurants – decorative lighting
  • Shops – decorative lighting, shelf lighting
  • Residential – cove lighting, under cabinet lighting
Dimming interface: Phase Cut

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, UKCA, EAC, SELV, CB
4062172237390SELV2.42…36.3 W24.2 Vnot relevant mA
OT FIT 75 /220-240/24 PC 🛈
Product family benefits
  • IP rating: IP20
  • High efficiency
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Independent installation possible
Areas of applicationion
  • Suitable for luminaires of protection classes I and II
  • Hospitality – decorative lighting, night light
  • Restaurants – decorative lighting
  • Shops – decorative lighting, shelf lighting
  • Residential – cove lighting, under cabinet lighting
Dimming interface: Phase Cut

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, UKCA, EAC, SELV, CB
4062172237413SELV24.2…75.8 W24.2 Vnot relevant mA
OT FIT 150 /220-240/24 PC 🛈
Product family benefits
  • IP rating: IP20
  • High efficiency
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Independent installation possible
Areas of applicationion
  • Suitable for luminaires of protection classes I and II
  • Hospitality – decorative lighting, night light
  • Restaurants – decorative lighting
  • Shops – decorative lighting, shelf lighting
  • Residential – cove lighting, under cabinet lighting
Dimming interface: Phase Cut

Type of protection
IP20		Certificates & Approbations
CE, ENEC, CCC, RCM, UKCA, EAC, SELV, CB
4062172237642SELV60.5…151.3 W24.2 Vnot relevant mA
OTI DALI
OTi DALI 50/220-240/24 1CH 🛈
Product family benefits
  • Intelligent power matching thanks to Smart power supply
  • Form factor for mounting on the cove or in luminaires
  • No stroboscopic effect thanks to patented high PWM frequency management ( 2 kHz)
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • DALI message detection "LED Module failure"
  • IP rating: IP20
Areas of applicationion
  • Cove lighting, wall washer, corridor, handrail, luminous ceilings
  • Suitable for use in luminaires of protection class I and II
Dimming interface: DALI-2, Touch DIM

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, EAC, EL, ENEC 10, RCM, VDE, VDE-ENEC
4062172177962SELV50 W24 Vnot relevant mA
OTi DALI 80/220-240/24 1CH 🛈
Product family benefits
  • Intelligent power matching thanks to Smart power supply
  • Form factor for mounting on the cove or in luminaires
  • No stroboscopic effect thanks to patented high PWM frequency management ( 2 kHz)
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • DALI message detection "LED Module failure"
  • IP rating: IP20
Areas of applicationion
  • Cove lighting, wall washer, corridor, handrail, luminous ceilings
  • Suitable for use in luminaires of protection class I and II
Dimming interface: DALI-2, Corridor, Touch DIM

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, EAC, EL, ENEC 10, RCM, VDE, VDE-ENEC
4062172177986SELV80 W24 Vnot relevant mA
OTi DALI 160/220-240/24 1CH 🛈
Product family benefits
  • Intelligent power matching thanks to Smart power supply
  • Form factor for mounting on the cove or in luminaires
  • No stroboscopic effect thanks to patented high PWM frequency management ( 2 kHz)
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • DALI message detection "LED Module failure"
  • IP rating: IP20
Areas of applicationion
  • Cove lighting, wall washer, corridor, handrail, luminous ceilings
  • Suitable for use in luminaires of protection class I and II
Dimming interface: DALI-2, Touch DIM

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, EAC, EL, ENEC 10, RCM, VDE, VDE-ENEC
4062172178006SELV160 W24 Vnot relevant mA
OTi DALI 30/220-240/24 1CH 🛈
Product family benefits
  • Intelligent power matching thanks to Smart power supply
  • Form factor for mounting on the cove or in luminaires
  • No stroboscopic effect thanks to patented high PWM frequency management ( 2 kHz)
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • DALI message detection "LED Module failure"
  • IP rating: IP20
Areas of applicationion
  • Cove lighting, wall washer, corridor, handrail, luminous ceilings
  • Suitable for use in luminaires of protection class I and II
Dimming interface: DALI

Type of protection
IP20		Certificates & Approbations
CE, CCC, BIS, ENEC, EL, ENEC 25, RCM, UKCA
4062172329767SELV30 W24.2 Vnot relevant mA
OTI DALI G3
OTi DALI 50/220-240/24 1CH G3 🛈
Product family benefits
  • Intelligent power matching thanks to Smart power supply
  • Form factor for mounting on the cove or in luminaires
  • No stroboscopic effect thanks to patented high PWM frequency management ( 2 kHz)
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • DALI message detection "LED Module failure"
  • IP rating: IP20
Areas of applicationion
  • Cove lighting, wall washer, corridor, handrail, luminous ceilings
  • Suitable for use in luminaires of protection class I and II
Dimming interface: DALI-2, Corridor, Touch DIM

Type of protection
IP20		Certificates & Approbations
BIS, CCC, EAC, EL, ENEC 10, RCM, VDE, VDE-EMC
4062172274340SELV50 W24 Vnot relevant mA
OTi DALI 80/220-240/24 1CH G3 🛈
Product family benefits
  • Intelligent power matching thanks to Smart power supply
  • Form factor for mounting on the cove or in luminaires
  • No stroboscopic effect thanks to patented high PWM frequency management ( 2 kHz)
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • DALI message detection "LED Module failure"
  • IP rating: IP20
Areas of applicationion
  • Cove lighting, wall washer, corridor, handrail, luminous ceilings
  • Suitable for use in luminaires of protection class I and II
Dimming interface: DALI-2, Touch DIM

Type of protection
IP20		Certificates & Approbations
BIS, CCC, EAC, EL, ENEC 10, RCM, VDE, VDE-EMC
4062172274364SELV80 W24 Vnot relevant mA
OTi DALI 160/220-240/24 1CH G3 🛈
Product family benefits
  • Intelligent power matching thanks to Smart power supply
  • Form factor for mounting on the cove or in luminaires
  • No stroboscopic effect thanks to patented high PWM frequency management ( 2 kHz)
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • DALI message detection "LED Module failure"
  • IP rating: IP20
Areas of applicationion
  • Cove lighting, wall washer, corridor, handrail, luminous ceilings
  • Suitable for use in luminaires of protection class I and II
Dimming interface: DALI-2, Corridor, Touch DIM

Type of protection
IP20		Certificates & Approbations
BIS, CCC, EAC, EL, ENEC 10, RCM, VDE, VDE-EMC
4062172274388SELV160 W24 Vnot relevant mA
OTI DALI TunableWhite
OTi DALI 50/220-240/24 4CHDT6/8 🛈
Product family benefits
  • Intelligent power matching thanks to Smart power supply
  • Form factor for mounting on the cove or in luminaires
  • No stroboscopic effect thanks to patented high PWM frequency management ( 2 kHz)
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • DALI message detection "LED Module failure"
  • IP rating: IP20
Areas of applicationion
  • Cove lighting, wall washer, corridor, handrail, luminous ceilings
  • Suitable for use in luminaires of protection class I and II
Dimming interface: DALI-2, Touch DIM

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, EAC, EL, ENEC 10, RCM, VDE, VDE-ENEC
4062172177900SELV50 W24 Vnot relevant mA
OTi DALI 80/220-240/24 4CHDT6/8 🛈
Product family benefits
  • Intelligent power matching thanks to Smart power supply
  • Form factor for mounting on the cove or in luminaires
  • No stroboscopic effect thanks to patented high PWM frequency management ( 2 kHz)
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • DALI message detection "LED Module failure"
  • IP rating: IP20
Areas of applicationion
  • Cove lighting, wall washer, corridor, handrail, luminous ceilings
  • Suitable for use in luminaires of protection class I and II
Dimming interface: DALI-2, Touch DIM

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, EAC, EL, ENEC 10, RCM, VDE, VDE-ENEC
4062172177924SELV80 W24 Vnot relevant mA
OTi DALI 160/220-240/24 2CHDT6/8 🛈
Product family benefits
  • Intelligent power matching thanks to Smart power supply
  • Form factor for mounting on the cove or in luminaires
  • No stroboscopic effect thanks to patented high PWM frequency management ( 2 kHz)
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • DALI message detection "LED Module failure"
  • IP rating: IP20
Areas of applicationion
  • Cove lighting, wall washer, corridor, handrail, luminous ceilings
  • Suitable for use in luminaires of protection class I and II
Dimming interface: DALI-2, Touch DIM

Type of protection
IP20		Certificates & Approbations
BIS, CCC, CE, EAC, EL, ENEC 10, RCM, VDE, VDE-ENEC
4062172177948SELV160 W24 Vnot relevant mA
OTI DALI TunableWhite G3
OTi DALI 50/220-240/ 24 4CH DT6/8 G3 🛈
Product family benefits
  • Intelligent power matching thanks to Smart power supply
  • Form factor for mounting on the cove or in luminaires
  • No stroboscopic effect thanks to patented high PWM frequency management ( 2 kHz)
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • DALI message detection "LED Module failure"
  • IP rating: IP20
Areas of applicationion
  • Cove lighting, wall washer, corridor, handrail, luminous ceilings
  • Suitable for use in luminaires of protection class I and II
Dimming interface: DALI-2, Corridor, Touch DIM

Type of protection
IP20		Certificates & Approbations
BIS, CCC, EAC, EL, ENEC 10, RCM, VDE, VDE-EMC
4062172274289SELV50 W24 Vnot relevant mA
OTi DALI 80/220-240/ 24 4CH DT6/8 G3 🛈
Product family benefits
  • Intelligent power matching thanks to Smart power supply
  • Form factor for mounting on the cove or in luminaires
  • No stroboscopic effect thanks to patented high PWM frequency management ( 2 kHz)
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • DALI message detection "LED Module failure"
  • IP rating: IP20
Areas of applicationion
  • Cove lighting, wall washer, corridor, handrail, luminous ceilings
  • Suitable for use in luminaires of protection class I and II
Dimming interface: DALI-2, Corridor, Touch DIM

Type of protection
IP20		Certificates & Approbations
BIS, CCC, EAC, EL, ENEC 10, RCM, VDE, VDE-EMC
4062172274302SELV80 W24 Vnot relevant mA
OTi DALI 160/220-240/ 24 2CH DT6/8 G3 🛈
Product family benefits
  • Intelligent power matching thanks to Smart power supply
  • Form factor for mounting on the cove or in luminaires
  • No stroboscopic effect thanks to patented high PWM frequency management ( 2 kHz)
  • Suitable for installation in emergency lighting systems according to EN 60598-2-22
  • DALI message detection "LED Module failure"
  • IP rating: IP20
Areas of applicationion
  • Cove lighting, wall washer, corridor, handrail, luminous ceilings
  • Suitable for use in luminaires of protection class I and II
Dimming interface: DALI-2, Corridor, Touch DIM

Type of protection
IP20		Certificates & Approbations
BIS, CCC, EAC, EL, ENEC 10, RCM, VDE, VDE-EMC
4062172274326SELV160 W24 Vnot relevant mA
CV Power supplies | Dimmable | Outdoor
OT Dimmable
OT 20/220-240/24 DIM P 🛈
Product family benefits
  • Large range of products from 20 W to 250 W
  • Installation in very cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Smart Power Supply: boosting power to turn on cold LEDs
  • Independent installation possible
  • Dimming range: 1…100 %
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations
Dimming interface: 1…10 V

Type of protection
IP66		Certificates & Approbations
ENEC, RCM, CCC, EAC
4052899545809SELV20 W24.2 Vnot relevant mA
OT 40/220-240/24 DIM P 🛈
Product family benefits
  • Large range of products from 20 W to 250 W
  • Installation in very cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Smart Power Supply: boosting power to turn on cold LEDs
  • Independent installation possible
  • Dimming range: 1…100 %
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations
Dimming interface: 1…10 V

Type of protection
IP66		Certificates & Approbations
ENEC, RCM, CCC, EAC
4052899545823SELV40 W24.2 Vnot relevant mA
OT 60/220-240/24 DIM P 🛈
Product family benefits
  • Large range of products from 20 W to 250 W
  • Installation in very cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Smart Power Supply: boosting power to turn on cold LEDs
  • Independent installation possible
  • Dimming range: 1…100 %
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations
Dimming interface: 1…10 V

Type of protection
IP66		Certificates & Approbations
ENEC, RCM, CCC, EAC
4052899545847SELV60 W24.2 Vnot relevant mA
OT 100/220-240/24 DIM P 🛈
Product family benefits
  • Large range of products from 20 W to 250 W
  • Installation in very cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Smart Power Supply: boosting power to turn on cold LEDs
  • Independent installation possible
  • Dimming range: 1…100 %
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations
Dimming interface: 1…10 V

Type of protection
IP66/IP67		Certificates & Approbations
ENEC, RCM, CCC, EAC
4052899545861SELV100 W24.2 Vnot relevant mA
OT 130/220-240/24 DIM P 🛈
Product family benefits
  • Large range of products from 20 W to 250 W
  • Installation in very cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Smart Power Supply: boosting power to turn on cold LEDs
  • Independent installation possible
  • Dimming range: 1…100 %
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations
Dimming interface: 1…10 V

Type of protection
IP66/IP67		Certificates & Approbations
ENEC, RCM, CCC, EAC
4052899545885SELV130 W24.2 Vnot relevant mA
OT 250/220-240/24 DIM P 🛈
Product family benefits
  • Large range of products from 20 W to 250 W
  • Installation in very cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Smart Power Supply: boosting power to turn on cold LEDs
  • Independent installation possible
  • Dimming range: 1…100 %
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations
Dimming interface: 1…10 V

Type of protection
IP66/IP67		Certificates & Approbations
ENEC, RCM, CCC, EAC
4052899545908SELV250 W24.2 Vnot relevant mA
OTI DALI
OTi DALI 210/220-240/24 1-4 CH 🛈
Product family benefits
  • Long lasting and high reliability
  • From 1 to 4 channels to arbitrarily distribute the power
  • Suitable for installation under sunlight
  • IP66/IP67 Salt mist resistant and DC functionality
  • AstroDim functionality for automatic dimming and turn on/off
Areas of applicationion
  • Public squares and architecture lighting
  • Suitable for indoor and outdoor SELV installations
  • Suitable for use in luminaires of protection class I
Dimming interface: DALI-2

Type of protection
IP66/IP67		Certificates & Approbations
BIS, CCC, CE, EAC, ENEC 10, RCM, VDE, VDE-EMC
4062172032087SELV210 W24.7 Vnot relevant mA
OTi DALI 100/220-240/24 1-4 CH P 🛈
Product family benefits
  • Long lasting and high reliability
  • From 1 to 4 channels to arbitrarily distribute the power
  • Suitable for installation under sunlight
  • IP66/IP67 Salt mist resistant and DC functionality
  • AstroDim functionality for automatic dimming and turn on/off
Areas of applicationion
  • Public squares and architecture lighting
  • Suitable for indoor and outdoor SELV installations
  • Suitable for use in luminaires of protection class I
Dimming interface: DALI-2

Type of protection
IP66/IP67		Certificates & Approbations
CE, EAC, ENEC 10, RCM, VDE, VDE-EMC
4062172119191SELV100 W24 Vnot relevant mA
OTI DALI TunableWhite
OTi DALI 210/220-240/244CHDT6/8 P 🛈
Product family benefits
  • Long lasting and high reliability
  • From 1 to 4 channels to arbitrarily distribute the power
  • Suitable for installation under sunlight
  • IP66/IP67 Salt mist resistant and DC functionality
  • AstroDim functionality for automatic dimming and turn on/off
Areas of applicationion
  • Public squares and architecture lighting
  • Suitable for indoor and outdoor SELV installations
  • Suitable for use in luminaires of protection class I
Dimming interface: DALI-2

Type of protection
IP66/IP67		Certificates & Approbations
ENEC 10, RCM, VDE, UKCA, EL, MM
4062172364263SELV0…210 W24.7 V8.5 A
CV Power supplies | Non-dimmable | Outdoor
OT
OT 20/220-240/24 P 🛈
Product family benefits
  • Large range of products from 20 W to 250 W
  • Installation in very cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Smart Power Supply: boosting power to turn on cold LEDs
  • Independent installation possible
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations

Type of protection
IP66		Certificates & Approbations
ENEC, RCM, CCC, EAC, CE
4052899545922SELV20 W24.2 Vnot relevant mA
OT 40/220-240/24 P 🛈
Product family benefits
  • Large range of products from 20 W to 250 W
  • Installation in very cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Smart Power Supply: boosting power to turn on cold LEDs
  • Independent installation possible
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations

Type of protection
IP66		Certificates & Approbations
ENEC, RCM, CCC, EAC, CE
4052899545946SELV40 W24.2 Vnot relevant mA
OT 60/220-240/24 P 🛈
Product family benefits
  • Large range of products from 20 W to 250 W
  • Installation in very cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Smart Power Supply: boosting power to turn on cold LEDs
  • Independent installation possible
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations

Type of protection
IP66		Certificates & Approbations
ENEC, RCM, CCC, EAC, CE
4052899545960SELV60 W24.2 Vnot relevant mA
OT 100/220-240/24 P 🛈
Product family benefits
  • Large range of products from 20 W to 250 W
  • Installation in very cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Smart Power Supply: boosting power to turn on cold LEDs
  • Independent installation possible
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations

Type of protection
IP66/IP67		Certificates & Approbations
ENEC, RCM, CCC, EAC, CE
4052899545984SELV100 W24.2 Vnot relevant mA
OT 130/220-240/24 P 🛈
Product family benefits
  • Large range of products from 20 W to 250 W
  • Installation in very cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Smart Power Supply: boosting power to turn on cold LEDs
  • Independent installation possible
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations

Type of protection
IP66/IP67		Certificates & Approbations
ENEC, RCM, CCC, EAC, CE
4052899546004SELV130 W24.2 Vnot relevant mA
OT 250/220-240/24 P 🛈
Product family benefits
  • Large range of products from 20 W to 250 W
  • Installation in very cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Smart Power Supply: boosting power to turn on cold LEDs
  • Independent installation possible
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations

Type of protection
IP66/IP67		Certificates & Approbations
ENEC, RCM, CCC, EAC, CE
4052899546028SELV250 W24.2 Vnot relevant mA
OT FIT
OT FIT 60/220-240/12 P 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 300 W
  • Very high efficiency
  • IP rating: up to IP67
  • High surge protection: up to 6 kV (L-N) / 6 kV (L/N-PE)
Areas of applicationion
  • Suitable for indoor and outdoor installations
  • Ideal for mounting in very tight spaces

Type of protection
IP66/IP67		Certificates & Approbations
CE, CCC, ENEC, TISI, RCM
4062172133487SELV60 W12.5 Vnot relevant mA
OT FIT 150/220-240/12 P 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 300 W
  • Very high efficiency
  • IP rating: up to IP67
  • High surge protection: up to 6 kV (L-N) / 6 kV (L/N-PE)
Areas of applicationion
  • Suitable for indoor and outdoor installations
  • Ideal for mounting in very tight spaces

Type of protection
IP66/IP67		Certificates & Approbations
CE, CCC, ENEC, TISI, RCM
4062172133500SELV150 W12.5 Vnot relevant mA
OT FIT 300/220-240/12 P 🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 300 W
  • Very high efficiency
  • IP rating: up to IP67
  • High surge protection: up to 6 kV (L-N) / 6 kV (L/N-PE)
Areas of applicationion
  • Suitable for indoor and outdoor installations
  • Ideal for mounting in very tight spaces

Type of protection
IP66/IP67		Certificates & Approbations
CE, CCC, ENEC, TISI, RCM
4062172133548SELV300 W12.5 Vnot relevant mA
OT FIT 30/220-240/12 P NEW🛈
Product family benefits
  • Versatile scope of application due to output power range of up to 300 W
  • Very high efficiency
  • IP rating: up to IP67
  • High surge protection: up to 6 kV (L-N) / 6 kV (L/N-PE)
Areas of applicationion
  • Suitable for indoor and outdoor installations
  • Ideal for mounting in very tight spaces

Type of protection
IP67		Certificates & Approbations
CE, VDE-ENEC, UKCA
4062172392570SELV30 W12 Vnot relevant mA
OPTOTRONIC Power supplies 24V | Non-dimmable | Outdoor
OT Small built-in
OT SLIM 30/220-240/24 🛈
Product family benefits
  • Installation in cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Independent installation possible
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations

Type of protection
IP20		Certificates & Approbations
CE, CB, ENEC, CCC, EAC, RCM, BIS
4062172135733SELV30 W24.2 Vnot relevant mA
OT SLIM 60/220-240/24 🛈
Product family benefits
  • Installation in cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Independent installation possible
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations

Type of protection
IP20		Certificates & Approbations
CE, CB, ENEC, CCC, EAC, RCM, BIS
4062172135856SELV60 W24.2 Vnot relevant mA
OT SLIM 100/220-240/24 🛈
Product family benefits
  • Installation in cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Independent installation possible
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations

Type of protection
IP20		Certificates & Approbations
CE, CB, ENEC, CCC, EAC, RCM, BIS
4062172135870SELV100 W24.2 Vnot relevant mA
OT SLIM 160/220-240/24 🛈
Product family benefits
  • Installation in cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Independent installation possible
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations

Type of protection
IP20		Certificates & Approbations
CE, CB, ENEC, CCC, EAC, RCM, BIS
4062172135894SELV160 W24.2 Vnot relevant mA
OT SLIM 250/220-240/24 🛈
Product family benefits
  • Installation in cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Independent installation possible
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations

Type of protection
IP20		Certificates & Approbations
CE, CB, ENEC, CCC, EAC, RCM, BIS
4062172135917SELV250 W24.2 Vnot relevant mA
OT
OT 6/200-240/24 CE 🛈
Product family benefits
  • Installation in cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Independent installation possible
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations

Type of protection
IP65		Certificates & Approbations
CE, VDE, ENEC 10, CB
4008321113269SELV6 W24 Vnot relevant mA
OT 20/220-240/24 🛈
Product family benefits
  • Installation in cold and hot environments
  • Very stable output power
  • High electronical reversible short-circuit, overload, overtemperature protection
  • Independent installation possible
Areas of applicationion
  • Facades, public squares, cruise ships
  • Signage
  • Suitable for indoor and outdoor installations

Type of protection
IP20		Certificates & Approbations
CE, ENEC 10, VDE, VDE-EMC, C-Tick
4050300618111SELV20 W24 Vnot relevant mA
